• Cisco C9300-48S-E switch with 48 SFP ports and blue LEDs
1 1

Cisco

Cisco C9300-48S-E | Catalyst 9300 48-Port 1G SFP Switch, Network Essentials

C9300-48S-E

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9300 C9300-48S-E is a stackable enterprise access switch built for campus and branch deployments where fibre downlinks are needed, such as fibre-to-the-desk or aggregation of 1G fibre links. It runs Cisco IOS XE on the UADP 2.0 ASIC and is a stackable building block for SD-Access in both 2-tier and 3-tier architectures.

The switch provides 48 x 1G SFP downlink ports and a modular uplink bay that accepts Catalyst 9300 network modules. Switching capacity is 256 Gbps, rising to 736 Gbps in a stack, with a forwarding rate of 190.47 Mpps (547.62 Mpps stacked). StackWise-480 supports up to 8 members, and StackPower allows power sharing across the stack. It carries 8 GB DRAM and 16 GB flash, and the default 715W AC power supply can be paired with a second unit for redundancy. This model has no PoE. It ships with the perpetual Network Essentials licence, covering Layer 2 and Layer 3 fundamentals, 802.1X, MACsec-128 and QoS. Switches in a stack must run the same licence level.

Uplinks use the C9300-NM-4G, C9300-NM-4M, C9300-NM-8X, C9300-NM-2Q and C9300-NM-2Y network modules. It stacks with other Catalyst 9300 SKUs at the same licence level using STACK-T1 cables.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Cisco IOS XE with model-driven programmability (NETCONF, RESTCONF, gNMI, YANG, on-box Python)
- StackWise-480 stacking and StackPower power sharing for resilience
- Dual redundant, field-replaceable power supplies and N+1 redundant fans
- Hardware-anchored Secure Boot, Trust Anchor module and image signing
- MACsec-128 link encryption and 802.1X access control
- Flexible NetFlow and NBAR2 application visibility
- Support for SD-Access, Plug and Play and zero-touch provisioning
- Container-based application hosting with external USB 3.0 SSD slot

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Ports: 48 x 1G SFP
- Uplink configuration: Modular uplinks
- Default AC power supply: 715W AC (PWR-C1-715WAC-P)
- PoE: No PoE
- Switching capacity: 256 Gbps
- Switching capacity with stacking: 736 Gbps
- Forwarding rate: 190.47 Mpps
- Forwarding rate with stacking: 547.62 Mpps
- Stacking: StackWise-480, 480 Gbps stacking bandwidth, up to 8 members
- Cisco StackPower: Supported
- MAC addresses: 32,000
- IPv4 routes: 32,000 (24,000 direct, 8,000 indirect)
- IPv6 routing entries: 16,000
- Multicast routing scale: 8,000
- QoS scale entries: 5,120
- ACL scale entries: 5,120
- Packet buffer: 16 MB
- Flexible NetFlow entries: 64,000 flows
- DRAM: 8 GB
- Flash: 16 GB
- VLAN IDs: 4094
- Jumbo frames: 9198 bytes
- Dimensions (H x W x D), chassis only: 4.3 x 44.4 x 44.9 cm
- Weight (with default power supply): 7.86 kg
- Operating temperature: -5 to +45 C up to 1500 m
- Storage temperature: -40 to 70 C
- Relative humidity: 5% to 90% non-condensing

FAQs

Q: Which licence does the C9300-48S-E use?
A: It ships with the perpetual Network Essentials licence, and a Cisco Catalyst (DNA) subscription term licence is also required at order, for example C9300-DNX-E-48S-3Y, 5Y or 7Y. Switches in a stack must have the same licence level.

Q: Does this switch provide PoE?
A: No. It has no PoE. It ships with a 715W AC power supply (PWR-C1-715WAC-P), and a second power supply can be added for redundancy.

Q: Which uplink modules does it support?
A: It uses Catalyst 9300 network modules: C9300-NM-4G, C9300-NM-4M, C9300-NM-8X, C9300-NM-2Q and C9300-NM-2Y. Catalyst 9300X network modules are not supported.

Q: What can it be stacked with?
A: It stacks with other Catalyst 9300 SKUs at the same licence level using STACK-T1-50CM, 1M or 3M cables, up to 8 members. It cannot stack with C9300L/LM models.

Q: Which IOS XE release does it need?
A: IOS XE 16.11.1a or later is required for the 1G fibre models.
