• Cisco C9500-16X-2Q-E 16x 10G SFP+ switch with 2x 40G QSFP+ uplinks
1 1

Cisco

Cisco C9500-16X-2Q-E | Catalyst 9500 16-Port 10G Switch, Network Essentials

C9500-16X-2Q-E

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9500 is a fixed 1RU core and aggregation switch built on the UADP 2.0 ASIC. This SKU combines 16 x 1/10G SFP/SFP+ ports with a C9500-NM-2Q network module providing 2 x 40G QSFP+ ports, and carries the Network Essentials licence tier. It suits campus core and aggregation, data centre and distribution-layer 10G/40G aggregation, SD-Access fabric border and control-plane roles, MPLS and VXLAN deployments, and collapsed-core designs.

Switching capacity reaches 480 Gbps with a forwarding rate of up to 360 Mpps. The switch supports up to 64,000 MAC addresses, 4,094 VLAN IDs and 9,198-byte jumbo frames, with 16 GB of DRAM and 16 GB of flash. Power is provided by dual 1+1 redundant AC or DC supplies, using the PWR-C4-950WAC-R (950W AC) or PWR-C4-950WDC-R (950W DC), with a field-replaceable front-to-back fan tray. The Network Essentials tier is supplied as a perpetual licence, and Cisco DNA Essentials or Advantage subscriptions add the full DNA feature set.

The chassis accepts the C9500-NM-8X (8 x 1/10G SFP/SFP+) and C9500-NM-2Q (2 x 40G QSFP+) network modules, and can be paired using StackWise Virtual. It supports Cisco Catalyst Center and Meraki cloud management, and runs Cisco IOS XE from release 16.8.1.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Cisco IOS XE with NETCONF, RESTCONF, gNMI/gNOI and YANG programmability, streaming telemetry and container-based application hosting
- Cisco StackWise Virtual with SSO and ISSU
- Support for Cisco SD-Access and BGP EVPN VXLAN
- MPLS Layer 3 VPN, EoMPLS, VPLS and MPLS-TE with advanced IPv4/IPv6 routing and multicast
- Secure Boot, image signing and Cisco Trust Anchor Module
- MACsec encryption with 256-bit AES-GCM
- Flexible NetFlow with NFv9 and IPFIX export
- Plug and Play and Zero-Touch Provisioning

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- ASIC: UADP 2.0
- Ports: 16 x 1/10G SFP/SFP+
- Network module: C9500-NM-2Q, 2 x 40G QSFP+
- Switching capacity: Up to 480 Gbps
- Forwarding rate: Up to 360 Mpps
- DRAM: 16 GB
- Flash: 16 GB
- MAC addresses: Up to 64,000
- IPv4 routes (indirect): Up to 64,000
- IPv4 host routes: Up to 80,000
- IPv6 routes (indirect): Up to 32,000
- Flexible NetFlow entries: Up to 512,000
- VLAN IDs: 4,094
- Jumbo frames: 9,198 bytes
- Form factor: 1 RU
- Dimensions (H x W x D): 4.39 x 44.45 x 54.66 cm
- Weight: 10.7 kg (chassis with 2 power supplies and built-in fan)
- Power supplies: Dual 1+1 redundant AC or DC
- Input voltage: 90 to 264 VAC
- Operating temperature: 0 to 40 C up to 10,000 feet
- Storage temperature: -20 to 65 C
- MTBF: 315,790 hours
- Out-of-band management: RJ-45 and USB mini type B
- Minimum software: Cisco IOS XE 16.8.1
- Licence tier: Network Essentials

FAQs

Q: Which licence does this SKU ship with?
A: It ships with the Network Essentials perpetual licence, indicated by the -E suffix. A Cisco DNA Essentials or Advantage subscription is required for the full DNA feature set, and licensing is managed through Cisco Smart Licensing.

Q: What power supplies does the C9500-16X support?
A: It supports dual 1+1 redundant supplies, the PWR-C4-950WAC-R (950W AC) and PWR-C4-950WDC-R (950W DC). A single supply must be fitted in bay 1.

Q: Which network modules work with this switch?
A: The chassis accepts the C9500-NM-8X (8 x 1/10G SFP/SFP+) and C9500-NM-2Q (2 x 40G QSFP+) network modules. This SKU is configured with the C9500-NM-2Q.

Q: How does this model differ from other C9500-16X variants?
A: This SKU pairs the Network Essentials licence tier with the 2 x 40G QSFP+ network module. Variants differ by licence tier and by the network module fitted.

Q: Can it be paired with a second switch for redundancy?
A: Yes. It supports Cisco StackWise Virtual with SSO and ISSU over a StackWise Virtual Link.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
