• Aruba R8Q69A switch in black rack with green cables on white tiles
1 1

Aruba

Aruba R8Q69A | CX 6200M 48-Port Gigabit Switch, 4x 10G SFP+, Modular

R8Q69A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Aruba CX 6200M is a stackable Layer 3 access switch built for the enterprise campus and branch access layer, as well as SMB networks. It provides edge connectivity for users, wireless access points, IoT devices and servers, with 10G uplinks for aggregation. It runs AOS-CX with built-in analytics.

This modular model has 48 10/100/1000BASE-T ports and 4 x 1G/10G SFP+ uplink ports, two of which are LRM and two of which are LRM with MACsec 256. Switching capacity is 176 Gbps, with a forwarding rate of up to 130.9 Mpps. It does not provide PoE. Power is modular, with two hot-swappable PSU slots, and at least one PSU is required and ordered separately. The 48-port non-PoE configuration with 1/10G SFP+ uplinks is what sets this SKU apart from other CX 6200M variants.

VSF stacking joins up to 8 members, with other 24- and 48-port CX 6200F and 6200M switches, for up to 384 ports and 40 Gbps of stacking bandwidth. The switch supports PSU JL085A and is a 1U rack-mountable unit.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Aruba Gen7 ASIC architecture for non-blocking, low-latency performance
- Layer 3 connectivity with ACLs, robust QoS, and static and access OSPF routing
- VSF stacking of up to 8 members, up to 384 ports across 24- and 48-port fixed and modular models
- Aruba Network Analytics Engine (NAE) for intelligent monitoring and visibility
- Dynamic segmentation with automated device profiling and role-based access control
- VXLAN switch-to-switch tunnels for low-latency, high-performance use cases
- Hot-swappable power supplies and fan trays
- Management via Aruba Central, web GUI, REST APIs, CLI and the CX Mobile app

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 48 x 10/100/1000BASE-T
- Uplink ports: 4 x 1G/10G SFP+ (2x LRM, 2x LRM/MACsec 256)
- PoE: Not supported
- Switching capacity: 176 Gbps
- Forwarding rate: Up to 130.9 Mpps
- Latency: 2.28 us (1 Gbps), 1.46 us (10 Gbps)
- MAC address table: 16,000 entries
- CPU: Quad-core ARM Cortex-A72 at 1.8 GHz
- Stacking: VSF, up to 8 members
- Stacking bandwidth: 40 Gbps
- Console: 1x RJ-45 console port, 1x USB-C console port
- Management ports: 1x OOBM port, 1x USB Type-A host port
- Power supply slots: 2 hot-swappable, 1 PSU required, supports JL085A
- Fan trays: 2 slots, field-replaceable and hot-swappable
- Form factor: 1U rack-mountable

FAQs

Q: Does this switch need a software licence?
A: It runs AOS-CX and no separate software licence is required for operation. Aruba Central cloud management is optional and uses its own subscription.

Q: Does this switch provide PoE?
A: No. This is a non-PoE model, so PoE devices such as access points or phones need a separate PoE source.

Q: What power supply does it use?
A: It has two hot-swappable PSU slots and at least one PSU is required. The supported power supply is the Aruba JL085A.

Q: How many switches can be stacked together?
A: VSF stacking supports up to 8 members, including other 24- and 48-port CX 6200F and 6200M switches, with 40 Gbps of stacking bandwidth.

Q: What speeds do the SFP+ uplinks support?
A: The four SFP+ ports accept 1G and 10G optics. Two of them are LRM ports and the other two are LRM ports that also support MACsec 256.
