Vendor:Arista
Arista QSFP-100G-SR4-E | 100G QSFP28 Transceiver, 850nm, 30m MMF, MPO
QSFP-100G-SR4-E
Vendor:AristaArista QSFP-100G-SR4-E | 100G QSFP28 Transceiver, 850nm, 30m MMF, MPO
The Arista QSFP-100G-SR4-E is a 100GBASE-SL4 enhanced QSFP28 optical transceiver designed for ultra-low latency applications in data centers and high-performance computing environments. Operating at 850nm wavelength over multimode fiber, it delivers 100 Gigabit Ethernet connectivity up to 30m over OM4 MMF via an MPO-12 connector. This enhanced variant operates without FEC for minimal latency, making it ideal for demanding financial trading, HPC clusters, and latency-sensitive workloads. -
Vendor:Arista
Arista QSFP-100G-SR4-E-Arista | 100G SR4 Transceiver, 850nm, 100m OM4, MPO, Extended Temp
QSFP-100G-SR4-E-Arista
Vendor:AristaArista QSFP-100G-SR4-E-Arista | 100G SR4 Transceiver, 850nm, 100m OM4, MPO, Extended Temp
The Arista QSFP-100G-SR4-E is a 100GBASE-SR4 QSFP28 optical transceiver designed for extended temperature operation in data center and enterprise network environments. Supporting 100 Gigabit Ethernet over multimode fiber, this module delivers up to 70m over OM3 or 100m over OM4 fiber using 850nm wavelength via an MPO-12 connector. With four independent 25 Gbps channels, Digital Diagnostic Monitoring capability, and enhanced environmental specifications, this transceiver is ideal for demanding high-bandwidth applications including data center interconnects, cloud infrastructure, and high-performance computing clusters. -
Vendor:Arista
Arista QSFP-100G-SRBD | 100G QSFP28 | 100GBASE-SR BD (BiDi) | 850/910 nm | Duplex MMF LC | OM3 70m / OM4 100m
QSFP-100G-SRBD
Vendor:AristaArista QSFP-100G-SRBD | 100G QSFP28 | 100GBASE-SR BD (BiDi) | 850/910 nm | Duplex MMF LC | OM3 70m / OM4 100m
100G QSFP28 SR BD (BiDi) transceiver that delivers full‑rate 100G over a single LC‑duplex multimode pair using two counter‑propagating wavelengths per fiber. Achieve up to 70 m on OM3 and 100 m on OM4 without MPO cabling. -
Vendor:Arista
Arista QSFP-100G-SRBD-Arista | 100G BiDi Transceiver, 850nm, 100m OM4, Duplex LC
QSFP-100G-SRBD-Arista
Vendor:AristaArista QSFP-100G-SRBD-Arista | 100G BiDi Transceiver, 850nm, 100m OM4, Duplex LC
The Arista QSFP-100G-SRBD is a 100GBASE-BiDi QSFP28 transceiver designed for short-reach data center and enterprise applications. It delivers 100 Gbps bandwidth over standard duplex multimode fiber, with each optical port containing both transmitter and receiver operating at full duplex 50 Gbps per fiber. Ideal for migrations from legacy 10G/40G duplex infrastructure and interoperability with 400G BiDi platforms when deployed in breakout configurations. -
Vendor:Arista
Arista QSFP-100G-SWDM4 | 100G QSFP28 | 100GBASE-SWDM4 | 850–940 nm | Duplex MMF LC | OM3 70m / OM4 100m
QSFP-100G-SWDM4
Vendor:AristaArista QSFP-100G-SWDM4 | 100G QSFP28 | 100GBASE-SWDM4 | 850–940 nm | Duplex MMF LC | OM3 70m / OM4 100m
100G QSFP28 SWDM4 transceiver that carries four wavelengths across a single duplex LC multimode pair—ideal for upgrading existing LC MMF runs to 100G without MPO cabling. Reach up to 70 m on OM3 and 100 m on OM4 with simple LC infrastructure. -
Vendor:Arista
Arista QSFP-100G-SWDM4-Arista | 100G QSFP28 Transceiver, Multi-Mode, 850-940nm, 100m, LC
QSFP-100G-SWDM4-Arista
Vendor:AristaArista QSFP-100G-SWDM4-Arista | 100G QSFP28 Transceiver, Multi-Mode, 850-940nm, 100m, LC
