Cisco

Cisco WS-C3850-24S-E | Catalyst 3850 24-Port SFP Switch, IP Services, 350W

SKU:WS-C3850-24S-E

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 3850 WS-C3850-24S-E is a stackable 1RU Layer 3 access and aggregation switch with 24 Gigabit Ethernet SFP downlinks. It suits campus and branch deployments that need fibre to the edge, including EMI-sensitive or secure environments, fibre aggregation of smaller access switches and converged wired and wireless access with an integrated wireless controller.

This SKU ships with the IP Services feature set, the highest tier, adding advanced Layer 3 IPv4 and IPv6 routing such as full OSPF, EIGRP, BGPv4, IS-IS, PIM, PBR and VRF-Lite. It delivers 92 Gbps switching capacity and a 68.4 Mpps forwarding rate, with 4 GB DRAM and 2 GB flash. StackWise-480 provides 480 Gbps of stacking bandwidth and StackPower enables power sharing between stack members. The integrated controller supports up to 100 access points and 2000 wireless clients. It is a non-PoE model with a 350W AC power supply (PWR-C1-350WAC) in a dual redundant modular PSU design.

Optional uplink network modules are C3850-NM-4-1G and C3850-NM-2-10G. It stacks only with other Catalyst 3850 switches running the same feature set.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Converged wired and wireless access with integrated wireless controller in mobility agent or controller mode
- Cisco StackWise-480 stacking and StackPower power sharing and redundancy
- Cisco UADP ASIC providing uniform wired and wireless policy, QoS and visibility
- IP Services Layer 3 routing including OSPF, EIGRP, BGPv4, IS-IS, PIM, IPv6 routing, PBR and VRF-Lite
- Security features including 802.1X, port security, DHCP snooping, DAI, IP Source Guard, CoPP and MACsec 128-bit
- Flexible NetFlow and hierarchical QoS with 8 wired egress queues per port
- Dual redundant modular power supplies and three field-replaceable fans
- Cisco Smart Install, Auto Smartports and Embedded Event Manager for simplified operations

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Model: WS-C3850-24S-E
- Downlink ports: 24 x SFP (1 Gigabit Ethernet)
- Feature set: IP Services
- Default power supply: PWR-C1-350WAC (350W AC)
- PoE: None (non-PoE model)
- Switching capacity: 92 Gbps
- Forwarding rate: 68.4 Mpps
- Stacking bandwidth: 480 Gbps (StackWise-480)
- StackPower: Supported
- MAC addresses: 32,000
- IPv4 routes (ARP plus learned): 24,000
- Flexible NetFlow entries: 24,000 flows
- DRAM: 4 GB
- Flash: 2 GB
- VLAN IDs: 4,000
- Switched Virtual Interfaces: 1,000
- Jumbo frame: 9198 bytes
- Wireless: up to 100 access points, 2000 clients, 64 WLANs, 20 Gbps per switch
- Dimensions (H x W x D): 4.45 x 44.5 x 45.0 cm (1 RU)
- Weight: 7.03 kg
- PSU input: 100-240 VAC, 50-60 Hz
- Maximum power draw: approx. 104 to 110 W depending on uplink module and traffic
- Operating temperature: -5 to +45 C up to 1500 m
- Storage temperature: -40 to 70 C
- MTBF: 300,760 hours

FAQs

Q: Which feature set does this SKU include and does it need a licence?
A: It ships with the IP Services feature set, the highest tier with advanced Layer 3 IPv4 and IPv6 routing. Feature sets are activated by Right-To-Use licensing on a single universal IOS XE image. A stack must use the same feature set on all members.

Q: Does this switch provide PoE?
A: No. This is a non-PoE SFP model with a 350W AC power supply (PWR-C1-350WAC) that powers the switch only. A second supply can be added for redundancy.

Q: Which uplink modules does it support?
A: It supports the C3850-NM-4-1G (4 x 1G SFP) and C3850-NM-2-10G (2 x 10G SFP+ and 4 x 1G SFP) network modules. The 4x10G, 8x10G and 2x40G modules are not supported on this model.

Q: Can it be stacked with other switches?
A: Yes, but only with other Catalyst 3850 switches running the same feature set, using StackWise-480 cables (STACK-T1-50CM=, 1M= or 3M=). StackPower cables are separate (CAB-SPWR-30CM= or 150CM=).

Q: How does it differ from other 24-port 3850 SKUs?
A: This model has 24 SFP downlink ports rather than copper, runs IP Services, and has no PoE. Copper and PoE variants and other feature sets are separate SKUs.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
