Cisco

Cisco WS-C3560X-24T-E | 24x 1G RJ45 (no PoE) | modular uplinks: 4x1G SFP or 2x10G SFP+ | IP Services

SKU:WS-C3560X-24T-E

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Enterprise fixed-access Layer 3 switch with 24 Gigabit copper ports and a modular uplink bay supporting either 4x 1G SFP or 2x 10G SFP+ (via optional network module). Ships with a 350W AC PSU in a 1RU chassis; supports a second hot-swap PSU and optional StackPower for power sharing. IP Services feature set enables advanced routing and policy features for campus distribution or small core roles.

Features

- 24x Gigabit copper access ports for high-density edge connectivity
- Modular uplink bay supports 4x1G SFP or 2x10G SFP+ for flexible aggregation
- IP Services image for advanced routing, segmentation, and policy control
- Optional StackPower to pool and share power across compatible switches
- Dual hot-swap PSU capability for power resiliency
- Comprehensive security and QoS for enterprise campus deployments

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: Does this unit include an uplink module?
A: No. Uplink modules are optional; it supports C3KX-NM-1G or C3KX-NM-10G depending on your 1G/10G needs.

Q: Can this model perform Layer 3 routing?
A: Yes. The IP Services feature set enables advanced L3 routing and policy features suitable for distribution roles.

Q: Does it support data stacking?
A: No. It does not support data stacking; it supports StackPower for power sharing when equipped with the StackPower cable.

Q: Can I add a second power supply for redundancy?
A: Yes. The chassis supports dual hot-swappable PSUs; one 350W AC PSU is included.

Q: Which optics are compatible for uplinks?
A: Standard 1G SFP and 10G SFP+ optics are supported when the corresponding C3KX uplink module is installed.

Technical Specifications

- Downlink ports: 24x 10/100/1000Base-T (RJ45, autosensing)
- PoE support: None (data-only)
- Uplink expansion: 1x network module bay
- Supported uplink modules: C3KX-NM-1G (4x 1G SFP), C3KX-NM-10G (2x 10G SFP+ + 2x 1G SFP)
- Software tier: IP Services (advanced Layer 3 features)
- Layer features: L2 switching, advanced L3 routing (e.g., OSPF/EIGRP/PBR), IPv6, ACLs, QoS
- Management: Console/SSH CLI, SNMP, RMON, NetFlow-Lite (where supported)
- Resiliency: Dual hot-swappable PSU support (1x 350W AC included), optional StackPower
- Form factor: 1RU rack-mount
- Operating modes: Mixed 1G downlinks with modular 1G/10G uplinks
- Security: 802.1X, DHCP snooping, DAI, IP Source Guard, port security
