Aruba

Aruba JL263A | 2930F 24-Port PoE+ Switch, 370W, 4x 10G SFP+, TAA

JL263A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Aruba 2930F is a fixed-port Layer 3 managed access switch for enterprise campus, SMB and branch networks. This TAA-compliant model provides 24 Gigabit PoE+ ports for powering wireless access points, IP phones and cameras, with 10GbE SFP+ uplinks back to the core.

It offers 24 autosensing 10/100/1000 RJ-45 PoE+ ports (IEEE 802.3at, up to 30 W per port) sharing a 370 W PoE budget, plus 4 SFP+ 1/10GbE uplink ports. The switch has 1 GB of DDR3 memory, 4 GB of flash and a 12.38 MB packet buffer. Static, RIP and Access OSPF routing are included with no software licence required, and the routing table holds 10,000 IPv4 and 5,000 IPv6 entries.

The SFP+ ports accept 1G SFP and 10G SFP+ transceivers. The switch is managed locally or through Aruba Central, AirWave, IMC and ClearPass, and supports VSF stacking. It is a 1U rack-mount unit with an internal AC power supply.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Layer 3 switching with VSF stacking support
- Static, RIP and Access OSPF routing with no software licence required
- IEEE 802.3at PoE+ delivering up to 30 W per port
- Zero Touch Provisioning and cloud-based management with Aruba Central
- Supported by Aruba ClearPass Policy Manager and AirWave
- Out-of-band management via serial console port
- REST APIs and OpenFlow support
- RMON and sFlow monitoring
- Traffic prioritisation (802.1p) with 8 queues and robust QoS

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Downlink ports: 24 x 10/100/1000 RJ-45 autosensing PoE+ (IEEE 802.3at)
- Uplink ports: 4 x SFP+ 1/10GbE (PHY-less)
- PoE budget: 370 W PoE+, up to 30 W per port
- Console port: 1 dual-personality (RJ-45 or USB micro-B) serial console
- Processor: Dual Core ARM Cortex A9 @ 1016 MHz
- Memory: 1 GB DDR3 SDRAM
- Flash: 4 GB eMMC
- Packet buffer: 12.38 MB (4.5 MB ingress / 7.875 MB egress)
- Latency (1000 Mb): less than 3.8 µs (64-byte packets)
- Routing table size: 10000 entries (IPv4), 5000 entries (IPv6)
- MAC address table size: 32768 entries
- Input voltage: 100-127 / 200-240 VAC, 50/60 Hz
- Maximum power rating: 445 W
- Idle power: 36.8 W
- Maximum heat dissipation: 258 BTU/hr
- Dimensions (W x D x H): 44.25 x 30.42 x 4.39 cm, 1U
- Weight: 3.9 kg
- Operating temperature: 0 to 45 C (up to 1524 m)
- Operating relative humidity: 15% to 95%, non-condensing
- Storage temperature: -40 to 70 C
- Compliance: TAA-compliant

FAQs

Q: Does the JL263A need a software licence for Layer 3 routing?
A: No. Static routing, RIP and Access OSPF are included in the base feature set with no software licence required. Aruba Central cloud management is optional and needs a separate subscription.

Q: How much PoE power does it provide?
A: It provides a 370 W PoE+ budget across its 24 ports, with up to 30 W per port under IEEE 802.3at. Maximum power draw of the switch is 445 W.

Q: Which transceivers fit the SFP+ uplink ports?
A: The 4 SFP+ ports take 1G SFP and 10G SFP+ transceivers, giving a choice of 1GbE or 10GbE uplinks.

Q: Can this switch be stacked?
A: Yes. It supports VSF stacking, which allows several switches to be combined and managed as a single virtual device.

Q: How does the JL263A differ from the non-TAA 2930F 24G PoE+ model?
A: It is the TAA-compliant version of the 2930F 24G PoE+ 4SFP+ switch, with the same 24 PoE+ ports, 370 W budget and 4 SFP+ uplinks.
