• Meraki C9300-48S-M silver switch with black ports, blue LEDs
1 1

Meraki

Meraki C9300-48S-M | Catalyst 9300 48-Port 1G SFP Switch, StackWise-480

C9300-48S-M

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9300-48S-M is a cloud-managed enterprise access switch designed for high-density fiber aggregation in campus and branch deployments. With 48 Gigabit SFP ports, modular uplink options supporting up to 40G connectivity, and 480 Gbps StackWise stacking, this switch delivers scalable performance for demanding network environments. Managed through the Meraki Dashboard, it combines powerful Cisco hardware with simplified cloud-based configuration and monitoring.

Features

Meraki Dashboard cloud management with zero-touch provisioning
- StackWise-480 stacking up to 8 switches at 480 Gbps bandwidth
- StackPower for resilient power distribution across the stack
- Adaptive Policy micro-segmentation using Security Groups
- Layer 3 routing with OSPFv2, static routing, and VRRP
- NetFlow v10 traffic analytics and visibility
- 802.1x authentication and Dynamic ARP Inspection
- Access Control List (ACL) support for traffic filtering
- VLAN support: 4,094 VLANs (1,000 active with STP)
- 802.1s Multiple Spanning Tree Protocol (MSTP)
- Link aggregation (802.3ad) with up to 8 ports per group
- Hot-swappable redundant power supply support
- Hot-swappable fan modules
- x86 CPU architecture for hosting containers
- USB 3.0 external SSD storage slot (up to 240GB)
- Energy-efficient operation certified for enterprise deployment

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

48x 1 Gigabit Ethernet SFP ports (fiber)
- Modular uplink slots supporting 4x 10G, 8x 10G, or 2x 40G configurations
- Switching capacity: 256 Gbps standalone, 736 Gbps with stacking
- Forwarding rate: 190.47 Mpps standalone, 547.62 Mpps with stacking
- StackWise-480 technology: up to 8 switches at 480 Gbps stacking bandwidth
- 8 GB memory, 16 GB flash storage
- 32,000 MAC address table entries
- Layer 3 routing: Static routing, OSPFv2, VRRP
- 715W AC hot-swappable power supply (PWR-C1-715WAC-P-M)
- Meraki Dashboard cloud management
- Power consumption: 88.9W idle, 158.3W maximum
- 1U rack-mountable form factor
- Dimensions: 1.73 in H × 17.5 in W × 19.2 in D
- Operating temperature: -5°C to 45°C

FAQs

Q: What uplink modules are compatible with the C9300-48S-M?
A: The switch supports field-replaceable network modules including C9300-NM-4G (4x 1G), C9300-NM-8X (8x 10G), C9300-NM-2Q (2x 40G), and C9300-NM-2Y-M (2x 25G SFP28). Uplink modules are sold separately and provide flexible connectivity options from 1G to 100G depending on your infrastructure requirements.

Q: Does the C9300-48S-M require a Meraki license?
A: Yes, this model requires either an Enterprise or Advanced Catalyst 9300-M cloud license to enable Dashboard management, firmware updates, and support. Licenses are available in 1, 3, 5, 7, or 10-year terms and must be purchased separately from the hardware.

Q: Can I stack multiple C9300-48S-M switches together?
A: Yes, StackWise-480 technology allows you to stack up to 8 switches with 480 Gbps of stacking bandwidth using STACK-T1 cables. This creates a single logical switch for simplified management and provides high-bandwidth interconnection between stack members.

Q: What Layer 3 routing protocols does this switch support?
A: The C9300-48S-M supports static routing, OSPFv2, and VRRP for warm-standby redundancy. Layer 3 routing capabilities enable the switch to function as a distribution layer device in campus networks with inter-VLAN routing and dynamic routing protocols.

Q: Is this switch suitable for connecting fiber uplinks from access layer switches?
A: Absolutely. With 48 Gigabit SFP ports, the C9300-48S-M is ideal for aggregating fiber connections from access switches, wireless access points, or other network devices in enterprise campus environments where fiber runs are already deployed.
