• HPE JG405A 1U SD-WAN router with black rackmount chassis, dual fans, 5.25-inch bay
1 1

HPE

HPE JG405A | FlexNetwork MSR3044 Router, 3x GbE, 2x SFP, 4 HMIM, 2U

JG405A

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The HPE FlexNetwork MSR3044 is a modular branch router from the MSR3000 series, built for medium to large branch offices that need integrated routing, switching, security and voice in a single box. Optional 3G/4G LTE SIC modules provide WAN backup for business continuity.

The JG405A provides 3 x 1000BASE-T ports and 2 x fixed Gigabit SFP ports, with 4 HMIM slots, 4 SIC slots (or 2 DSIC slots, or a combination) and 2 voice processing module slots for flexible expansion. A 4-core 1 GHz processor and 2 GB DDR3 memory deliver throughput of up to 3.5 Mpps, and the routing table supports 500,000 IPv4 and 500,000 IPv6 entries. Two power supply slots accept AC 100-240 VAC or DC -36 to -75 VDC supplies, with PoE+ capability of 450 W depending on options. The chassis is 2U.

Routing, switching, security and SIP features need no additional licensing, while the IPS filter is an optional HPE subscription. The router accepts HMIM, SIC and DSIC modules, voice processing modules, SFP transceivers in the Gigabit SFP ports and the Open Application Platform module. It runs HPE Comware software and is managed through HPE Intelligent Management Center.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Integrated routing, switching, security and SIP in a single box with no additional feature licensing
- Built-in IPS and stateful firewall, with optional HPE IPS filter subscription
- WAN survivability with 4G LTE SIC modules and flexible power options
- Serial, GbE and Gig-T SIC modules for flexible configuration
- High-density voice modules and channelised POS access
- ADVPN and hierarchical QoS
- Zero-touch deployment (ZTP) and Dynamic VPN
- Managed with HPE Intelligent Management Center (IMC)
- Open Application Platform module supports HPE AllianceOne applications such as WAN acceleration and Skype for Business

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 3 x RJ-45 1000BASE-T
- Fixed SFP ports: 2 x Gigabit Ethernet SFP
- HMIM slots: 4
- SIC slots: 4 (or 2 x DSIC slots, or a combination)
- Voice processing module slots: 2
- Processor: 4-core 1 GHz
- Memory: 2 GB DDR3 default
- Throughput: up to 3.5 Mpps
- Routing table: 500,000 IPv4 entries, 500,000 IPv6 entries
- Wireless options: 3G / 4G LTE via SIC modules
- PoE capability: 450 W PoE+ (depending on options)
- Power supply slots: 2
- Input voltage: 100-240 VAC or -36 to -75 VDC, depending on power supply
- Maximum power consumption: 300 W
- Heat dissipation: 172 BTU/hr
- Operating humidity: 5 to 90% non-condensing
- Dimensions: 44 x 48 x 8.81 cm
- Weight: 12.45 kg

FAQs

Q: Does the MSR3044 need additional feature licences?
A: No. Integrated routing, switching, security and SIP features need no additional licensing. The IPS filter is an optional HPE subscription.

Q: How many power supplies does it take and what input is supported?
A: It has 2 power supply slots and at least one power supply must be fitted. Power supplies cannot be mixed. Input is 100-240 VAC or -36 to -75 VDC depending on the supply chosen.

Q: Can it provide cellular WAN backup?
A: Yes. Optional 3G/4G LTE SIC modules can be installed to give WAN resilience alongside the wired uplinks.

Q: What expansion modules does it accept?
A: It accepts HMIM, SIC and DSIC modules, voice processing modules and the Open Application Platform module. The two fixed SFP ports take Gigabit SFP transceivers.

Q: How is the router managed?
A: It runs HPE Comware software and is managed through HPE Intelligent Management Center (IMC). It also supports zero-touch deployment.
