Cisco PWR-IE170W-PC-AC | IE Family 170W AC/High-DC DIN-Rail Power Supply, 54V

SKU:PWR-IE170W-PC-AC

Stock Status: Enquire

Request Quote

Sale Sold out

Shipping calculated at checkout.

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 170W DIN-rail power supply is designed for Cisco Industrial Ethernet switches and delivers 54VDC output to support PoE and PoE+ in hardwired installations. It accepts universal AC input (90-264V) or high-voltage DC input (106-300V), making it suited to industrial sites with mixed power sources. The extended operating range of -40°C to +75°C with no derating suits harsh environments, and it is the AC / high-DC input variant, as opposed to the low-voltage DC input model.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Supports PoE and PoE+ for compatible Cisco IE switches
- Hardwired DIN-rail mounting for industrial environments
- Accepts universal AC or high-voltage DC input
- Extended temperature range with no derating
- Over-temperature and short-circuit protection
- Can power four PoE or PoE+ ports on IE 2000U switches

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Output power: 170W
- Output: 54VDC, 3.2A
- Input: AC 100-240V, 2.3A, 50-60Hz, or DC 125-250V, 2.1A
- Operating input range: AC 90-264V or DC 106-300V
- Efficiency: 88%
- Inrush current: less than 35A at 115VAC and 70A at 230VAC
- Hold-up time: 20ms
- Protection: over-temperature and short circuit
- Ingress protection: IP20
- Operating temperature: -40°C to +75°C, no derating
- Storage temperature: -40°C to +85°C
- Humidity: less than 95% RH, non-condensing
- Dimensions: 96 x 150 x 146 mm
- Weight: 1.76 kg
- MTBF: 2,384,975 hours
- Approved for Class 1, Div 2/Zone 2 installations; CSA certified

FAQs

Q: What input voltages does this power supply accept?
A: It accepts AC 100-240V (operating range 90-264V) or high-voltage DC 125-250V (operating range 106-300V).

Q: How does it differ from the PWR-IE170W-PC-DC model?
A: This model takes AC or high-voltage DC input, while the PWR-IE170W-PC-DC variant takes low-voltage DC input of 10.8-60V. Both are 170W units with 54VDC output.

Q: Does it support PoE and PoE+?
A: Yes. The 54VDC output supports PoE and PoE+ on compatible Cisco Industrial Ethernet switches, and it can power four PoE or PoE+ ports on IE 2000U switches.

Q: What temperature range can it operate in?
A: It operates from -40°C to +75°C with no derating, and can be stored at -40°C to +85°C.

Q: How is it mounted?
A: It is a DIN-rail mounted unit measuring 96 x 150 x 146 mm and weighing 1.76 kg, with IP20 ingress protection.
