• Cisco Catalyst 9300-24S-E switch with 24x 1G SFP ports in silver and black
1 1

Cisco

Cisco C9300-24S-E | Catalyst 9300 24-Port SFP Switch, Network Essentials

C9300-24S-E

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9300 C9300-24S-E is a stackable enterprise access switch with 24 x 1G SFP fibre downlink ports and a modular uplink slot. It suits campus and branch access layers that need fibre to remote closets, building-to-building links or fibre-to-the-desk, and it forms a foundation for SD-Access deployments.

The switch delivers 208 Gbps of switching capacity and a 154.76 Mpps forwarding rate, rising to 688 Gbps and 511.90 Mpps in a stack. StackWise-480 provides 480 Gbps of stacking bandwidth with up to 8 members, and StackPower allows power sharing across the stack. It ships with the Network Essentials licence, which covers Layer 2, routed access with RIP, EIGRP stub and OSPF up to 1000 routes, policy-based routing, 802.1X and MACsec-128. A 715W AC power supply is the default, with a second bay for redundancy. This is a data-only model with no PoE.

Optional C9300 network modules add uplinks of 4x1G, 8x10G, 2x25G, 2x40G or 4x multigigabit. The switch stacks with other C9300 and C9300X models at the same licence level, and supports SFP, SFP+, QSFP+ and QSFP28 optics.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- StackWise-480 stacking with up to 8 members managed as a single virtual switch
- Cisco StackPower for power pooling and redundancy across the stack
- Modular uplink slot supporting 1G, 10G, 25G, 40G and multigigabit network modules
- Cisco IOS XE with NETCONF, RESTCONF, gNMI and YANG programmability plus on-box Python
- Hardware-based Flexible NetFlow and NBAR2 application recognition
- Container-based application hosting on an x86 CPU complex with optional USB 3.0 SSD
- MACsec-128, Secure Boot and Trust Anchor module
- Dual redundant power supply bays and three field-replaceable fans
- Cross-stack EtherChannel and NSF/SSO with sub-50 ms failover

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Downlink ports: 24 x 1G SFP
- Uplinks: modular, via optional C9300 network modules
- PoE: none (data-only model)
- Licence: Network Essentials
- Stacking: StackWise-480, 480 Gbps, up to 8 members
- Switching capacity: 208 Gbps (688 Gbps in a stack)
- Forwarding rate: 154.76 Mpps (511.90 Mpps in a stack)
- DRAM: 8 GB
- Flash: 16 GB
- MAC addresses: 32,000
- IPv4 routes: 32,000 (24,000 direct and 8,000 indirect)
- IPv6 routing entries: 16,000
- Multicast routing scale: 8,000
- QoS scale entries: 5,120
- ACL scale entries: 5,120
- Packet buffer: 16 MB
- Flexible NetFlow entries: 64,000 flows
- VLAN IDs: 4094
- Jumbo frames: 9198 bytes
- Default power supply: 715W AC (PWR-C1-715WAC-P), dual PSU bays
- Input voltage: 100-240 VAC, 47-63 Hz
- Power consumption at full port traffic: 119.8-126.4 W (115 VAC)
- Dimensions (H x W x D), chassis only: 4.3 x 44.4 x 44.9 cm
- Weight with default power supply: 7.64 kg
- Operating temperature: -5 to 45 C up to 1500 m
- MTBF: 284,130 hours
- Minimum software: Cisco IOS XE 16.11.1a

FAQs

Q: Does the C9300-24S-E need a software subscription?
A: The -E suffix means the Network Essentials perpetual licence is included. For new orders a matching Catalyst Essentials or Advantage term subscription is also required, for example C9300-DNX-E-24S-3Y, 5Y or 7Y. Smart Licensing is used, with a 90-day evaluation period available.

Q: Does this switch provide PoE?
A: No. This is a data-only fibre model, so it has no PoE budget. It ships with a 715W AC power supply that powers the switch itself.

Q: Which uplink modules does it support?
A: It supports the C9300 network modules C9300-NM-4G, C9300-NM-4M, C9300-NM-8X, C9300-NM-2Q and C9300-NM-2Y. C9300X modules are not compatible.

Q: What can it be stacked with?
A: It stacks with other C9300 and C9300X models at StackWise-480 speeds, provided they run the same licence level. Use STACK-T1-50CM, STACK-T1-1M or STACK-T1-3M cables. It cannot stack with C9300L, C9300LM or UB/UXB models.

Q: Which power supplies can I fit?
A: The default is PWR-C1-715WAC-P. Compatible alternatives are PWR-C1-715WDC, PWR-C1-1100WAC-P and PWR-C1-1100WAC-UP. If only one supply is fitted it must go in bay 1.
