• Cisco Catalyst 9300 C9200-48T-E switch with 48x1G ports and silver finish
1 1

Cisco

Cisco C9200-48T-E | Catalyst 9200 48-Port Gigabit Switch, Network Essentials

C9200-48T-E

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9200 48-port data-only switch is a Gigabit Ethernet access switch for branch offices and campus access layers that need resilient, secure, Layer 3-capable connectivity. It ships with the Network Essentials licence tier and can be managed on-premises through Cisco Catalyst Center or from the cloud through the Meraki dashboard.

There are 48 x 10/100/1000 data ports with no PoE, so it suits workstations, printers and other powered-locally endpoints. A modular uplink slot accepts C9200-NM-4G or C9200-NM-4X network modules for 1G or 10G uplinks. Switching capacity is 176 Gbps, or 336 Gbps when stacked, with a forwarding rate of 130.95 Mpps. Optional StackWise-160 stacking provides up to 160 Gbps between as many as 8 members. The default PWR-C6-125WAC power supply is field-replaceable, with redundant field-replaceable fans.

Stacking requires the C9200-STACK-KIT and only works with other C9200 models at the same licence level. It runs Cisco IOS XE and supports SD-Access fabric edge deployments with 4 virtual networks.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Layer 3 capabilities including OSPF, EIGRP, IS-IS, RIP and routed access
- AES-128 MACsec encryption, policy-based segmentation and Secure Boot with image signing
- Cisco IOS XE with NETCONF, RESTCONF and YANG programmability and streaming telemetry
- Cisco SD-Access support with 4 virtual networks
- Plug and Play and Cisco Catalyst Center management
- Cloud monitoring and management through the Meraki dashboard
- Field-replaceable power supplies, fans and uplink modules
- Flexible NetFlow, QoS and eight egress queues per port

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Downlink ports: 48 x 10/100/1000 data ports (no PoE)
- Uplinks: modular uplink slot for C9200-NM-4G and C9200-NM-4X network modules
- Switching capacity: 176 Gbps (336 Gbps with stacking)
- Forwarding rate: 130.95 Mpps (250 Mpps with stacking)
- Stacking: StackWise-160, up to 160 Gbps, up to 8 members
- Licence tier: Network Essentials
- Default power supply: PWR-C6-125WAC
- Fans: field-replaceable, redundant
- MAC addresses: 32,000
- VLAN IDs: 4,094
- DRAM: 4 GB
- Flash: 4 GB
- Packet buffer: 6 MB
- Jumbo frames: 9198 bytes
- Dimensions (H x W x D): 4.4 x 44.5 x 35.0 cm
- Weight: 5.0 kg
- Operating temperature: -5 to 45 C up to 1500 m
- Input voltage: 100-240 VAC, 50-60 Hz
- MTBF: 571,440 hours

FAQs

Q: Does this switch need a licence?
A: It ships with the Network Essentials licence tier, which covers foundational Layer 2 and Layer 3 switching, automation, visibility and security. Cisco DNA subscriptions and an upgrade to Network Advantage are optional.

Q: Does it provide PoE?
A: No. This is a data-only model with no PoE budget, so powered devices need their own power source or a separate PoE injector.

Q: Which uplink modules does it use?
A: It has a modular uplink slot that accepts the C9200-NM-4G and C9200-NM-4X network modules. The C9200-NM-2Y and C9200-NM-2Q modules are not supported on this model.

Q: Can it be stacked with other switches?
A: Yes, with the C9200-STACK-KIT and STACK-T4 stacking cables. It stacks only with other Catalyst 9200 models at the same licence level, up to 8 members.

Q: Can I claim it on my Meraki dashboard?
A: Yes. Every Meraki device XS Network Tech supplies can be claimed on your Meraki dashboard.
