• Cisco Nexus 9018 switch with 48x10G SFP+ ports, black silver accents
1 1

Cisco

Cisco C9500-48X-A | Catalyst 9500 48-Port 10G SFP+ Switch, Network Advantage

C9500-48X-A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9500 is a fixed 1RU enterprise core and aggregation switch built for high-density 10 Gigabit deployments. This C9500-48X-A suits campus core and aggregation layers, collapsed-core designs, and SD-Access fabric border and control plane roles.

It provides 48 x 1/10G SFP+ ports on the Cisco UADP 2.0 platform, with 16 GB of DRAM and 16 GB of flash. The platform family delivers up to 480 Gbps switching capacity and up to 360 Mpps forwarding rate. This SKU is supplied with Network Advantage licensing, which adds advanced routing, MPLS, VXLAN/BGP EVPN and SD-Access capability over the base tier. It runs Cisco IOS XE and supports redundant 1+1 hot-swappable power supplies and a field-replaceable fan tray.

Optional uplink modules C9500-NM-8X and C9500-NM-2Q, rack-mount kits and pluggable SSD options are supported, and optics compatibility is listed in the Cisco TMG Optics-to-Device Compatibility Matrix.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Cisco UADP ASIC with programmable pipeline and template-based allocation of forwarding, ACL and QoS entries
- StackWise Virtual for multichassis EtherChannel, SSO and ISSU
- Advanced routing including OSPF, EIGRP, IS-IS, BGP and PIM, plus MPLS and VXLAN/BGP EVPN
- SD-Access fabric support
- Hardware MACsec 256-bit AES-GCM encryption, secure boot and image signing
- Container-based application hosting with pluggable SSD storage
- Programmability via NETCONF, RESTCONF, gNMI/gNOI, YANG models and ZTP/PnP
- Redundant 1+1 hot-swappable power supplies and field-replaceable fan tray

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Ports: 48 x 1/10G SFP+
- Licence tier: Network Advantage
- Switching capacity: up to 480 Gbps
- Forwarding rate: up to 360 Mpps
- DRAM: 16 GB
- Flash: 16 GB
- VLAN IDs: 4,094
- Jumbo frames: 9,198 bytes
- Form factor: 1 RU
- Dimensions (H x W x D): 4.39 x 44.45 x 54.66 cm
- Power input: 90 to 264 VAC
- Operating temperature: 0 to 40 C up to 3,000 m
- Storage temperature: -20 to 65 C
- Operating humidity: 5% to 90% non-condensing
- Software: Cisco IOS XE

FAQs

Q: Which licence does the C9500-48X-A include?
A: The -A suffix denotes the Network Advantage licence tier. Cisco DNA Advantage subscription options and Smart Licensing also apply to the platform.

Q: What power supplies does it use?
A: It uses redundant 1+1 hot-swappable power supplies from the 10G UADP 2.0 platform, such as the PWR-C4-950WAC-R (AC) and PWR-C4-950WDC-R (DC). Input range is 90 to 264 VAC.

Q: Can I add uplink modules?
A: Yes. The platform supports the C9500-NM-8X (8 x 1/10G SFP/SFP+) and C9500-NM-2Q (2 x 40G QSFP+) network modules.

Q: How does it differ from other Catalyst 9500 SKUs?
A: This SKU provides 48 x 10G SFP+ ports with Network Advantage licensing. Other Catalyst 9500 models differ in port count, port speed or licence tier.

Q: Which software release does it need?
A: The UADP 2.0 platform requires Cisco IOS XE Release 16.8.1 or later.