The Arista QSFP-100G-SWDM4 is a 100G QSFP28 transceiver designed for high-speed data center interconnects over duplex multimode fiber. Using Short Wavelength Division Multiplexing (SWDM4) technology, it transmits four channels at 25 Gbps each across 850, 880, 910, and 940nm wavelengths, supporting link distances up to 70m on OM3 fiber or 100m on OM4 fiber. This hot-pluggable optical module is ideal for upgrading from 10G/40G to 100G Ethernet using existing duplex fiber infrastructure, eliminating the need for costly parallel fiber deployments. -
Vendor:Arista
Arista QSFP-100G-XCWDM4 | 100G QSFP28 | CWDM4 (XCWDM4) 4×25G | 1271–1331 nm | 10 km SMF | LC duplex
QSFP-100G-XCWDM4
Vendor:AristaArista QSFP-100G-XCWDM4 | 100G QSFP28 | CWDM4 (XCWDM4) 4×25G | 1271–1331 nm | 10 km SMF | LC duplex
100G CWDM4 QSFP28 optical transceiver for up to 10 km over duplex single-mode fiber using four CWDM wavelengths. Low power, high-density 100GbE for leaf–spine, campus, and metro edge. -
Vendor:Arista
Arista QSFP-100G-XCWDM4-Arista | 100G QSFP28 Transceiver, CWDM4, 10km, LC, SMF
QSFP-100G-XCWDM4-Arista
Vendor:AristaArista QSFP-100G-XCWDM4-Arista | 100G QSFP28 Transceiver, CWDM4, 10km, LC, SMF
The Arista QSFP-100G-XCWDM4 is a 100G QSFP28 optical transceiver designed for extended-reach single-mode fiber deployments up to 10 km. Using four CWDM wavelengths (1271, 1291, 1311, 1331 nm) multiplexed over a single duplex LC fiber pair, it delivers cost-effective 100GbE connectivity for data center interconnect, metro edge, and campus backbone applications. Hot-swappable, low-power design with digital diagnostics monitoring. -
Vendor:Arista
Arista QSFP-100G-XSR4 | 100G QSFP28 | 100GBASE-XSR4 | 850 nm | Parallel MMF MPO-12 | OM3 150m / OM4 300m
QSFP-100G-XSR4
Vendor:AristaArista QSFP-100G-XSR4 | 100G QSFP28 | 100GBASE-XSR4 | 850 nm | Parallel MMF MPO-12 | OM3 150m / OM4 300m
High‑density 100G QSFP28 extended‑SR (XSR4) transceiver for parallel multimode fiber. Delivers four 25G lanes over MPO‑12 with extended reach versus SR4: up to 150 m on OM3 and 300 m on OM4. Ideal for short‑to‑mid fabric links in spine/leaf and aggregation where parallel MMF cabling is available. -
Vendor:Arista
Arista QSFP-100G-XSR4-Arista | 100G QSFP28 Transceiver, Multi-Mode, 850nm, 300m, MPO-12
QSFP-100G-XSR4-Arista
Vendor:AristaArista QSFP-100G-XSR4-Arista | 100G QSFP28 Transceiver, Multi-Mode, 850nm, 300m, MPO-12
The Arista QSFP-100G-XSR4 is a 100GBASE-XSR4 QSFP28 optical transceiver designed for high-speed data center connectivity. It delivers 100Gbps throughput up to 300m over OM4 multi-mode fiber using an 850nm wavelength via an MPO-12 connector. This hot-swappable module supports breakout to 4x 25GBASE-SR applications and is ideal for enterprise networks, high-performance computing, and data center interconnects. -
Vendor:Arista
Arista QSFP-100G-ZR4-Arista | 100G QSFP28 Transceiver, Single-Mode, 80km, LC
QSFP-100G-ZR4-Arista
Vendor:AristaArista QSFP-100G-ZR4-Arista | 100G QSFP28 Transceiver, Single-Mode, 80km, LC
The Arista QSFP-100G-ZR4 is a high-performance 100GBase-ZR4 QSFP28 optical transceiver designed for long-reach data center interconnect and metro applications. Supporting link distances up to 80km over single-mode fiber, this module uses four LAN WDM wavelengths (1295nm to 1309nm) delivered via a duplex LC connector. Built to QSFP28 MSA standards and featuring digital diagnostics monitoring, it provides reliable 100 Gigabit Ethernet connectivity for demanding enterprise and service provider networks. -
