• Cisco WS-C3850-32XS-S Catalyst 9300 switch with 32x 10GbE SFP+ ports
1 1

Cisco

Cisco WS-C3850-32XS-S | Catalyst 3850 32-Port 10G SFP+ Switch, 8x 10G SFP+ Module, IP Base

WS-C3850-32XS-S

Stock Status: Enquire

Request Quote
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco WS-C3850-32XS-S is an enterprise-class Layer 3 stackable switch featuring 24 SFP+ ports with an included C3850-NM-8-10G module providing 8 additional 10G SFP+ uplinks for a total of 32 ports. Built on Cisco's Unified Access Data Plane ASIC architecture, this 1RU switch delivers seamless wired and wireless convergence with StackWise-480 technology supporting up to 9 switches and 480 Gbps stacking bandwidth. Ideal for high-density 10 Gigabit aggregation and campus backbone deployments requiring advanced Layer 3 routing with the IP Base feature set.

Features

Cisco Unified Access Data Plane (UADP) ASIC for wired-wireless convergence
- Integrated wireless controller supporting up to 100 access points and 2000 clients per stack
- StackWise-480 stacking with 480 Gbps bandwidth and stateful switchover (SSO) for high availability
- StackPower technology for power supply pooling and redundancy across up to 4 switches
- Layer 3 routing: Static routing, RIPv2, OSPF, EIGRP, BGP, Policy-Based Routing (PBR)
- Advanced QoS with 8 egress queues per port, granular traffic classification and marking
- Comprehensive security: MACsec encryption, 802.1X, port security, DHCP snooping, Dynamic ARP Inspection, IP Source Guard
- Flexible NetFlow (FNF) for application visibility and traffic analysis
- Energy-Efficient Ethernet (EEE) IEEE 802.3az support
- Redundant fan and power supply support for mission-critical deployments
- Modular network module slot for flexible uplink configurations
- Cisco IOS XE operating system with consistent feature set across enterprise platforms

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

Total Ports: 24 x 10G SFP+ base ports + 8 x 10G SFP+ uplinks (C3850-NM-8-10G module included) = 32 ports
- Port Speed: 1/10 Gigabit Ethernet SFP+ (backward compatible with 1G SFP modules)
- Switching Capacity: 640 Gbps
- Forwarding Rate: 454.55 Mpps (million packets per second)
- Layer Support: Layer 2 and Layer 3 switching with IP Base feature set
- Memory: 8GB DRAM, 4GB Flash
- Stacking: Cisco StackWise-480 technology, up to 9 switches, 480 Gbps stack bandwidth
- Power Supply: 715W AC power supply (field-replaceable, redundant power supply optional)
- Wireless Controller: Integrated wireless controller supporting up to 100 access points and 2000 wireless clients per stack
- Management: Cisco IOS XE, CLI, web interface, SNMP, USB and RJ-45 console ports
- Dimensions: 1.75 in H x 17.7 in W x 17.5 in D (4.45 x 45.0 x 44.5 cm), 1 RU
- Weight: Approximately 15.9 lbs (7.2 kg)
- Operating Temperature: 0°C to 45°C (32°F to 113°F) at up to 5,000 feet
- Standards Compliance: IEEE 802.1p, 802.1Q, 802.1x, 802.3ad, 802.3af, 802.3at
- MTBF: Approximately 297,500 hours

FAQs

Q: What is included in the WS-C3850-32XS-S bundle?
A: The WS-C3850-32XS-S includes the base switch with 24 SFP+ ports, the C3850-NM-8-10G network module providing 8 additional 10G SFP+ uplinks, a 715W AC power supply, and the IP Base feature set. SFP/SFP+ transceivers and stacking cables are sold separately.

Q: Can this switch support both 1G and 10G SFP modules simultaneously?
A: Yes, all SFP+ ports on the WS-C3850-32XS-S are backward compatible and support both 1G SFP and 10G SFP+ transceivers simultaneously, allowing flexible mixed-speed deployments without requiring separate interface types.

Q: What is the difference between IP Base and IP Services feature sets?
A: The IP Base feature set included with the WS-C3850-32XS-S provides Layer 3 routing with up to 1000 VLANs, static routing, OSPF, EIGRP, and policy-based routing. IP Services (available with the -E SKU) adds advanced features like VRF-Lite, multicast routing (PIM), and additional security capabilities. License upgrades are available.

Q: How many switches can be stacked together?
A: The Catalyst 3850-32XS-S supports stacking up to 9 switches using StackWise-480 technology with 480 Gbps of stack bandwidth. The stack operates as a single logical unit with unified management and can only stack with other Catalyst 3850 Series switches running the same license level (IP Base).

Q: Does this switch support Power over Ethernet (PoE)?
A: No, the WS-C3850-32XS-S is a non-PoE model designed for fiber connectivity via SFP/SFP+ transceivers. For PoE requirements, consider Catalyst 3850 models with RJ45 ports such as the WS-C3850-24P or WS-C3850-48P series.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
