• Cisco APIC-CLUSTER-M4 medium tier cluster server with slots and buttons
1 1

Cisco

Cisco APIC-CLUSTER-M4 | ACI APIC Controller Cluster, Medium M4, 3 Nodes

APIC-CLUSTER-M4

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The APIC-CLUSTER-M4 is a bundle of three APIC-M4 medium-size controller appliances from the Cisco Application Policy Infrastructure Controller range. Together they form the minimum cluster needed to manage and automate a Cisco ACI fabric, and this medium configuration is built for small-to-medium data centre fabrics of up to 1200 edge ports.

Each APIC-M4 node is a 1RU rack server with one AMD 7313P 3.0GHz 16-core CPU, six 16GB DDR4-3200 RDIMMs and a pair of enterprise SATA SSDs (480GB and 960GB). Each node has a single power supply, 1050W (AC and DC) or 1600W, with eight hot-swappable fans and front-to-rear airflow. PCIe slots can be fitted with an Intel E810XXVDA2 2x25/10GbE SFP28 or Intel X710T2LG 2x10GbE RJ45 NIC.

The cluster manages ACI fabrics built on Cisco Nexus 9000 Series spine and leaf switches in ACI mode, and can coexist with virtual APICs in hybrid clusters. Fabrics larger than 1200 edge ports need the APIC-CLUSTER-L4.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Single point of automation, management, policy enforcement and health monitoring for the Cisco ACI fabric
- Clustered controller design that unifies physical and virtual environments
- Application-centric network policies with data-model-based declarative provisioning
- Application and topology monitoring and troubleshooting
- L4-L7 services integration
- Integrations with VMware vCenter and vShield, Nutanix, OpenShift, Terraform, Ansible, Chef, Puppet, Python and ServiceNow
- Image management for spine and leaf switches
- Any controller can service any user for any operation, and controllers can be added or removed transparently

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: APIC-CLUSTER-M4
- Configuration: Cluster of 3 x APIC-M4 appliances
- Scale: up to 1200 edge ports
- Processor per node: 1 x AMD 7313P 3.0GHz 155W 16-core, 128MB cache, DDR4 3200MHz
- Memory per node: 6 x 16GB DDR4-3200 RDIMM
- Storage per node: 480GB and 960GB 2.5in Enterprise Performance 6G SATA SSD (3X endurance)
- PCIe NIC options per node: Intel E810XXVDA2 2x25/10GbE SFP28 or Intel X710T2LG 2x10GbE RJ45
- Power supply per node: 1 x 1050W (AC and DC) or 1600W
- Cooling: 8 hot-swappable fans, front-to-rear airflow
- Form factor: 1RU rack mount
- Dimensions per node (H x W x D): 43.2 mm x 429.0 mm x 740.3 mm (server only)
- Operating temperature: 10 to 35 C (50 to 95 F), no direct sunlight
- Non-operating temperature: below -40 C or above 65 C
- Operating humidity: 8 to 90% RH, non-condensing
- Operating altitude: 0 to 10,000 ft
- Non-operating altitude: 0 to 40,000 ft
- Minimum cluster size: three controllers

FAQs

Q: How many controllers are in this cluster?
A: The APIC-CLUSTER-M4 is a cluster of three APIC-M4 appliances, which is the minimum cluster size for an ACI fabric.

Q: What fabric size does the medium configuration support?
A: It supports ACI fabrics of up to 1200 edge ports. Larger fabrics need the APIC-CLUSTER-L4.

Q: What power supply does each node use?
A: Each APIC-M4 node has one power supply, either 1050W (AC and DC) or 1600W.

Q: Which switches does it manage?
A: It manages Cisco ACI fabrics built on Cisco Nexus 9000 Series spine and leaf switches running in ACI mode.

Q: Which network card options are available?
A: Each node can be configured with an Intel E810XXVDA2 2x25/10GbE SFP28 NIC or an Intel X710T2LG 2x10GbE RJ45 NIC.
