Description

The Catalyst 9300-M 48-port multigigabit UPOE switch is a stackable Layer 3 access switch ordered in Meraki mode and managed from the Meraki Dashboard. It provides 48 mGig RJ45 ports up to 5G with 60W UPoE, modular 10G/40G uplinks and a default 1100W AC power supply. It requires an active Meraki Enterprise or Advanced licence to operate in cloud-managed mode, making it suited to campus and branch access layers with high-power PoE and multigigabit Wi-Fi 6 and Wi-Fi 6E deployments.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Managed via the Meraki Dashboard with zero-touch provisioning
- StackPower support
- Hot-swappable power supplies and fans
- Integrated multi-factor authentication and role-based access control for Dashboard management
- IEEE 802.1X RADIUS and MAB, DHCP snooping, Dynamic ARP Inspection, IPv4/IPv6 ACLs
- Adaptive Policy support
- Requires an active Meraki Enterprise or Advanced licence to operate in cloud-managed mode

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 48 x 100M/1G/2.5G/5G mGig RJ45 ports with UPoE (60W, 802.3bt)
- Modular uplinks (10G/40G SFP+/QSFP+ network modules; MA-MOD-4X10G, MA-MOD-8X10G and MA-MOD-2X40G are compatible)
- 2 x 120G hardware stack ports, 480 Gbps stacking bandwidth
- 1 x dedicated management interface
- Switching capacity: 640 Gbps
- Forwarding rate: 476.19 Mpps
- Default power supply: PWR-C1-1100WAC-P-M (1100W AC), dual hot-swap PSU bays
- Available PoE: 645W with primary PSU, up to 1745W with a secondary 1100W PSU
- Power load (idle/max): 157.9 / 843.8 W
- Dimensions (H x W x D): 1.73 x 17.5 x 22.2 in (4.4 x 44.5 x 56.4 cm)
- Weight: 20.05 lb (9.09 kg)
- 1U rack mount with 3 hot-swap fans
- Operating temperature: -5°C to 45°C, humidity 5 to 90%
- Layer 3: static routing, OSPFv2, PIM-ASM multicast, warm spare (VRRP), DHCP server/relay

FAQs

Q: What licence does the C9300-48UN-M need?
A: It requires an active Meraki Enterprise or Advanced licence to operate in cloud-managed mode through the Meraki Dashboard.

Q: What uplink modules are compatible?
A: This model uses modular uplinks. The MA-MOD-4X10G, MA-MOD-8X10G and MA-MOD-2X40G network modules are compatible.

Q: What speeds do the access ports support?
A: All 48 RJ45 ports are multigigabit and support 100M, 1G, 2.5G and 5G, with UPoE delivering up to 60W per port using 802.3bt.

Q: Can the PoE budget be increased?
A: Yes. The primary 1100W AC supply provides 645W of PoE, and adding a secondary 1100W supply raises the available PoE to up to 1745W.

Q: Does this switch support stacking?
A: Yes. It has 2 x 120G hardware stack ports for 480 Gbps of stacking bandwidth and also supports StackPower.
