• White cisco catalyst 9800 series switch rear panel with multiple ethernet ports and control knobs for meraki c8235-g2 router
1 1

Meraki

Meraki C8235-G2-MX | MX C8235-G2 Secure Router, 8x 2.5G, 2x 10G SFP+

C8235-G2-MX

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The C8235-G2-MX is a cloud-managed secure router from the Meraki MX family, built for large and medium branch sites of up to about 1,000 devices. It combines a next-generation firewall, unified threat management and SD-WAN in a single appliance, and is deployed and administered through the Meraki dashboard with minimal pre-configuration. It also suits VPN concentrator roles and SASE/ZTNA architectures.

The unit provides 8x 2.5G multigigabit RJ45 ports and 2x 10G SFP/SFP+ ports, with up to 3 WAN uplinks available through LAN/WAN conversion. Two of the 2.5G ports support UPoE+ when the optional 230W AC PoE power supply is fitted, giving a 120W PoE budget. Maximum firewall throughput is 6 Gbps, site-to-site VPN throughput is 4 Gbps and advanced security throughput is 3 Gbps, with up to 750 recommended VPN tunnels.

This is a hardware SKU and requires a Meraki MX licence to operate. Enterprise, Advanced Security and SD-WAN licence options are available in 1, 3, 5 and 7 year terms. The appliance is a fanless 1 RU design with a 19-inch rack-mount tray, and runs from a standard 85 to 264 Vac input.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Dedicated secure networking processor for fast cryptography and deep packet inspection
- Hardware acceleration for high throughput with threat protection enabled
- SD-WAN dynamic path selection based on latency, jitter and packet loss
- Unified threat management with stateful firewall, IDS/IPS and malware protection
- Content filtering with URL categorisation and reputation-based filtering
- Auto VPN SD-WAN fabric with native IPsec or Cisco AnyConnect client VPN
- VPN concentrator support for large site-to-site and client VPN topologies
- Built-in SD-WAN connectivity to Cisco Umbrella
- Cloud management via the Meraki dashboard with zero-touch style deployment

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Model: C8235-G2-MX
- Ports: 2x 10 GE SFP/SFP+
- Ports: 8x 2.5 GE multigigabit RJ45
- WAN uplinks: up to 3 with LAN/WAN conversion (Multi-WAN mode)
- PoE: 2x 2.5 GE mGig RJ45 UPoE+ ports
- PoE budget: 120 W (with optional 230W AC PoE power supply, ports 6 and 7)
- Management: 1x RJ45 console port, 1x RJ45 management interface
- Maximum firewall throughput: 6 Gbps
- Maximum site-to-site VPN throughput: 4 Gbps
- Advanced security throughput: 3 Gbps
- Recommended device count: 1,000
- Maximum recommended tunnels: 750
- Power supply: 66W AC
- Optional power supply: 230W AC with PoE
- Typical power consumption: 45 W (excluding PoE)
- Input voltage: 85 to 264 Vac
- Form factor: 1 RU, fanless, 19-inch rack mount
- Dimensions (H x W x D): 4.19 x 22.60 x 32.26 cm
- Weight: 3.17 kg
- Operating temperature: 0 to 40 C
- Storage temperature: -40 to 70 C
- Humidity: 5 to 85% non-condensing (operating)

FAQs

Q: Does the C8235-G2-MX need a licence?
A: Yes. It requires a Meraki MX licence to operate and the hardware SKU does not include a licence term. Enterprise (LIC-C8235-ENT), Advanced Security (LIC-C8235-SEC) and SD-WAN (LIC-C8235-SDW) licences are available in 1, 3, 5 and 7 year terms.

Q: How is PoE provided on this router?
A: Ports 6 and 7 support UPoE+ when the optional 230W AC PoE power supply is fitted, giving a 120W PoE budget. The standard 66W AC power supply does not supply PoE.

Q: Which SFP and SFP+ modules does it support?
A: The 10G ports support MA-SFP-10GB-SR, MA-SFP-10GB-LR, MA-SFP-10GB-LRM and MA-SFP-10GB-ER. MA-SFP-1GB-TX and MA-SFP-1GB-LX10 are supported on both the 10G and 1G ports.

Q: How many WAN uplinks can it use?
A: Up to 3 WAN uplinks are available through LAN/WAN conversion in Multi-WAN mode.

Q: Can I claim it on my Meraki dashboard?
A: Yes. Every Meraki device XS Network Tech supplies can be claimed on your Meraki dashboard.
