• Black Cisco CX60 router with silver accents on ISR4451-X-AX/K9 SD-WAN model
1 1

Cisco

Cisco ISR4451-X-AX/K9 | ISR 4451-X Router, 4x GE, AX Bundle AppX + Security

ISR4451-X-AX/K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco ISR 4451-X is a modular branch-office Integrated Services Router in the Cisco 4000 Series, built on Cisco IOS XE with a multicore CPU architecture. It is designed for medium and large branch sites that need application-aware WAN edge routing, VPN security, voice and unified communications, WAAS and UCS E-Series server hosting, with room to grow through modular LAN and WAN slots.

This AX Bundle SKU pairs the ISR 4451-X platform with the Application Experience (AppX) and Security technology licences. The router supports concurrent services up to 2 Gbps, with a performance-on-demand upgrade available to double base forwarding throughput. It provides four onboard 10/100/1000 WAN/LAN ports that accept SFP or RJ-45, three NIM slots, two SM-X service-module slots (one doublewide capable) and one ISC slot. Default memory is 4 GB control-plane DRAM, upgradable to 16 GB, plus 2 GB data-plane DRAM and 8 GB flash, upgradable to 32 GB.

It runs a single Cisco IOS XE Universal image. The 2RU chassis includes 19-inch rack-mount hardware, uses an internal AC power supply, and can take an optional PoE or redundant power supply. Compatible modules include PVDM4 DSP modules in the ISC slot, NIM SSD/HDD modules and Cisco UCS E-Series modules.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Multicore CPU with separated control and data planes for consistent performance as services are added
- Single Cisco IOS XE Universal image with technology packages enabled via Right-to-Use licences
- Embedded hardware encryption acceleration for IPsec VPN, enabled with the Security licence
- Up to 10 Gbps module-to-module backplane bandwidth
- All four onboard GE ports support SFP or RJ-45 connections
- Online insertion and removal (OIR) for service modules and NIMs
- Support for Cisco UCS E-Series modules for hosting server applications
- Embedded management with EEM, IP SLAs, SNMP, RMON, syslog, NetFlow/IPFIX and onePK

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Onboard WAN/LAN ports: 4 x 10/100/1000 (RJ-45 or SFP)
- NIM slots: 3
- Enhanced service-module (SM-X) slots: 2, 1 doublewide capable
- Onboard ISC slot: 1
- System throughput: concurrent services up to 2 Gbps
- Control-plane DRAM: 4 GB default, 16 GB maximum
- Data-plane DRAM: 2 GB
- Flash memory: 8 GB default, 32 GB maximum
- USB 2.0 Type-A ports: 2
- Console ports: USB Type-B, serial console and serial auxiliary
- Power supply options: internal AC and PoE, with optional redundancy
- AC input voltage: 100 to 240 VAC autoranging, 47 to 63 Hz
- Typical power (no modules): 158 W
- Maximum power with AC power supply: 450 W (no PoE)
- Dimensions (H x W x D): 88.9 x 438.15 x 469.9 mm
- Rack height: 2RU, 19 in. rack-mount, 23 in. optional
- Weight with 450 W AC power supply (no modules): 13.1 kg
- Airflow: I/O side to bezel side
- Operating temperature (0 to 3000 m): 0 to 40 C
- Operating relative humidity: 5 to 85%
- Licensing: AX Bundle (AppX + Security licences)

FAQs

Q: Which licences does the AX Bundle include?
A: The AX Bundle SKU includes the Application Experience (AppX) and Security technology licences on top of the Cisco IOS XE Universal image. The Security licence enables the embedded IPsec hardware encryption acceleration.

Q: What throughput does the ISR 4451-X support?
A: It supports concurrent services up to 2 Gbps. A performance-on-demand licence upgrade is available to double the base forwarding throughput.

Q: What modules and optics work with the ISR 4451-X?
A: It has three NIM slots, two SM-X slots (one doublewide capable) and one ISC slot for PVDM4 DSP modules. It also supports Cisco UCS E-Series modules, NIM SSD/HDD modules and SFP optics on all four onboard Gigabit Ethernet ports.

Q: Can the ISR 4451-X supply PoE?
A: Yes, with the optional PoE power supply. It provides up to 500 W of endpoint PoE power with redundancy, or 950 W with PoE boost and no redundancy.

Q: Can the memory and flash be upgraded?
A: Yes. Control-plane DRAM ships at 4 GB and can be upgraded to 16 GB, and flash ships at 8 GB and can be upgraded to 32 GB.