Vendor:Arista
Arista QSFP-100G-ZR42 | 100G Transceiver, 80km Single-Mode, 1310nm, LC
QSFP-100G-ZR42
Vendor:AristaArista QSFP-100G-ZR42 | 100G Transceiver, 80km Single-Mode, 1310nm, LC
The Arista QSFP-100G-ZR42 is a 100GBASE-ZR4 QSFP28 optical transceiver engineered for long-reach data center interconnects and metro network applications. Supporting link distances up to 80km over OS2 single-mode fiber with duplex LC connectors, this module uses four wavelengths in the 1295-1309nm range with 4x25G electrical lanes. Ideal for connecting distributed data centers, enterprise campus cores, and service provider metro networks requiring high-bandwidth, extended-reach connectivity. -
Vendor:Arista
Arista QSFP-200G-FR4 | 200G QSFP56 Transceiver, Single-Mode, 2km, LC
The Arista QSFP-200G-FR4 is a high-performance 200GBASE-FR4 QSFP56 transceiver designed for 200 Gigabit Ethernet applications over single-mode fiber. Supporting transmission distances up to 2km with duplex LC connectors, this module uses PAM4 modulation across four CWDM wavelengths for efficient bandwidth utilization. Ideal for data center interconnects, cloud networks, and enterprise campus core applications requiring high-speed, low-latency connectivity. -
Vendor:Arista
Arista QSFP-200G-FR4-Arista | 200G QSFP56 Transceiver, Single-Mode, 2km, Duplex LC
QSFP-200G-FR4-Arista
Vendor:AristaArista QSFP-200G-FR4-Arista | 200G QSFP56 Transceiver, Single-Mode, 2km, Duplex LC
The Arista QSFP-200G-FR4 is a 200GBASE-FR4 QSFP56 optical transceiver designed for data center and enterprise networks requiring high-bandwidth connectivity up to 2km over single-mode fiber. This dual-rate module supports both 200G and 100G operation with PAM4 modulation, enabling seamless migration from 100G infrastructure. Featuring duplex LC connectors and DDM support, it delivers reliable performance for spine-leaf architectures and cloud network deployments. -
Vendor:Arista
Arista QSFP-200G-SR4 | 200G QSFP56 Transceiver, 850nm, 100m MMF, MPO-12
QSFP-200G-SR4
Vendor:AristaArista QSFP-200G-SR4 | 200G QSFP56 Transceiver, 850nm, 100m MMF, MPO-12
The Arista QSFP-200G-SR4 is a 200GBASE-SR4 QSFP56 optical transceiver designed for high-speed data center and enterprise network connectivity. It delivers 200 Gigabit Ethernet throughput over multi-mode fiber up to 100 meters on OM4 or 70 meters on OM3, using an MPO-12 connector and 850nm wavelength. This hot-swappable module features digital optical monitoring and is compliant with IEEE 802.3bs and QSFP56 MSA standards, making it ideal for spine-leaf architectures, high-performance computing, and scalable cloud infrastructure. -
Vendor:Arista
Arista QSFP-200G-SR4-Arista | 200G SR4 QSFP56 Transceiver, 850nm, 100m MMF, MPO-12
QSFP-200G-SR4-Arista
Vendor:AristaArista QSFP-200G-SR4-Arista | 200G SR4 QSFP56 Transceiver, 850nm, 100m MMF, MPO-12
The Arista QSFP-200G-SR4 is a 200GBASE-SR4 QSFP56 optical transceiver designed for high-speed data center connectivity. It delivers 200 Gigabit Ethernet over multimode fiber using PAM4 modulation at 850nm wavelength, reaching up to 100 meters on OM4 fiber via MPO-12 connector. Compliant with IEEE 802.3bs and SFF-8665 standards, it features digital optical monitoring (DOM) and hot-swappable design for enterprise core, distribution, and high-performance computing networks.
