Cisco

Cisco WS-C3850-48T-S | Catalyst 3850 48-Port Gigabit Switch, IP Base, 350W

SKU:WS-C3850-48T-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 3850 WS-C3850-48T-S is a 48-port 10/100/1000 non-PoE stackable access switch for converged wired and wireless campus and branch wiring closets. It terminates wireless traffic through its integrated controller capability and aggregates data-only Gigabit Ethernet ports, with an optional uplink network module slot for 1G or 10G connectivity.

The switch delivers 176 Gbps of switching capacity and a 130.95 Mpps forwarding rate. StackWise-480 provides 480 Gbps of stack bandwidth and StackPower shares power across stack members. It runs the IP Base feature set, which is required for Mobility Controller mode, and is fitted with a 350W AC power supply with a second power supply slot available for redundancy. As a data-only model it has no PoE budget.

Uplink modules available are the C3850-NM-4-1G, C3850-NM-2-10G and C3850-NM-4-10G. The SFP and SFP+ uplink ports accept Cisco SFP and SFP+ transceivers, and the switch stacks with other Catalyst 3850 switches.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Integrated wireless controller capability (Mobility Agent by default, Mobility Controller mode with IP Base)
- StackWise-480 stacking with 480 Gbps of stack throughput
- StackPower power sharing across stack members
- Optional field-replaceable uplink network modules
- Dual redundant modular power supply slots and three modular fans
- Programmable UADP ASIC with Cisco ONE and Cisco DNA support
- Single universal Cisco IOS XE image across all licence levels
- Energy-Efficient Ethernet (EEE) on RJ-45 ports
- MACsec-128 encryption on all models

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Ports: 48 x 10/100/1000 Ethernet
- PoE: None (data-only model)
- Uplinks: Optional network module (C3850-NM-4-1G, C3850-NM-2-10G or C3850-NM-4-10G)
- Software feature set: IP Base
- Default power supply: 350W AC (PWR-C1-350WAC)
- Power supply input: 100-240 VAC, 50-60 Hz, 4-2 A
- Switching capacity: 176 Gbps
- Forwarding rate: 130.95 Mpps
- Stacking: StackWise-480, 480 Gbps stack bandwidth
- StackPower: Yes
- MAC addresses: 32,000
- IPv4 routes: 24,000
- VLAN IDs: 4,000
- Switched Virtual Interfaces: 1,000
- Jumbo frame: 9198 bytes
- DRAM: 4 GB
- Flash: 2 GB
- Wireless: up to 100 access points and 2000 clients per switch or stack
- Dimensions (H x W x D): 4.45 x 44.5 x 45.0 cm (1 RU)
- Weight (excluding uplink module): 7.7 kg
- Operating temperature: -5 to +45 C up to 1500 m
- Relative humidity: 10% to 95%, noncondensing
- MTBF: 303,660 hours

FAQs

Q: What licence does the WS-C3850-48T-S use?
A: The -S suffix denotes the IP Base feature set. The IOS XE image is the same across all licence levels, and no extra licence is needed for Mobility Agent mode. IP Base is required for Mobility Controller mode. Optional Cisco DNA Essentials or Advantage term licences add SD-Access and DNA Center features.

Q: Does this switch provide PoE?
A: No. It is a data-only model with 48 x 10/100/1000 ports and no PoE budget. If you need to power access points or phones, choose a PoE variant of the Catalyst 3850.

Q: Which power supplies does it support?
A: It uses the 350W AC PWR-C1-350WAC by default and has two power supply slots for redundancy with AC/DC mixing. Compatible supplies are PWR-C1-350WAC, PWR-C1-715WAC, PWR-C1-1100WAC and PWR-C1-440WDC.

Q: Which uplink modules fit this switch?
A: The C3850-NM-4-1G, C3850-NM-2-10G and C3850-NM-4-10G network modules are supported. The SFP and SFP+ uplink ports accept Cisco SFP and SFP+ transceivers.

Q: Can it be stacked with other switches?
A: Yes. It stacks with other Catalyst 3850 switches over StackWise-480 with 480 Gbps of stack bandwidth, and StackPower shares power between stack members.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
