Cisco

Cisco C9300X-12Y-E | Catalyst 9300X 12-Port 25G SFP28 Switch, Network Essentials

C9300X-12Y-E

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9300X C9300X-12Y-E is a stackable enterprise access switch for high-density fibre access and aggregation at the campus or branch edge. It suits 25G and 10G server or uplink aggregation, secure edge connectivity with IPsec to cloud or SIG, and SD-Access or hybrid cloud-managed deployments.

It provides 12 fixed SFP28 ports that run at 25G, 10G or 1G, plus a modular uplink slot for 10G to 100G network modules. Switching capacity is 1,000 Gbps (2,000 Gbps when stacked) with a forwarding rate of 744.04 Mpps. StackWise-1T supports up to eight stack members. This SKU carries the Network Essentials licence tier and has no PoE, with a 715W AC power supply as the default.

The uplink slot accepts the C9300X-NM-8M, C9300X-NM-8Y and C9300X-NM-2C network modules. The switch stacks with other Catalyst 9300X and C9300 models at the same licence level using STACK-T1 cables, and supports SFP, SFP+ and SFP28 optics.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- StackWise-1T stacking with up to 1 Tbps of stacking bandwidth, including mixed stacking with C9300 models
- Up to 100G line-rate hardware IPsec on the UADP 2.0sec ASIC (requires an HSEC key)
- MACsec-256 and MACsec-128 link encryption, Encrypted Traffic Analytics and Trust Anchor secure boot
- App hosting with support for ThousandEyes and ASAc firewall (Advantage tier features)
- StackPower+ support for power resiliency
- Redundant power supplies and field-replaceable N+1 fans
- Cisco IOS XE with NETCONF, RESTCONF, gNMI and YANG programmability
- Flexible NetFlow, NBAR2 application visibility, PTP/AVB and SD-Access fabric foundation

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Downlink ports: 12 x 25G/10G/1G SFP28
- Uplinks: modular slot (C9300X-NM-8M, C9300X-NM-8Y, C9300X-NM-2C)
- Switching capacity: 1,000 Gbps (2,000 Gbps with stacking)
- Forwarding rate: 744.04 Mpps (1,488 Mpps with stacking)
- Stacking: StackWise-1T, up to 8 members
- Default power supply: 715W AC (PWR-C1-715WAC-P)
- PoE: none (data only)
- Memory: 16 GB DRAM, 16 GB flash
- Packet buffer: 16 MB
- MAC addresses: 32,000
- IPv4 routes: 39,000
- IPv6 routing entries: 19,500
- ACL scale entries: 8,000
- QoS scale entries: 4,000
- VLAN IDs: 4094
- Jumbo frames: 9198 bytes
- Dimensions (H x W x D), chassis only: 4.4 x 44.5 x 40.9 cm
- Weight (with default power supply): 6.80 kg
- Operating temperature: -5 to +45 C up to 1500 m
- Storage temperature: -40 to 70 C
- Relative humidity: 5% to 90% non-condensing
- MTBF: 265,650 hours

FAQs

Q: Which licence tier is the C9300X-12Y-E?
A: The -E suffix means the Network Essentials tier. A Cisco Catalyst or DNA Essentials or Advantage subscription (3, 5 or 7 years) is required at order time, and Network Essentials can pair with either subscription tier. A Cisco Smart Account is needed for Smart Licensing.

Q: Does this switch support PoE?
A: No. The C9300X-12Y-E is a data-only switch. It uses one 715W AC power supply (PWR-C1-715WAC-P), and a second supply can be added for redundancy.

Q: Which uplink modules does it accept?
A: It accepts the C9300X-NM-8M (8x 10G/mGig), C9300X-NM-8Y (8x 25G/10G/1G SFP) and C9300X-NM-2C (2x 100G/40G QSFP) network modules.

Q: Can it be stacked with other Catalyst 9300 switches?
A: Yes. It stacks with other Catalyst 9300X and C9300 models at the same licence level using STACK-T1-50CM, 1M or 3M cables. Mixed stacks with C9300 models run at StackWise-480 speeds.

Q: Does 100G IPsec need an extra licence?
A: Yes. 100G hardware IPsec on this switch requires an HSEC licence key.
