• Cisco VEDGE-2000-AC-K9 SD-WAN router with ports and antennas
1 1

Cisco

Cisco VEDGE-2000-AC-K9 | vEdge 2000 SD-WAN Router, 4x 1G SFP, 2 PIM, AC

VEDGE-2000-AC-K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The vEdge 2000 is a 1RU Viptela OS SD-WAN router for large enterprise branch, campus and data-centre edge sites. It provides secure site-to-site connectivity over any mix of WAN transports within the Cisco SD-WAN overlay, and is managed through the SD-WAN fabric.

This AC router base chassis has four fixed 1GE SFP traffic ports and two Pluggable Interface Module (PIM) slots, which accept a 2 x 10GE SFP+ or an 8 x 1GE SFP module. A separate 10/100/1000 RJ-45 port handles management. It delivers 1 Gbps unidirectional IMIX forwarding throughput including encryption, with hardware-based IPSec crypto acceleration, 8 GB DDR3 ECC DRAM and 8 GB internal NAND.

Power comes from dual hot-swappable AC supply slots running in active-active redundancy on 100-240 V input, with typical consumption of 125 W. Front-to-back airflow and redundant hot-swappable fan trays suit rack deployments. It works with the PIM-2X10GE-SFP+ and PIM-8X1GE-SFP modules, and VIP-SFP-1GE-BASET, VIP-SFP-1GE-LX and VIP-SFP-1GE-SX pluggable SFPs.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Secure site-to-site connectivity with IPSec encryption and QoS
- Secure identification chip for anti-counterfeit protection and authentication
- Routing with OSPF, eBGP, iBGP, static routes and OMP
- Zero-trust security with DTLS/TLS, IPSec, DDoS and control-plane protection
- Management via vManage (REST), Netconf over SSH and CLI
- App-aware routing with control, data, ACL and VPN membership policies
- Multicast with IGMP v1/v2, PIM and Auto-RP
- Bridging with 802.1Q, bridge domains and IRB

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Fixed SFP traffic ports: 4 x 1GE
- PIM slots: 2 (2 x 10GE SFP+ or 8 x 1GE SFP modules)
- Management port: 1 x RJ-45 10/100/1000
- Console ports: 1 x USB Type B, 1 x RJ-45 serial (115.2 Kbps)
- Forwarding throughput: 1 Gbps unidirectional IMIX, including encryption
- Crypto: embedded hardware-based IPSec acceleration
- Memory: 8 GB DDR3 ECC DRAM
- Storage: 8 GB internal NAND
- USB: 2 x USB 3.0 Type A host ports
- SD card slot: external, up to 32 GB
- Power supply: dual hot-swappable AC slots, 1+1 active-active redundancy
- AC input: 90-264 Vrms (100-240 V), 47-63 Hz
- Typical power consumption: 125 W
- Fans: 2, hot-swappable
- Airflow: front to back
- Form factor: 1 RU, 17.25 in. wide chassis, 18.5 in. deep
- Weight: 11 lb chassis only, 15 lb with two power supplies
- Operating temperature: 0 to 40 C at sea level
- Operating humidity: 10 to 85% RH
- MTBF: 420K hours
- Safety: AS/NZS 60950-1, UL60950-1, CE Marking
- EMC: AS/NZS CISPR22 Class A, FCC Class A
- Environmental: RoHS

FAQs

Q: What software does the vEdge 2000 run?
A: It runs Viptela OS and is managed by the Cisco SD-WAN fabric through vManage, vSmart and vBond controllers.

Q: Which modules fit the PIM slots?
A: The two PIM slots accept the PIM-2X10GE-SFP+ (2 x 10GE SFP+) and PIM-8X1GE-SFP (8 x 1GE SFP) modules.

Q: Which SFPs work in the fixed 1GE ports?
A: The pluggable SFPs listed for this platform are VIP-SFP-1GE-BASET, VIP-SFP-1GE-LX and VIP-SFP-1GE-SX.

Q: What power does this AC model need?
A: It has dual hot-swappable AC power supply slots with active-active redundancy. Input is 100-240 V AC at 47-63 Hz, with typical consumption of 125 W.

Q: Can it be managed from a central controller?
A: Yes. It is managed through Cisco SD-WAN vManage, and also supports Netconf over SSH and CLI access.
