• Cisco Catalyst 3850 switch stack in N540-ACC-M chassis
1 1

Cisco

Cisco N540-ACC-M | NCS 540 24x 1/10G, 8x 25G, 2x 100G Router, Fixed 1RU

N540-ACC-M

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The NCS 540 N540-ACC-M is a 1RU fixed-chassis, temperature-hardened router from the Cisco Network Convergence System 540 medium-density family. It is built for service-provider converged access and aggregation, including mobile backhaul and fronthaul, business and residential services, and cell-site or cabinet deployments that need a low-power, hardened platform with precise timing.

The port layout combines 24x 1/10GE SFP+, 8x 1/10/25GE SFP28 and 2x 40/100GE QSFP28 ports, with forwarding performance of up to 300 Mpps. This variant is the 24x1/10GE + 8x10/25GE + 2x100GE fixed chassis (-M) with front-to-back airflow and modular AC/DC power supplies, supporting 1+1 power redundancy and 3+1 fan redundancy. It runs carrier-class Cisco IOS XR software and supports SyncE and PTP (Class B) with an internal GNSS receiver.

It works with the N540-PWR400-A (AC) and N540-PWR400-D (DC) power supplies, the N540-FAN fan module, and the N540-RCKMT-19, N540-RCKMT-23 and N540-RKMT-ETSI rack mounts. Software licensing is flexible consumption per 10G of capacity, as Access Essentials or Access Advantage.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Environmentally hardened for indoor or outdoor cabinet deployment
- Carrier-class Cisco IOS XR with programmability, automation and network visibility
- Layer 2 and Layer 3 services including VLAN/Q-in-Q, LAG/LACP, G.8032, VRF, OSPF, IS-IS, MP-BGP, BFD and VRRP
- MPLS, L2VPN/EVPN and Segment Routing (SR-MPLS, SRv6) with TI-LFA and Flex-Algo
- Precise frequency and phase/time synchronisation with SyncE and PTP
- Trust anchor hardware, secure boot, image signing and run-time defence
- MEF 3.0 compliant
- Zero-touch provisioning (ZTP) and third-party app hosting

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 24x 1GE/10GE SFP+
- Ports: 8x 1GE/10GE/25GE SFP28
- Ports: 2x 40GE/100GE QSFP28
- Forwarding performance: up to 300 Mpps
- CPU: 4-core 1.5 GHz x86
- Storage: 128 GB
- Form factor: 1RU fixed chassis, 26 cm depth
- Dimensions (H x W x D): 1.72 x 17.3 x 10.1 in
- Weight: 5.9 kg
- Power supplies: 2 hot-swappable AC/DC, 1+1 redundancy
- Fans: 4 modular fans, 3+1 redundancy
- Airflow: front-to-back
- Operating temperature: -40 to +70 C at 1,000 ft (I-Temp)
- Power consumption (NCS 540 family): minimum under 100 W, typical under 200 W, maximum 250 W
- Latency: typically under 10 us
- Timing: SyncE and PTP (Class B), internal GNSS receiver, 1pps, 10MHz and ToD interfaces
- Compliance: NEBS GR-63-CORE and GR-1089-CORE
- Software: Cisco IOS XR

FAQs

Q: Which power supplies and fan module does it use?
A: It uses the N540-PWR400-A (AC) or N540-PWR400-D (DC) hot-swappable power supplies in a 1+1 arrangement, and the N540-FAN module for 3+1 fan redundancy.

Q: How is software licensed?
A: NCS 540 uses flexible consumption licensing per 10G of capacity, as Access Essentials or Access Advantage, available as right-to-use or term-based subscriptions.

Q: Which rack mounts are compatible?
A: The N540-RCKMT-19, N540-RCKMT-23 and N540-RKMT-ETSI rack mounts are supported, along with the N540-CBL-GD-19 cable bracket.

Q: Can it be deployed outside a climate-controlled room?
A: Yes. It is rated I-Temp from -40 to +70 C at 1,000 ft and suits indoor or outdoor cabinet deployments.

Q: Does it support precise timing for mobile networks?
A: Yes. It supports SyncE and PTP to Class B with an internal GNSS receiver, plus 1pps, 10MHz and ToD interfaces.
