Cisco WS-C3850-24XU-L | Catalyst 3850 24-Port 10G mGig UPoE Switch, 580W, LAN Base

SKU:WS-C3850-24XU-L

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 3850 24-port Multigigabit UPOE switch is a stackable, fixed-configuration 1RU access switch for enterprise campus and branch networks. It runs a converged wired and wireless Cisco IOS XE platform, and its Multigigabit ports let 802.11ac Wave 2 access points and UPOE-powered devices run over existing Cat5e or Cat6 cabling.

This SKU provides 24 RJ-45 ports that negotiate 100M, 1G, 2.5G, 5G or 10G, each with Cisco UPOE of up to 60W per port. It offers 640 Gbps of switching capacity and a 500 Mpps forwarding rate, and StackWise-480 delivers 480 Gbps of stacking bandwidth. With the default 1100W AC power supply the PoE budget is 580W, rising to 1680W when a second 1100W supply is fitted. The LAN Base feature set applies to this model, and Cisco DNA licence tiers are sold separately.

Five optional uplink modules cover 1G, 10G and 40G needs: C3850-NM-4-1G, C3850-NM-2-10G, C3850-NM-4-10G, C3850-NM-8-10G and C3850-NM-2-40G. It stacks with other Catalyst 3850 switches and supports StackPower for power sharing across stack members.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Cisco UPOE delivering 60W per port, with IEEE 802.3at PoE+ at 30W per port
- IEEE 802.3bz support for 2.5 and 5 Gbps over existing Cat5e or Cat6 cabling
- StackWise-480 stacking with 480 Gbps of stack throughput
- StackPower for power sharing and redundancy across stack members
- Dual redundant modular power supply bays and three field-replaceable fans
- Five optional uplink network modules covering 1G, 10G and 40G
- Converged wired and wireless access on a single Cisco IOS XE platform
- UADP ASIC with Flexible NetFlow and granular QoS
- MACsec-256 support on the Multigigabit ports

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Model: WS-C3850-24XU
- Ports: 24 x 100Mbps/1/2.5/5/10 Gbps Multigigabit UPOE RJ-45
- PoE: Cisco UPOE up to 60W per port, PoE+ 30W per port
- Default power supply: PWR-C1-1100WAC (1100W AC)
- Available PoE power: 580W with default power supply
- PoE budget with 1100W secondary power supply: 1680W
- Available PoE with 2 x 440W DC power supplies: 360W
- Switching capacity: 640 Gbps
- Forwarding rate: 500 Mpps (80B packets)
- Stacking: StackWise-480, 480 Gbps
- StackPower: Yes
- MAC addresses: 32,000
- IPv4 routes: 24,000
- DRAM: 4 GB
- Flash: 2 GB
- VLAN IDs: 4,000
- Switched Virtual Interfaces: 1,000
- Jumbo frame: 9198 bytes
- Routed ports per stack: 208
- Dimensions (H x W x D): 4.45 x 44.5 x 48.8 cm (1RU)
- Weight: 8.0 kg
- MTBF: 203,150 hours
- Operating temperature (AC PSU): -5 to +45 C up to 1500 m
- Relative humidity: 10% to 95%, noncondensing
- Feature set: LAN Base

FAQs

Q: Which licence tier does this SKU use?
A: The -L suffix indicates the LAN Base feature set, the entry-level Catalyst 3850 licence level. Cisco DNA Essentials and Advantage term licences are sold separately.

Q: How much PoE does it provide?
A: With the default 1100W AC power supply the PoE budget is 580W. Fitting a second 1100W power supply raises the budget to 1680W.

Q: Which uplink modules can I fit?
A: It supports the C3850-NM-4-1G, C3850-NM-2-10G, C3850-NM-4-10G, C3850-NM-8-10G and C3850-NM-2-40G network modules.

Q: Which power supplies does it support?
A: It supports the PWR-C1-350WAC, PWR-C1-715WAC, PWR-C1-1100WAC and 440W DC supplies. The 750W AC supplies are intended for 48-port SFP+ models.

Q: Can it be stacked with other switches?
A: Yes. It stacks with other Catalyst 3850 switches using StackWise-480, which provides 480 Gbps of stacking bandwidth.
