• Cisco ISR4321-V/K9 router, black with silver accents and vents
1 1

Cisco

Cisco ISR4321-V/K9 | ISR 4321 Router, 2x Gigabit, 2x NIM, Voice Bundle

ISR4321-V/K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ISR 4321 is a branch-office router from the Cisco ISR 4300 family, built for small and medium sites that need WAN edge routing with integrated voice. This ISR4321-V/K9 is the Voice bundle, aimed at sites running VoIP gateway, CUBE SIP trunking and Communications Express (CME) workloads, as well as SD-WAN branch connectivity.

It provides two onboard 10/100/1000 WAN/LAN ports, one of which is SFP-capable, two NIM slots and one onboard ISC slot for PVDM4 voice DSP modules. Aggregate throughput is 50 Mbps by default and can be raised to 100 Mbps with the Performance licence, while the Boost licence removes the cap. It ships with 4 GB DRAM and 4 GB flash, upgradable to 8 GB of each. The platform is 1 RU, runs Cisco IOS XE and supports Cisco Catalyst SD-WAN mode.

The -V/K9 suffix includes the Unified Communications technology package entitlement. IPsec VPN features need the Security licence, and CUBE sessions are licensed separately. The NIM slots support online insertion and removal, and LTE connectivity is available through optional cellular modules.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Multicore processors with an emulated Flow Processor for consistent performance as services are added
- Embedded IPsec VPN hardware acceleration, enabled with the Security licence
- Cisco Catalyst SD-WAN capable with IOS XE SD-WAN software
- Modular NIM slots with online insertion and removal
- Onboard ISC slot for PVDM4 high-density packet voice DSP modules
- Supports integrated IP PBX (CME) and Session Border Controller (CUBE)
- USB mini-B and RJ-45 console plus RJ-45 auxiliary port

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Onboard WAN/LAN ports: 2 x 10/100/1000 (2 RJ-45, 1 SFP-capable)
- NIM slots: 2
- SM-X slots: 0
- Onboard ISC slot: 1 (PVDM4 voice DSP)
- Aggregate throughput (default): 50 Mbps
- Aggregate throughput (Performance licence): 100 Mbps
- Aggregate CEF-only throughput (Boost licence): 1.5 Gbps
- Default memory: 4 GB DDR3 ECC DRAM
- Maximum memory: 8 GB
- Default flash: 4 GB
- Maximum flash: 8 GB
- USB: 1 x USB 2.0 type A
- Console: 1 x USB mini-B, 1 x RJ-45
- Auxiliary port: 1 x RJ-45
- AC input: 100 to 240 VAC autoranging, 47 to 63 Hz
- Typical power (no modules): 36 W
- Maximum power with AC power supply: 125 W
- Dimensions (H x W x D): 44.55 x 369.57 x 294.64 mm
- Rack height: 1 RU
- Weight (no modules): 3.5 kg plus 0.66 kg external power supply
- Airflow: right I/O side to left I/O side
- Operating temperature: 0 to 40 C
- MTBF: 593,270 hours

FAQs

Q: What does the -V/K9 suffix mean?
A: It denotes the Voice bundle, which includes the Unified Communications (UC) technology package entitlement. CUBE sessions are licensed separately.

Q: Can the 50 Mbps throughput limit be increased?
A: Yes. Aggregate throughput is 50 Mbps by default. The Performance licence raises it to 100 Mbps and the Boost licence removes the cap.

Q: Does it need a licence for IPsec VPN?
A: The IPsec VPN feature set needs the Security (SEC) licence. The router includes embedded hardware acceleration for IPsec once that licence is applied.

Q: Can I add LTE or other interfaces?
A: Yes. It has two NIM slots with online insertion and removal, and LTE is available through optional cellular modules. There are no SM-X slots.

Q: How much memory and flash can it take?
A: It has 4 GB DRAM and 4 GB flash by default, and both can be upgraded to a maximum of 8 GB.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

Download product manual
