Cisco WS-C3850-48T-E | Catalyst 3850 48-Port Gigabit Switch, Layer 3, IP Services

WS-C3850-48T-E

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco WS-C3850-48T-E is an enterprise-class stackable Layer 3 switch featuring 48 Gigabit Ethernet ports and IP Services licensing. Built on the Unified Access Data Plane ASIC, this switch delivers 176 Gbps switching capacity and StackWise-480 technology for high-performance campus networks. The modular design supports optional network uplink modules for flexible 1G or 10G connectivity, making it ideal for converged wired-wireless deployments and advanced routing applications.

Features

IP Services feature set with advanced Layer 3 routing: EIGRP, OSPF, BGP, PIM, OSPFv3, EIGRPv6
- StackWise-480 stacking technology for up to 9 switches at 480 Gbps throughput
- Integrated wireless controller capability supporting up to 100 access points and 2,000 clients
- Unified Access Data Plane (UADP) ASIC for wired-wireless convergence
- Cisco StackPower technology for power redundancy across up to 4 switches
- Modular uplink design with field-replaceable network modules
- Advanced QoS with MQC-based quality of service and 802.1p/DSCP classification
- Flexible NetFlow (FNF) Version 9 for application visibility and monitoring
- Comprehensive Layer 2 features: STP, RSTP, MSTP, VTP, 802.1Q VLANs
- Advanced security: 802.1X, MACsec, DHCP snooping, Dynamic ARP Inspection, IP Source Guard
- Energy Efficient Ethernet (EEE) support for reduced power consumption
- Dual redundant fans and power supplies for high availability

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

48x 10/100/1000 Ethernet RJ45 ports
- 1x optional network module slot (modules sold separately)
- Module options: C3850-NM-4-1G (4x 1G SFP), C3850-NM-2-10G (4x 1G SFP / 2x 10G SFP+), C3850-NM-4-10G (4x 10G SFP+)
- Switching capacity: 176 Gbps
- Forwarding rate: 130.95 Mpps
- MAC address table: 32,000 entries
- IPv4 routing table: 24,000 routes
- Switched virtual interfaces (SVIs): 1,000
- VLANs supported: 4,094
- StackWise-480 stacking: up to 9 switches at 480 Gbps stack bandwidth
- Dual redundant hot-swappable power supplies (second PSU sold separately)
- Default power supply: 350W AC (PWR-C1-350WAC)
- Flash memory: 2 GB
- DRAM: 4 GB
- Management: Cisco IOS XE, CLI, web UI, SNMP v1/v2c/v3
- Dimensions (H x W x D): 4.45 x 44.5 x 45.0 cm (1.75 x 17.5 x 17.7 in), 1RU
- Weight: 7.7 kg (17.0 lb)
- Operating temperature: -5°C to 45°C (up to 1500m), -5°C to 40°C (up to 3000m)

FAQs

Q: What is the difference between IP Services and IP Base licensing?
A: IP Services provides full enterprise Layer 3 routing with advanced protocols including EIGRP, OSPF, BGP, PIM, and full IPv6 routing (OSPFv3, EIGRPv6). IP Base offers entry-level Layer 3 routing with static routing and RIP. The WS-C3850-48T-E comes pre-licensed with IP Services for advanced routing deployments.

Q: Does this model support PoE or Power over Ethernet?
A: No, the WS-C3850-48T-E is a data-only model without PoE capability. For PoE+ support on 48 ports, consider the WS-C3850-48P-E (435W budget) or WS-C3850-48F-E (800W budget). For UPOE, the WS-C3850-48U-E is available.

Q: What uplink modules are compatible with this switch?
A: The 48-port models support three network modules: C3850-NM-4-1G (4x 1G SFP), C3850-NM-2-10G (4x 1G SFP / 2x 10G SFP+), and C3850-NM-4-10G (4x 10G SFP+). Modules are sold separately and hot-swappable. The default configuration does not include an uplink module.

Q: Can this switch function as a wireless controller?
A: Yes, with IP Services licensing the Catalyst 3850 can operate as an integrated wireless controller (mobility controller or mobility agent). A single switch supports up to 100 access points and 2,000 wireless clients. Separate access point licenses are required for mobility controller mode.

Q: How many switches can be stacked together?
A: Up to 9 Catalyst 3850 switches with the same feature set can be stacked using StackWise-480 technology, providing 480 Gbps of stack bandwidth. Mixed stacks of different license levels (LAN Base, IP Base, IP Services) are not supported. Stacking cables are sold separately.
