• Cisco VEDGE-5000-AC-K9 SD-WAN router with ports and antennas
1 1

Cisco

Cisco VEDGE-5000-AC-K9 | vEdge 5000 SD-WAN Router, 4 NIM Slots, AC Power

VEDGE-5000-AC-K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The vEdge 5000 is a 1RU Viptela OS SD-WAN router from the Cisco SD-WAN vEdge range. It sits at the perimeter of a large branch, campus or data-centre site and forms a secure virtual overlay across any mix of WAN transports. It is the highest-density model in the vEdge range.

This AC-powered base chassis provides four Network Interface Module slots, 32 GB DDR4 memory and 120 GB of internal NAND storage. NIM options are 8 x 1GbE copper, 8 x 1GbE SFP or 4 x 10GbE SFP+, so the port mix can be matched to the site. NIMs are ordered separately. Power comes from hot-swappable AC supplies with redundancy support, rated for 100-240V input at up to 285W maximum consumption, and four hot-swappable fans cool the chassis with front-to-back airflow. A management Ethernet port, RJ-45 serial console and two USB 2.0 ports handle out-of-band access.

Compatible NIMs are NIM-8-1GE-RJ45, NIM-8-1GE-SFP and NIM-4-10GE-SFPP. The router is managed through Cisco SD-WAN vManage.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Runs Viptela OS with the same software functionality as all vEdge routers
- Routing support for OSPF, eBGP, iBGP, static routes and OMP
- Security features including zero-trust, DTLS/TLS, IPSec, DDoS and control plane protection
- QoS with classification, low latency queuing, shaping, policing and NAT/PAT
- Multicast support with IGMP v1/v2, PIM and Auto-RP
- Policy tools including app-aware routing, ACL policy and service insertion policy
- Management via Netconf over SSH, CLI, REST (vManage) and out-of-band ports
- AAA with TACACS+, RADIUS, local accounts and role-based access control

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Traffic ports: 4 x Network Interface Module (NIM) slots
- NIM options: 8 x 1GbE copper, 8 x 1GbE SFP, 4 x 10GbE SFP+
- Memory: 32 GB DDR4
- Internal storage: 120 GB NAND
- Management Ethernet: 1 x RJ-45 10/100/1000
- Serial console: 1 x RJ-45 (115.2 Kbps)
- USB host ports: 2 x USB 2.0 Type A
- PoE: Not supported
- Power supplies: Hot-swappable, redundancy supported
- AC input voltage: 90-264 Vrms (100-240V)
- AC input frequency: 47-63 Hz
- Power consumption: Max 285W
- Fans: 4 x hot-swappable
- Airflow: Front to back
- Form factor: 1RU rack-mount, 19-inch EIA rack-mount kit
- Chassis dimensions: 1.75 in. (4.4 cm) high, 438mm wide, 580mm deep
- Weight: 37 lbs with fans and power supplies installed
- Operating temperature: 0 to 40 C (32 to 104 F) at sea level
- Operating humidity: 10 to 85% RH
- Operating altitude: Max 3000 m (10000 ft)
- Storage temperature: -40 to 70 C (-40 to 158 F)
- MTBF: 178K hours
- Safety: AS/NZS 60950-1, CB-IEC60950-1, CE, EN 60950-1, UL60950-1
- EMC: Class A (AS/NZS CISPR 32, EN 55032, EN 55024, FCC Part 15)
- Environmental: RoHS

FAQs

Q: Which NIMs can be fitted to the four slots?
A: The NIM-8-1GE-RJ45 (8 x 1GE copper), NIM-8-1GE-SFP (8 x 1GE SFP) and NIM-4-10GE-SFPP (4 x 10GE SFP+) are the supported modules. Different NIM types can be mixed across the slots.

Q: How does this router differ from other vEdge models?
A: All vEdge routers run the same Viptela OS software. The vEdge 5000 is the highest-density model, with four NIM slots, hot-swappable AC power supplies with redundancy support and four hot-swappable fans.

Q: What power does the vEdge 5000 need?
A: It takes AC input of 90-264 Vrms (100-240V) at 47-63 Hz, with maximum consumption of 285W. It does not provide PoE.

Q: How is the vEdge 5000 managed?
A: It is managed through Cisco SD-WAN vManage, with CLI over SSH, Netconf and REST also available. A management Ethernet port and RJ-45 serial console support out-of-band access.

Q: Are the NIMs included in the base chassis?
A: No. This SKU is the base chassis only, and NIMs are ordered separately to suit the ports required at the site.
