• Cisco WS-C3850-24S-S 24-port 1G SFP fiber switch
1 1

Cisco

Cisco WS-C3850-24S-S | Catalyst 3850 24-Port Gigabit SFP Switch, IP Base

WS-C3850-24S-S

Stock Status: Enquire

Request Quote
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco Catalyst 3850-24S-S is a stackable Layer 3 enterprise access switch designed for converged wired and wireless networks. With 24 Gigabit Ethernet SFP ports and one hot-swappable network module slot for flexible uplinks, this switch delivers 92 Gbps switching capacity and StackWise-480 technology for high-availability deployments. The IP Base feature set provides comprehensive Layer 2 switching, up to 1000 VLANs, and entry-level Layer 3 routing capabilities including wireless controller functionality.

Features

IP Base feature set with Layer 2 and entry-level Layer 3 routing
- StackWise-480 technology with 480 Gbps stack bandwidth and stateful switchover (SSO)
- Cisco Unified Access Data Plane (UADP) ASIC for wired and wireless convergence
- Integrated wireless controller capability (Mobility Agent and Mobility Controller modes)
- Support for up to 100 Cisco Aironet access points and 2,000 wireless clients
- VLANs: 4,000 VLAN IDs with 1,000 active VLANs (IP Base)
- Advanced security: IEEE 802.1x, port security, DHCP snooping, Dynamic ARP Inspection, IP Source Guard, Control Plane Protection (CoPP)
- Quality of Service (QoS): 802.1p CoS, DSCP marking, Shaped Round Robin (SRR) scheduling
- Flexible NetFlow (FNF) Version 9 for traffic visibility
- Link aggregation: LACP (IEEE 802.3ad) and PAgP
- Spanning Tree: PVST+, Rapid PVST+, MSTP (802.1s)
- Hot-swappable network module and dual power supply support for high availability
- Field-replaceable fans and redundant power supplies
- IPv4 and IPv6 dual-stack support

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

24 x 1 Gigabit Ethernet SFP ports
- One hot-swappable network module slot for uplink expansion
- Switching capacity: 92 Gbps
- Forwarding rate: 68.4 Mpps
- Stacking bandwidth: 480 Gbps (StackWise-480)
- Memory: 4 GB DRAM, 2 GB Flash
- MAC address table: 32,000 entries
- IPv4 routes: 24,000
- Switched virtual interfaces (SVIs): 1,000
- VLAN support: 4,000 VLAN IDs, 1,000 active VLANs (IP Base)
- Jumbo frame support: 9,198 bytes
- Power supply: 350W AC (included), supports dual redundancy
- Dimensions (H x W x D): 1.75 x 17.5 x 17.7 inches (4.45 x 44.5 x 45.0 cm)
- Weight: 15.5 lbs (7.02 kg)
- Management: CLI, web GUI, SNMP, RMON, USB, mini-USB console
- Certifications: IEEE 802.3, 802.1Q, 802.1p, 802.1x, 802.1ab (LLDP)

FAQs

Q: What network modules are compatible with the WS-C3850-24S-S?
A: The WS-C3850-24S-S supports C3850-NM-4-10G (4x 10G SFP+), C3850-NM-8-10G (8x 10G SFP+), and C3850-NM-2-40G (2x 40G QSFP+) modules for high-speed uplinks. Note that C3850-NM-4-1G and C3850-NM-2-10G modules are not supported on 24-port SFP models.

Q: Can this switch operate as a wireless controller?
A: Yes, with the IP Base license, the WS-C3850-24S-S can operate as a Mobility Agent (default mode) to terminate CAPWAP tunnels from access points and support up to 100 access points and 2,000 wireless clients per switch. It can be configured as a Mobility Controller via CLI for additional wireless coordination functions.

Q: Can I stack this switch with other Catalyst 3850 models?
A: Yes, the WS-C3850-24S-S supports StackWise-480 for stacking up to 9 switches with 480 Gbps stack bandwidth. However, IP Base switches can only stack with other Catalyst 3850 IP Base switches; mixed stacking with LAN Base or IP Services models is not supported.

Q: What Layer 3 routing protocols are supported with IP Base?
A: IP Base provides entry-level Layer 3 routing including static routing, RIP, and routed access capabilities. For advanced routing protocols such as EIGRP, OSPF, BGP, and PIM, the IP Services feature set is required.

Q: Does this switch support Power over Ethernet?
A: No, the WS-C3850-24S-S does not support PoE. It has 24 SFP fiber ports without PoE capability. For PoE requirements, consider the WS-C3850-24P-S or WS-C3850-24U-S models.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
