Meraki

Meraki C8355-G2-MX | MX 4x 10G SFP+ SD-WAN Router, 4x 5G mGig, 10Gbps

C8355-G2-MX

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The C8355-G2-MX is a cloud-managed Cisco Secure Router from the Meraki MX range, built for large branch sites that need Security and SD-WAN in one appliance. It combines next-generation firewall services, site-to-site VPN and high-speed branch connectivity, all managed through the Meraki dashboard with minimal pre-configuration at the remote site.

On the numbers, it delivers up to 10 Gbps of next-generation firewall throughput, 5 Gbps of site-to-site VPN throughput and 4 Gbps of advanced security throughput. Connectivity includes 2x 10G SFP+ WAN ports and 2x 10G SFP+ LAN ports, with LAN/WAN port conversion allowing up to 3 WAN links in Multi-WAN mode. The LAN side adds 4x 5 Gbps mGig RJ45 ports with UPoE+ and 2x 1 Gbps RJ45 ports, plus dedicated console and management ports. It is recommended for up to 5,000 devices and 1,500 tunnels, and requires a Meraki MX / Secure SD-WAN licence to operate on the dashboard.

The SFP+ ports accept the Meraki optics MA-SFP-10GB-SR, -LR, -LRM and -ER, MA-SFP-1GB-TX and MA-SFP-1GB-LX10, and the MA-CBL-TA-1M and MA-CBL-TA-3M twinax cables on 10G ports.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Cloud-managed Security and SD-WAN through the Meraki dashboard
- Hardware-accelerated firewall, VPN and advanced threat protection
- Multigigabit LAN access for high-speed branch aggregation
- Flexible Multi-WAN mode through LAN/WAN conversion on the SFP+ ports
- Dedicated console and management ports for deployment and recovery workflows
- Simple deployment with minimal pre-configuration required at the branch

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Maximum NGFW throughput: 10 Gbps
- Maximum site-to-site VPN throughput: 5 Gbps
- Advanced security throughput: 4 Gbps
- WAN ports: 2x 10G SFP+ (up to 3 WAN with LAN/WAN conversion in Multi-WAN mode)
- LAN ports: 2x 10G SFP+ (convertible to WAN)
- LAN ports: 4x 5 Gbps mGig RJ45 with UPoE+
- LAN ports: 2x 1 Gbps RJ45
- Console port: 1x RJ45
- Management interface: 1x RJ45
- Recommended device count: 5,000
- Maximum recommended tunnels: 1,500
- Optional power upgrade: 230W
- Supported power cords: CAB-AC-C5-US, -EU, -UK, -AU, -BR
- Management: Meraki cloud dashboard

FAQs

Q: Does the C8355-G2-MX need a licence?
A: Yes. It requires a Meraki MX / Secure SD-WAN licence, which is a Meraki cloud subscription, to operate and be managed through the Meraki dashboard.

Q: Which optics and cables work in the SFP+ ports?
A: The SFP+ ports support MA-SFP-10GB-SR, -LR, -LRM and -ER. MA-SFP-1GB-TX and MA-SFP-1GB-LX10 are supported at both 10G and 1G port speeds. Twinax cables MA-CBL-TA-1M and MA-CBL-TA-3M are supported on the 10G ports.

Q: Can I run more than two WAN links?
A: Yes. In Multi-WAN mode, LAN/WAN port conversion on the SFP+ ports allows up to 3 WAN connections.

Q: Can I claim it on my Meraki dashboard?
A: Yes. Every Meraki device XS Network Tech supplies can be claimed on your Meraki dashboard.

Q: Does it support PoE on the mGig ports?
A: The 4x 5 Gbps mGig RJ45 LAN ports support UPoE+. UPoE and PoE support is due in a later 26.2 release, and an optional 230W power upgrade is available.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
