Meraki

Meraki MS150-24T-4G | MS150 24-Port Gigabit Switch, 4x 1G SFP

SKU:MS150-24T-4G

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Meraki MS150-24T-4G is a cloud-managed Layer 2 stackable access switch designed for branch and campus deployments. With 24 Gigabit Ethernet ports, 4x 1G SFP uplinks, and 56 Gbps switching capacity, it delivers reliable connectivity for data-only environments. Stack up to 8 switches with 80 Gbps total bandwidth to scale your network, while centralized cloud management simplifies deployment and ongoing operations.

Features

Cloud-managed architecture with zero-touch provisioning and automatic firmware updates
- Layer 2 switching with static routing capabilities
- Stacking support for up to 8 switches with 80 Gbps aggregate backplane bandwidth
- Non-blocking switch fabric for maximum throughput
- Advanced security features: DHCP snooping, Dynamic ARP Inspection (DAI), Broadcast Storm Control
- ACL support for granular traffic control and security policies
- VLAN tagging and 802.1Q support for network segmentation
- Adaptive Policy ready with Advanced license for identity-based segmentation
- Network-wide visibility and control through centralized Meraki Dashboard
- Remote troubleshooting tools and real-time monitoring
- Seamless firmware updates with no downtime
- Integrated rack mount kit for easy installation

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Technical Specifications

24x 10/100/1000Base-T RJ45 ports (data only, non-PoE)
- 4x 1G SFP uplink ports
- Switching capacity: 56 Gbps
- Layer 2 switching with static routing
- Stacking: Up to 8 switches via 2 dedicated stacking ports with 80 Gbps aggregate bandwidth
- Power input: 12VDC, 2.5A (32.4W maximum)
- Management: Cloud-managed via Meraki Dashboard, SNMP, Syslog
- 1x dedicated management interface
- MTBF: 2,267,202 hours at 25°C
- Form factor: 1U rack-mountable with integrated mounting kit
- Operating temperature: 0°C to 45°C
- Dimensions: 19" W x 9.84" H x 1.72" D

FAQs

Q: Does this switch require a license to operate?
A: Yes, the MS150-24T-4G requires a Meraki Enterprise or Advanced license to function. The license enables cloud management, firmware updates, and ongoing feature enhancements. Licenses are available in 1, 3, 5, 7, and 10-year terms.

Q: Can I stack multiple MS150-24T-4G switches together?
A: Yes, the MS150-24T-4G supports stacking up to 8 switches using 2 integrated stacking ports with 80 Gbps aggregate bandwidth. Stacking cables (MA-CBL-100G series) are sold separately and enable simplified management of multiple switches as a single logical unit.

Q: What is the difference between Enterprise and Advanced licenses?
A: Enterprise licenses provide core Layer 2 switching features, cloud management, monitoring, and security capabilities. Advanced licenses add Adaptive Policy support and additional security features for organizations requiring enhanced network segmentation and access control.

Q: What SFP modules are compatible with this switch?
A: The MS150-24T-4G supports 1G SFP modules including MA-SFP-1GB-SX (multimode fiber), MA-SFP-1GB-LX10 (single-mode fiber), and MA-SFP-1GB-TX (copper). All SFP modules are sold separately.

Q: Is this switch suitable for PoE devices like access points or IP phones?
A: No, the MS150-24T-4G is a data-only model without PoE capability. For powering PoE devices, consider the MS150-24P-4G which offers 370W PoE+ budget across 24 ports.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
