• Aruba J9778A 48-port PoE+ L2 managed switch with SFP uplinks
1 1

Aruba

Aruba J9778A | 2530 48-Port 10/100 PoE+ Switch, 382W, 2x SFP

J9778A

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Aruba 2530 48 PoE+ is a fully managed Layer 2 access switch from the Aruba 2530 Switch Series. It suits enterprise edge, branch office and SMB access-layer deployments that need PoE+ power for IP phones, video cameras and wireless access points.

It provides 48 autosensing 10/100 PoE+ (IEEE 802.3at) RJ-45 ports with a 382 W total PoE budget. Uplinks are two autosensing 10/100/1000 RJ-45 ports and two fixed Gigabit SFP ports. Switching capacity is 17.6 Gbps with throughput of up to 13 Mpps, backed by 256 MB DDR3 memory and 128 MB flash. The switch runs without a subscription, as its software features are included with the hardware.

It mounts in a 19-inch rack at 1U, or on a wall or horizontal surface, and supports virtual stacking of up to 16 switches. It can be managed through Aruba Central, AirWave or ClearPass Policy Manager, as well as the web interface, CLI and SNMP.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Fully managed Layer 2 switching with PoE+ on all 48 access ports
- Local MAC, 802.1X and MAC/Web authentication
- DoS protection including DHCP Protection, Dynamic ARP Protection and Dynamic IP Lockdown
- ACLs and QoS with IEEE 802.1p prioritisation across eight priority levels
- Energy Efficient Ethernet (IEEE 802.3az), LED disable and port low-power mode
- Zero touch provisioning (ZTP)
- Management through Aruba Central, AirWave, IMC, web GUI, CLI and SNMP
- RMON and sFlow monitoring and reporting

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 48 x RJ-45 10/100 PoE+ (IEEE 802.3at), Auto-MDIX, half or full duplex
- Uplink ports: 2 x autosensing 10/100/1000 RJ-45
- SFP ports: 2 x fixed Gigabit Ethernet SFP
- Console port: 1 dual-personality serial (RJ-45 or USB micro-B)
- PoE budget: 382 W total across all PoE ports
- Switching capacity: 17.6 Gbps
- Throughput: up to 13 Mpps (64-byte packets)
- Processor: ARM9E at 800 MHz
- Memory: 256 MB DDR3 DIMM, 128 MB flash
- Packet buffer: 3 MB dynamically allocated
- MAC address table: 16000 entries
- Latency: under 6.6 µs at 100 Mb, under 2.2 µs at 1000 Mb (64-byte packets)
- Stacking: virtual stacking, up to 16 switches
- Power input: 100-127 / 200-240 VAC, 50/60 Hz
- Maximum power: 441 W, idle power 37.5 W
- Dimensions (W x D x H): 44.2 x 32.26 x 4.45 cm, 1U
- Weight: 4.58 kg
- Operating temperature: 0 to 45 °C
- Operating humidity: 15% to 95% at 40 °C, non-condensing
- Mounting: 19-inch rack, horizontal surface or wall
- IPv6: IPv6 Ready Certified

FAQs

Q: Does the J9778A need a licence or subscription?
A: No. Switch software features are included with the hardware and there are no separate licence tiers. Optional management platforms such as Aruba Central, AirWave and ClearPass are separate.

Q: How much PoE power does it provide?
A: It has a 382 W total PoE+ (IEEE 802.3at) budget shared across the 48 PoE ports. The budget is the total available, so it is not 30 W on every port at the same time.

Q: Which SFP modules work in the fixed SFP ports?
A: SFPs used in the two fixed Gigabit SFP ports must be revision B or later, for example J4858B or J4859C.

Q: Can it be stacked?
A: Yes. It supports virtual stacking of up to 16 switches so a group can be managed as one unit.

Q: What management options are available?
A: You can manage it through Aruba Central, AirWave, IMC, the web interface, the CLI or SNMP, with a serial console over RJ-45 or micro USB. It also integrates with ClearPass Policy Manager.
