Cisco

Cisco WS-C3850-24XS-S | Catalyst 3850 24-Port 10G SFP+ Switch, IP Base, 715W

SKU:WS-C3850-24XS-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 3850 24-port 10G SFP+ switch is a stackable 1 RU enterprise switch for campus access and aggregation. It suits converged wired and wireless access with an integrated wireless controller, branch aggregation of access switches over fibre links, and SD-Access fabric edge deployments with the appropriate DNA licence.

This SKU has 24 x 1/10G SFP+ ports, a default 715W AC power supply and the IP Base feature set. Switching capacity is 640 Gbps with a forwarding rate of 454.55 Mpps, and StackWise-480 stacking provides 480 Gbps of stacking bandwidth. It carries 4 GB of DRAM and 4 GB of flash, with room for optional uplink network modules. No PoE is provided on this model.

IP Base covers Layer 3 routed access, smart operations, Flexible NetFlow and wireless mobility agent and controller functions. A second power supply can be added for redundancy, and the switch works with the C3850-NM-4-10G, C3850-NM-8-10G and C3850-NM-2-40G uplink modules. Stacks must use matching feature sets.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Integrated wireless controller capability, with mobility agent and mobility controller modes
- Cisco StackWise-480 stacking with Stateful Switchover (SSO) resiliency
- Cisco StackPower power sharing and redundancy among stack members
- Modular, field-replaceable uplink network modules
- Dual redundant modular power supplies and three modular fans
- MACsec encryption, 128-bit on all models and 256-bit on SFP+ and Multigigabit models
- Flexible NetFlow for wired and wireless traffic visibility
- Modular QoS with hierarchical wireless bandwidth management
- Cisco Catalyst SmartOperations including Smart Install, Auto Smartports and Smart Troubleshooting
- Single universal Cisco IOS XE image across licence levels

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Ports: 24 x 1/10G SFP+
- Form factor: 1 RU, stackable
- Power supply: PWR-C1-715WAC (715 W, 100-240 VAC, 50-60 Hz)
- PoE: Not provided on this model
- Feature set: IP Base
- Switching capacity: 640 Gbps
- Forwarding rate: 454.55 Mpps
- Stacking bandwidth: 480 Gbps (StackWise-480)
- DRAM: 4 GB
- Flash: 4 GB
- MAC addresses: 32,000
- IPv4 routes (ARP plus learned routes): 24,000
- FNF entries: 48,000 flows
- VLAN IDs: 4,000
- Switched Virtual Interfaces: 1,000
- Jumbo frame: 9198 bytes
- Routed ports per stack: 208
- Wireless access points per switch or stack: 100
- Wireless clients per switch or stack: 2000
- WLANs per switch: 64
- Dimensions (H x W x D): 4.45 x 44.5 x 45.0 cm
- Weight: 6.1 kg
- MTBF: 307,990 hours
- Operating temperature (AC supply): -5 to +45 C up to 1500 m, -5 to +40 C up to 3000 m
- Storage temperature: -40 to 70 C
- Relative humidity: 10% to 95%, noncondensing

FAQs

Q: Which licence does this SKU ship with?
A: It ships with the IP Base feature set, shown by the -S suffix. IP Base includes Layer 3 routed access, smart operations, Flexible NetFlow and wireless mobility agent and controller functionality. IP Services can be added through an RTU licence such as L-C3850-24-S-E.

Q: Does it provide PoE?
A: No. This model does not supply PoE. It runs from a PWR-C1-715WAC power supply rated at 715 W.

Q: Can I add a second power supply for redundancy?
A: Yes. A second supply can be installed. Compatible options are PWR-C1-350WAC, PWR-C1-715WAC, PWR-C1-1100WAC and PWR-C1-440WDC.

Q: Which uplink modules does it support?
A: It supports the C3850-NM-4-10G, C3850-NM-8-10G and C3850-NM-2-40G uplink modules. The C3850-NM-4-1G and C3850-NM-2-10G modules are not supported on SFP+ models.

Q: How do I stack it with other Catalyst 3850 switches?
A: Use StackWise-480 cables such as STACK-T1-50CM, STACK-T1-1M or STACK-T1-3M, which give 480 Gbps of stacking bandwidth. StackPower cables CAB-SPWR-30CM and CAB-SPWR-150CM share power between members. All stack members must run the same feature set.
