• Cisco C1121-4PLTEPPM ISR 1100 router with Ethernet ports, USB, yellow accents
1 1

Cisco

Cisco C1121-4PLTEPPM | ISR 1100 Router, 4x GE LAN, Dual WAN, Pluggable LTE, PoE

C1121-4PLTEPPM

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ISR 1100 is a compact, fanless branch router from the Cisco 1000 Series Integrated Services Routers. It combines routing, switching and a pluggable cellular WAN slot in one small chassis, suiting small and branch offices, retail stores, medical clinics and remote sites that need a secure router with LTE backup or primary cellular connectivity. It also serves as an SD-WAN edge device and provides VoIP survivability through Cisco Unified Border Element and Unified SRST.

The C1121-4PLTEPPM provides 4 x Gigabit Ethernet LAN ports and a dual-WAN arrangement of one copper GE port plus one combo copper/SFP GE port. A pluggable cellular module slot accepts LTE and 5G modules, and the unit is PoE-ready, with optional PoE on the LAN ports via the ISR-1100-POE2 adapter and 115W power supply (2 PoE ports or 1 PoE+ port). It carries 4 GB DRAM and 4 GB flash, with up to 1600 Mbps IPv4 forwarding throughput and up to 500 Mbps IPsec throughput in autonomous mode. It runs Cisco IOS XE or controller-managed IOS XE SD-WAN, and ships with IP Base.

The combo WAN port supports SFPs including GLC-SX-MM(D), GLC-LH-SM(D) and GLC-ZX-SM(D), and the cellular slot supports a range of LTE CAT4, CAT6, CAT7 and CAT18 modules as well as 5G options.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Fanless, small-form-factor router combining routing, switching and cellular WAN
- Choice of Cisco IOS XE or controller-managed IOS XE SD-WAN
- Management via WebUI, Cisco DNA Center and Catalyst SD-WAN Manager
- On-box security: NGFW with application awareness, IPS/IDS, Advanced Malware Protection, URL filtering and Cisco Umbrella
- Cellular failover between the primary WAN and a backup LTE/5G link, with dual SIM support on PIM modules
- VoIP support through Cisco Unified Border Element (CUBE) and Unified SRST
- Pay-as-you-grow performance licensing (VPERF/HSEC)

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- LAN ports: 4 x Gigabit Ethernet (copper)
- WAN ports: 1 x GE copper + 1 x GE combo (copper/SFP)
- Cellular: 1 pluggable module slot (PIM), LTE CAT4/6/7/18 or 5G NSA/SA modules
- Wi-Fi: None
- DRAM / flash: 4 GB / 4 GB
- IPv4 forwarding throughput (512B, autonomous): up to 1600 Mbps
- IPsec throughput (512B, autonomous): up to 500 Mbps
- SD-WAN IPsec throughput (512B): up to 450 Mbps
- SD-WAN overlay tunnels: 200
- Console: 1 x Micro-USB; 1 x USB 3.0 Type-A port
- PoE option: ISR-1100-POE2 with 115W power supply, 2 PoE or 1 PoE+ port
- External power supply: 100 to 240 VAC input, 12 VDC output, max 66 W
- Maximum power consumption: 23.5 W (excluding power supply loss)
- Dimensions (H x W x D): 1.65 x 10.80 x 7.85 in.
- Weight: 3.70 lb (1.68 kg)
- Operating temperature: 0 to 40 C at sea level
- Operating humidity: 10% to 85% RH (non-condensing)
- Minimum software: IOS XE 16.11.1 (autonomous), IOS XE SD-WAN 17.2.1

FAQs

Q: Which licence does it ship with?
A: It ships with IP Base. Optional technology licences cover Application Experience, Unified Communications and Security, plus IPsec performance upgrades. SD-WAN deployments use Cisco DNA Essentials, Advantage or Premier subscriptions, and Smart Licensing requires a Cisco Smart Account.

Q: How is PoE provided on the LAN ports?
A: PoE is optional. It requires the ISR-1100-POE2 adapter and a 115W power supply, which provides 2 PoE ports or 1 PoE+ port on the 4-port models.

Q: Which cellular modules does the pluggable slot support?
A: Supported modules include P-LTE (CAT4), P-LTEA (CAT6), P-LTEA7 (CAT7) and P-LTEAP18-GL (CAT18), plus P-5GS6-GL for 5G NSA and P-5GS6-R16-SA for 5G SA on suitable IOS XE releases.

Q: Which SFPs work in the combo WAN port?
A: The combo copper/SFP WAN port supports GLC-SX-MM(D), GLC-LH-SM(D), GLC-ZX-SM(D), GLC-T/TE and the GLC-BX series, as well as 100BASE FE, CWDM and DWDM SFPs.

Q: Can it run in SD-WAN mode?
A: Yes. It runs either autonomous Cisco IOS XE or controller-managed IOS XE SD-WAN from version 17.2.1, and supports up to 200 SD-WAN overlay tunnels.
