Cisco

Cisco C9300-24UXB-E | Catalyst 9300 24-Port mGig UPOE Deep Buffer Switch, Network Essentials

C9300-24UXB-E

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9300 24-port Multigigabit UPOE switch is a stackable enterprise access switch for campus and branch networks, built for high-bandwidth Wi-Fi 6/6E access points and PoE endpoints such as IP phones, cameras and IoT devices. As a higher-scale, deep-buffer model, it suits multimedia and lossless content delivery where larger tables and bigger buffers matter.

All 24 downlink ports run at 10G, 5G, 2.5G, 1G or 100M with Cisco UPOE at up to 60W per port. Uplinks are modular, so the switch can move from 1G to 10G, 25G or 40G with C9300 network modules. It provides 640 Gbps switching capacity (1120 Gbps with stacking), a 476.19 Mpps forwarding rate and a 64 MB packet buffer. The default 1100W AC Platinum power supply delivers a 560W PoE budget, rising to a maximum of 1440W with a second supply. This SKU carries the perpetual Network Essentials licence tier.

It stacks over StackWise-480 with up to 8 members and supports StackPower, but only with other C9300 higher-scale models at the same licence level. It accepts C9300 network modules and the PWR-C1 series power supplies.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Cisco UPOE at 60W per port on all 24 Multigigabit ports
- Deep buffer and higher-scale tables for multimedia and large routing environments
- Modular uplinks provide a migration path from 10G to 25G and 40G
- StackWise-480 stacking with StackPower for power redundancy
- Cisco IOS XE with NETCONF, RESTCONF, gNMI and YANG programmability and model-driven telemetry
- MACsec-128, Secure Boot and Trust Anchor security features
- Perpetual PoE and Fast PoE keep endpoints powered during a reload
- Dual redundant power supply support and N+1 field-replaceable fans

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Downlink ports: 24 x 10G/5G/2.5G/1G/100M Multigigabit copper
- PoE: Cisco UPOE, 60W per port
- Uplinks: modular, C9300 network modules
- Licence tier: Network Essentials (perpetual)
- Default power supply: PWR-C1-1100WAC-P, 1100W AC Platinum
- Available PoE budget (default PSU): 560W
- Maximum PoE budget with second PSU: 1440W
- Switching capacity: 640 Gbps
- Switching capacity with stacking: 1120 Gbps
- Forwarding rate: 476.19 Mpps
- Forwarding rate with stacking: 833.33 Mpps
- Stacking: StackWise-480, up to 8 members, StackPower support
- Packet buffer: 64 MB
- DRAM: 8 GB
- Flash: 16 GB
- MAC addresses: 64,000
- IPv4 routes: 112,000
- IPv6 routing entries: 56,000
- Flexible NetFlow entries: 256,000 flows
- VLAN IDs: 4094
- Jumbo frames: 9198 bytes
- Dimensions (chassis only): 4.4 x 44.5 x 43.4 cm
- Weight (with default PSU): 8.25 kg
- Operating temperature: -5 to +45 C up to 1500 m
- PSU input: 115 to 240 VAC, 47 to 63 Hz

FAQs

Q: Which licence does this switch use?
A: It uses the perpetual Network Essentials licence tier. A Cisco Catalyst or DNA Essentials subscription term must be ordered with a new switch and must match the network licence tier. Advanced routing such as BGP, VRF and MACsec-256 needs Network Advantage.

Q: How much PoE power is available?
A: With the default 1100W AC power supply the PoE budget is 560W. Adding a second power supply raises it to 910W with a 350W unit, 1275W with a 715W unit and 1440W with an 1100W or 1900W unit.

Q: Which network modules and power supplies does it work with?
A: It accepts C9300 network modules: C9300-NM-4G, -4M, -8X, -2Q and -2Y. C9300X modules are not supported. Compatible power supplies are PWR-C1-1100WAC-P, PWR-C1-715WAC-P, PWR-C1-350WAC-P, PWR-C1-1900WAC-P and PWR-C1-1900WHV-T.

Q: Can it be stacked with other Catalyst 9300 switches?
A: Yes, but only with other C9300 higher-scale models (C9300-24UB, C9300-24UXB, C9300-48UB) at the same licence level. It cannot be mixed with standard C9300, C9300X, C9300L or C9300LM models.

Q: How does this model differ from the standard Catalyst 9300 24-port mGig switch?
A: This is the higher-scale deep-buffer variant with a 64 MB packet buffer and larger MAC, routing and NetFlow tables. It also has modular uplinks and ships with the 1100W AC power supply.
