• Cisco C9300-24S-A Catalyst 9300 switch with 24x 1G SFP ports
1 1

Cisco

Cisco C9300-24S-A | Catalyst 9300 24-Port 1G SFP Switch, Network Advantage

C9300-24S-A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9300 24-port 1G SFP switch is a stackable enterprise access switch built for campus and branch networks that need fibre connectivity at the access layer. It runs Cisco IOS XE on the UADP 2.0 ASIC and works as a stackable access switch in SD-Access fabrics, with a modular uplink slot for 1G, 10G, 25G or 40G upstream links.

This SKU provides 24 x 1G SFP downlink ports with 208 Gbps of switching capacity and a 154.76 Mpps forwarding rate, rising to 688 Gbps and 511.90 Mpps when stacked. StackWise-480 supports up to 8 members, with StackPower available for shared power. It carries 8 GB of DRAM, 16 GB of flash and 32,000 MAC addresses. It is a data-only switch with no PoE, and is fitted with a 715W AC Platinum-rated power supply with a second supply possible for redundancy. This is the Network Advantage variant, so it ships with the perpetual Network Advantage licence, adding BGP, EIGRP, IS-IS, MPLS, VRF, VXLAN, LISP and TrustSec.

The uplink slot accepts the C9300-NM-4G, C9300-NM-4M, C9300-NM-8X, C9300-NM-2Q and C9300-NM-2Y network modules. It stacks with other Catalyst 9300 SKUs at the same licence level using STACK-T1 cables.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- UADP 2.0 ASIC with programmable pipeline
- Cisco IOS XE with NETCONF, RESTCONF, gNMI, YANG programmability and streaming telemetry
- SD-Access foundation with segmentation and group-based policy
- MACsec-256 encryption, Encrypted Traffic Analytics, Secure Boot and Trust Anchor module
- Network Advantage routing and services: BGP, EIGRP, HSRP, IS-IS, MPLS, VRF, VXLAN, LISP, TrustSec and PTP
- Cross-stack EtherChannel, NSF/SSO and software patching
- Flexible NetFlow, NBAR2 application visibility and QoS with 8 egress queues per port
- Container-based application hosting with an external USB 3.0 SSD slot
- Redundant field-replaceable fans and dual power supply support

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Downlink ports: 24 x 1G SFP
- Uplinks: modular uplink slot
- Software licence: Network Advantage (perpetual)
- Switching capacity: 208 Gbps (688 Gbps with stacking)
- Forwarding rate: 154.76 Mpps (511.90 Mpps with stacking)
- Stacking: StackWise-480 (480 Gbps), up to 8 members
- StackPower: supported
- PoE: none (data only)
- Default power supply: 715W AC (PWR-C1-715WAC-P), Platinum-rated
- DRAM: 8 GB
- Flash: 16 GB
- Packet buffer: 16 MB
- MAC addresses: 32,000
- VLAN IDs: 4094
- Jumbo frames: 9198 bytes
- IPv6 routing entries: 16,000
- ACL scale entries: 5,120
- QoS scale entries: 5,120
- Flexible NetFlow: 64,000 flows
- Dimensions (H x W x D), chassis only: 4.3 x 44.4 x 44.9 cm
- Weight (with default power supply): 7.64 kg
- MTBF: 284,130 hours
- Operating temperature: -5 to 45 C up to 1500 m
- Storage temperature: -40 to 70 C
- Relative humidity: 5% to 90% non-condensing

FAQs

Q: Which licence does this SKU include?
A: The -A suffix means it ships with the perpetual Network Advantage licence. A matching Cisco Catalyst subscription licence of the same Advantage tier is required for new orders, and Smart Licensing is used.

Q: Does it support PoE?
A: No. This model is data only and has no PoE budget. It ships with a 715W AC power supply (PWR-C1-715WAC-P), and a second supply can be added for redundancy.

Q: Which uplink modules fit the modular slot?
A: It accepts the C9300-NM-4G, C9300-NM-4M, C9300-NM-8X, C9300-NM-2Q and C9300-NM-2Y network modules. C9300X network modules are not compatible.

Q: Can it be stacked with other Catalyst 9300 switches?
A: Yes, at StackWise-480 using STACK-T1-50CM, 1M or 3M cables, up to 8 members at the same licence level. Stacking with the higher-scale -UB and -UXB models is not supported.

Q: Which software release does it need?
A: 1G fibre models of the Catalyst 9300 require Cisco IOS XE 16.11.1a or later.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
