• Cisco N520-20G4Z-A router with 20x1G ports, 4x10G, and power supply
1 1

Cisco

Cisco N520-20G4Z-A | NCS 520 20x1G + 4x10G Router, Commercial Temp, AC

N520-20G4Z-A

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco NCS 520 is a fixed 1RU carrier Ethernet demarcation device built for service providers. It supports Layer 2 and Layer 3 services, is MEF 3.0 certified, and is designed for customer-located deployment of business Ethernet services, mobile backhaul and cloud access, with zero-touch provisioning for touchless rollout.

This N520-20G4Z-A model provides 24 ports: 4 x 1G copper RJ45, 16 x 1G SFP and 4 x 1/10G SFP+. It is the commercial-temperature, AC-powered variant with dual AC power supplies accepting 85 to 264 V AC, 4+1 fan redundancy and front-to-back airflow. Maximum input power for the 24-port chassis is 110 W. It runs Cisco IOS XE, with the Metro Access License as the base software and optional port upgrade licences, and supports Smart Licensing alongside PAK licensing.

It works with Cisco 100M/1G SFP and 10G SFP+ optics such as GLC-SX-MMD, GLC-LH-SMD, GLC-T, SFP-10G-SR and SFP-10G-LR, as well as SFP-H10GB-CU DAC cables and CWDM, DWDM and BiDi SFP+ modules. 19 in., 23 in. and ETSI rack mount kits are available.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- MEF 3.0 certified Carrier Ethernet services: E-Line, E-LAN, E-Tree, Access E-Line and Transit E-Line
- Zero-Touch Provisioning with a front-panel ZTP button
- Layer 3 routing including VRF Lite, OSPF, IS-IS, BGP, VRRP and HSRP, plus G.8032 ring protection and PVST/RPVST+
- Class-based 3-level hierarchical QoS with policing, shaping and deep packet buffers
- OAM and service assurance with 802.1ag CFM, Y.1731, Y.1564 and TWAMP responder
- Secure boot with signed image and Trust Anchor module, plus DHCP snooping, DAI, AAA/TACACS+ and SSH
- Management through CLI, SNMP, NETCONF/YANG, EPN-M and NSO
- NEBS Level 3 and ETSI compliance

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Product ID: N520-20G4Z-A
- 1G copper (RJ45) ports: 4
- 1G SFP ports: 16
- 1/10G SFP+ ports: 4
- Power supplies: dual AC
- AC input voltage: 85 to 264 V AC, nominal 100 to 240 V AC
- AC input frequency: 47 to 63 Hz, nominal 50 to 60 Hz
- Maximum input power (24-port): 110 W (375 BTU per hr)
- PoE: not supported
- Fan redundancy: 4+1 (5 integrated fans)
- Airflow: Front-to-back
- Form factor: 1 RU fixed
- Dimensions (H x W x D): 1.75 in. x 17.5 in. x 9 in.
- Weight (AC variant): 8.38 lb (3.8 kg)
- Operating temperature (commercial): 0 to 55 C up to 300 m; 0 to 50 C up to 1800 m; 0 to 40 C up to 4000 m
- Relative humidity: 5 to 95 percent, noncondensing
- Storage temperature: -40 to 70 C
- Chassis MTBF at 40 C: 371,000 hours
- Seismic: Zone 4
- Rack mounts: ETSI, 19 in. and 23 in. kits
- RoHS: RoHS 6
- Software: Cisco IOS XE

FAQs

Q: What software and licensing does the NCS 520 use?
A: It runs Cisco IOS XE. The base software is the Metro Access License (N520-S-M), with port upgrade licences available as N520-1G-8 and N520-10G-2. Smart Licensing is supported alongside PAK licensing.

Q: How is the N520-20G4Z-A powered?
A: It has dual AC power supplies accepting 85 to 264 V AC at 47 to 63 Hz. Maximum input power for the 24-port chassis is 110 W. It does not provide PoE.

Q: Which optics and cables does it work with?
A: It supports Cisco 100M/1G SFP and 10G SFP+ optics including GLC-SX-MMD, GLC-LH-SMD, GLC-T, SFP-10G-SR, SFP-10G-LR, SFP-10G-ER and SFP-10G-ZR. SFP-H10GB-CU1M/3M/5M DAC cables and CWDM, DWDM and BiDi SFP+ modules are also supported.

Q: What rack mounting options are available?
A: Compatible kits are N520-RCKMT-19-D3A for 19 in. racks, N520-RCKMT-23-D3A for 23 in. racks and N520-RMT-ETSI-D3A for ETSI racks. An N520-WALLMT wall mount is also available.

Q: How does this model differ from other NCS 520 variants?
A: The N520-20G4Z-A is the commercial-temperature, AC-powered model with 20 x 1G and 4 x 1/10G ports. It operates from 0 to 55 C, with temperature limits that reduce at higher altitude.
