• Black HPE ProLiant ML30 Gen10 tower server with perforated front panel and USB ports
1 1

HPE

HPE HPE-ML30-G9 | ProLiant ML30 Gen9 Tower Server, Xeon E3 v5/v6, 64GB

HPE-ML30-G9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.

Custom Built Servers

Need a different spec, quantity or configuration?

We build configured-to-order refurbished servers from Cisco, Dell, HPE, NVIDIA Lenovo and Supermicro. Tell us what you need and we'll come back with options within 24 hours.

Configure your server now →

Description

The HPE ProLiant ML30 Gen9 is a single-socket 4U tower server designed for small businesses and remote branch offices. Powered by Intel Xeon E3-1200 v5 or v6 processors with up to 4 cores, it supports up to 64GB DDR4 ECC UDIMM memory across 4 DIMM slots. Flexible storage options include 4x LFF or 8x SFF drive bays with SATA B140i or optional Smart Array controllers, dual Gigabit Ethernet ports, and iLO 4 management for reliable, affordable performance.

Features

Single-socket Intel Xeon E3-1200 v5/v6 processor support for efficient compute performance
- DDR4 ECC Unbuffered memory with up to 64GB capacity for data integrity
- Flexible drive configuration supporting either 4x LFF or 8x SFF bays
- Embedded SATA B140i controller with optional Smart Array controller upgrades
- RAID support (0, 1, 5, 10) with optional Smart Array controllers
- Dual embedded Gigabit Ethernet ports for network connectivity
- HPE iLO 4 standard for comprehensive remote server management
- Intelligent Provisioning for simplified deployment and updates
- 4x PCIe 3.0 expansion slots for enhanced flexibility
- Optional hot-plug redundant power supply support (460W 80 PLUS Gold)
- Compact 4U tower form factor ideal for office environments
- TPM 1.2 and 2.0 support for enhanced security
- ClearOS compatibility for open-source server applications

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

Processor: Single-socket Intel Xeon E3-1200 v5 or v6, up to 4 cores, up to 4.0 GHz
- Memory: 4 DIMM slots, DDR4 ECC UDIMM, up to 64GB maximum, 2400 MHz
- Storage: 4x LFF (3.5-inch) or 8x SFF (2.5-inch) SATA/SAS drive bays
- Storage Controller: SATA B140i embedded, optional Smart Array controllers (RAID 0/1/5/10)
- Network: Dual embedded Broadcom 5720 Gigabit Ethernet ports (2x 1GbE)
- Expansion: 4x PCIe 3.0 slots (1x x16, 1x x8, 2x x4)
- Management: HPE iLO 4 standard, Intelligent Provisioning
- Power Supply: 350W non-hot-plug standard, optional 460W hot-plug redundant (80 PLUS Gold)
- Form Factor: 4U tower
- Operating Temperature: Up to 35°C ambient (tower configuration)

FAQs

Q: What processors are supported by the HPE ML30 Gen9?
A: The ML30 Gen9 supports single-socket Intel Xeon E3-1200 v5 and v6 processors, as well as Intel Core i3 and Pentium processors, offering up to 4 cores and clock speeds up to 4.0 GHz for small business workloads.

Q: Can I mix different memory speeds in this server?
A: Yes, you can mix different DDR4 ECC UDIMM speeds, but all modules will operate at the speed of the slowest module installed. The maximum supported speed is 2400 MHz, dependent on the processor selected.

Q: What storage configurations are available?
A: The ML30 Gen9 offers flexible storage with either 4x LFF (3.5-inch) or 8x SFF (2.5-inch) drive configurations. Storage can be hot-plug or non-hot-plug depending on the chassis model, supporting SATA and SAS drives with optional Smart Array controllers for RAID functionality.

Q: Does this server support redundant power supplies?
A: Yes, the ML30 Gen9 can be configured with redundant 460W hot-plug power supplies with the appropriate backplane and enablement kit. The standard configuration includes a single 350W non-hot-plug power supply.

Q: What management capabilities does the ML30 Gen9 provide?
A: The server includes HPE iLO 4 (Integrated Lights-Out) for remote management, allowing administrators to monitor, configure, and troubleshoot the server remotely. It also features Intelligent Provisioning for easy deployment and configuration.
