• Aruba R0X27A CX 6410 chassis with PoE and modular ports
1 1

Aruba

Aruba R0X27A | CX 6410 10-Slot Modular Switch Chassis, Mgmt Module, 4 Fans

R0X27A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Aruba CX 6410 is a 10-slot modular Layer 3 chassis switch from the CX 6400 series, aimed at enterprise campus access and aggregation, high-density PoE and multi-gigabit access for Wi-Fi access points and IoT devices, and data centre deployments that need VSX high availability. It is built on Gen7 ASICs with a fully distributed, wire-speed design.

This SKU is the 10-slot chassis bundle: the 6410 chassis (R0X25A), one R0X31A management module and four R0X32A fan trays. It offers 28 Tbps of switching capacity and 11.4 Bpps of throughput, with 2.8 Tb of non-blocking fabric per slot. Line cards provide 1/2.5/5GbE Smart Rate, 10GbE, 25GbE, 40GbE and 100GbE interfaces, and PoE line cards deliver IEEE 802.3af/at/bt power up to 60W per port. Up to four modular power supplies can be fitted, and the PoE budget depends on the line cards and power supplies installed. AOS-CX native features need no separate licence.

Supported line cards are R0X38B, R0X39B, R0X40B, R0X41A, R0X42A, R0X43A, R0X44A, R0X45A, R0X44C and R0X45C. Power supplies R0X35A (1800W) and R0X36A (3000W) are compatible.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Gen7 ASIC architecture with a fully distributed design and wire-speed switching and routing
- Virtual Switching Extension (VSX) for high availability and non-disruptive upgrades
- Layer 3 features including BGP, MPLS, EVPN, VXLAN, VRF and OSPF
- Full-density Smart Rate multi-gigabit 1/2.5/5GbE with 60W PoE on PoE line cards
- Network Analytics Engine for monitoring and remediation
- Dynamic segmentation for wired and wireless role-based policy
- Management via Aruba Central or HPE Mist
- Redundant power supplies and fans

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form factor: 10-slot modular chassis
- Chassis: 1x 6410 Chassis (R0X25A)
- Management module: 1x R0X31A
- Fan trays: 4x R0X32A, field replaceable
- Open module slots: 10
- Switching capacity: 28 Tbps
- Throughput: 11.4 Bpps
- Fabric: non-blocking 2.8 Tb per slot
- Line-card interfaces: 1/2.5/5GbE Smart Rate, 10GbE, 25GbE, 40GbE, 100GbE
- PoE standards: IEEE 802.3af, 802.3at, 802.3bt (up to 60W) with PoE line cards
- Power supplies: up to 4 modular front-serviceable PSUs (R0X35A 1800W, R0X36A 3000W)
- Console ports: 1x RJ-45, 1x USB-C
- Other ports: 1x OOBM, 1x USB Type A host
- Management module CPU: Quad Core ARM Cortex A72 @ 1.8GHz
- Management module memory: 16GB DDR4 ECC, 32GB eMMC
- Line card memory: 4GB DDR4
- Switched virtual interfaces (dual stack): 2,048
- MAC table capacity: 32,768
- IPv4 / IPv6 unicast routes: 61,000 each
- Dimensions (W x D x H): 44.26 x 44.85 x 52.88 cm
- Weight: 53.5 kg
- Operating temperature: 0 to 45 C up to 5,000 ft; 0 to 40 C at 5,001-10,000 ft
- Operating humidity: 15% to 95% RH at 45 C, non-condensing

FAQs

Q: Does this switch need a licence?
A: It runs AOS-CX, whose native features need no separate licence. An optional term-based CX Advanced Feature Pack adds extra visibility and security use cases. Aruba Central management needs a separate Foundation or Advanced subscription.

Q: Which power supplies does it use?
A: It takes up to four modular power supplies: the R0X35A 1800W with a C16 inlet or the R0X36A 3000W with a C20 inlet. The PoE budget depends on the line cards, fan trays and power supplies installed.

Q: Which line cards are compatible?
A: Compatible line cards are R0X38B, R0X39B, R0X40B, R0X41A, R0X42A, R0X43A, R0X44A, R0X45A, R0X44C and R0X45C.

Q: How does this SKU differ from other 6410 options?
A: This SKU is the 10-slot chassis bundle of the 6410 chassis, one management module and four fan trays, with no power supplies or line cards.

Q: Can it provide PoE to access points and IoT devices?
A: Yes, with PoE line cards. They support IEEE 802.3af, 802.3at and 802.3bt, delivering up to 60W per port.
