• Cisco C9300-48S-A switch with 48x 1G SFP ports and blue LEDs
1 1

Cisco

Cisco C9300-48S-A | Catalyst 9300 48-Port 1G SFP Switch, Network Advantage

C9300-48S-A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9300 48-port 1G SFP switch is a stackable enterprise access switch built for campus and branch networks that need fibre-based gigabit downlinks. It suits fibre-to-the-desk, building aggregation and SD-Access fabric edge deployments, and it is built on the UADP 2.0 ASIC running Cisco IOS XE.

The switch provides 48 x 1G SFP downlink ports and a modular uplink slot that accepts C9300 network modules from 4x1G through 8x10G, 4x mGig, 2x25G and 2x40G, so uplinks can migrate from 1G to higher speeds without replacing the chassis. Switching capacity is 256 Gbps (736 Gbps when stacked) with a forwarding rate of 190.47 Mpps. StackWise-480 supports up to eight members, and Cisco StackPower is supported. It is a data-only model with no PoE, ships with a 715W AC power supply as standard, and carries 8 GB DRAM and 16 GB flash. This SKU includes the perpetual Network Advantage feature set, adding BGP, EIGRP, IS-IS, VRF, VXLAN, LISP, MPLS and TrustSec.

It accepts C9300-NM-4G, C9300-NM-4M, C9300-NM-8X, C9300-NM-2Q and C9300-NM-2Y network modules and stacks with other modular-uplink Catalyst 9300 switches at the same licence level.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- StackWise-480 stacking gives a single management and control plane across up to 8 switches
- Cisco StackPower provides power sharing and redundancy across the stack
- Dual redundant, field-replaceable power supplies and N+1 field-replaceable fans
- Modular uplinks allow nondisruptive migration from 1G to 10G, 25G and 40G
- Cisco IOS XE with NETCONF, RESTCONF, gNMI/YANG programmability and streaming telemetry
- MACsec-256 and MACsec-128 link encryption with Encrypted Traffic Analytics and Secure Boot
- Network Advantage routing and fabric features including BGP, VRF, VXLAN, LISP and TrustSec
- Container-based application hosting with USB 3.0 SSD slot, plus SD-Access and Catalyst Center support

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Downlink ports: 48 x 1G SFP
- Uplinks: Modular, C9300 network module sold separately
- Software licence tier: Network Advantage (perpetual)
- PoE: None (data only)
- Switching capacity: 256 Gbps (736 Gbps with stacking)
- Forwarding rate: 190.47 Mpps (547.62 Mpps with stacking)
- Stacking: StackWise-480, up to 8 members
- StackPower: Supported
- Default power supply: PWR-C1-715WAC-P, 715W AC
- DRAM: 8 GB
- Flash: 16 GB
- MAC addresses: 32,000
- IPv4 routes: 32,000
- IPv6 routing entries: 16,000
- Packet buffer: 16 MB
- VLAN IDs: 4094
- Jumbo frames: 9198 bytes
- Dimensions, chassis only (H x W x D): 4.3 x 44.4 x 44.9 cm
- Weight with default power supply: 7.86 kg
- Operating temperature: -5 to +45 C up to 1500 m
- Humidity: 5% to 90% non-condensing
- MTBF: 281,920 hours

FAQs

Q: Does this switch need a separate licence?
A: It ships with the perpetual Network Advantage licence. A matching Cisco Catalyst subscription at the Advantage tier is required with new orders, using Smart Licensing through a Cisco Smart Account.

Q: Does the C9300-48S-A support PoE?
A: No. It is a data-only switch with no PoE capability. The default power supply is the 715W AC PWR-C1-715WAC-P and a second supply can be added for redundancy.

Q: Which uplink modules does it accept?
A: It accepts C9300-NM-4G, C9300-NM-4M, C9300-NM-8X, C9300-NM-2Q and C9300-NM-2Y network modules. C9300X network modules are not supported.

Q: What can it be stacked with?
A: It stacks via StackWise-480 with other modular-uplink Catalyst 9300 models at the same licence level. It cannot stack with C9300L or C9300LM fixed-uplink models.

Q: How does it differ from the C9300-48S-E?
A: Both share the same 48 x 1G SFP hardware. This -A model carries the Network Advantage feature set, which adds advanced routing and fabric features such as BGP, VXLAN, LISP and MPLS.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
