• Cisco ISR4321-AXV/K9 black branch router with silver accents and vents
1 1

Cisco

Cisco ISR4321-AXV/K9 | ISR 4321 Router, 2x GE, APP + SEC + UC Licences

ISR4321-AXV/K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ISR 4321 AXV bundle is a branch-office router from the Cisco 4000 Series Integrated Services Routers (ISR 4300) family. It suits small to midsize branch offices that need secure WAN connectivity, SD-WAN, application services and integrated voice such as SIP trunking, IP PBX and session border control, all from one 1RU platform.

The AXV bundle pairs the ISR 4321 platform with the AppX (APP), Security (SEC) and Unified Communications (UC) technology-package licences. Onboard you get 2 x 10/100/1000 RJ-45 ports plus 1 SFP-based port, 2 NIM slots and 1 onboard ISC slot. Default aggregate throughput is 50 Mbps, with 100 Mbps available through the Performance licence and 1.5 Gbps CEF-only through the Boost licence. It ships with 4 GB DRAM and 4 GB flash, upgradeable to 8 GB of each. Power is an external AC supply, 100 to 240 VAC, with typical draw of 36 W and a 125 W maximum.

Cellular (LTE) connectivity is added through optional NIM modules, and an optional PoE AC power supply (PWR-4320-POE-AC) provides up to 120 W of endpoint PoE.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Supports Cisco Catalyst SD-WAN software features from the ISR 4000 family
- Embedded IPsec VPN hardware acceleration with WAN link security and VPN services under the Security licence
- Integrated voice gateway with SIP trunking, Cisco Unified Communications Express and Cisco Unified Border Element (CUBE) under the UC licence
- Modular NIM slots for WAN, LAN, voice and cellular interfaces with online insertion and removal
- Optional PoE power supply providing up to 30 W PoE+ on the built-in GE ports
- Software-upgradable throughput through Performance and Boost licences
- USB mini-B and RJ-45 serial console access

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Aggregate throughput (default): 50 Mbps
- Aggregate throughput (Performance licence): 100 Mbps
- Aggregate CEF-only throughput (Boost licence): 1.5 Gbps
- Onboard WAN/LAN 10/100/1000 ports: 2 (RJ-45)
- SFP-based ports: 1
- NIM slots: 2
- Enhanced service-module slots: 0
- Doublewide service-module slots: 0
- Onboard ISC slot: 1
- OIR (all I/O modules): Yes
- Default DRAM: 4 GB DDR3 ECC (8 GB maximum)
- Default flash memory: 4 GB (8 GB maximum)
- USB 2.0 slots (type A): 1
- USB console port (type B mini): 1
- Serial console and auxiliary ports (RJ45): 1 each
- Power supply: External AC, optional AC with PoE
- AC input: 100 to 240 VAC, 47 to 63 Hz
- Typical power (no modules): 36 W
- Maximum power (AC power supply): 125 W
- Maximum power (PoE power supply, platform only): 260 W
- Maximum endpoint PoE power: 120 W
- Dimensions (H x W x D): 44.55 x 369.57 x 294.64 mm
- Rack height: 1 RU, 19 in. EIA rack-mountable
- Wall-mount: Mounting holes under chassis
- Weight with AC PS (no modules): 3.5 kg plus 0.66 kg external PS
- Operating temperature: 0 to 40 C
- Operating relative humidity: 5% to 85%
- MTBF: 593,270 hours

FAQs

Q: Which licences does the AXV bundle include?
A: The AXV bundle includes the AppX (APP), Security (SEC) and Unified Communications (UC) technology-package licences on the ISR 4321 platform. Performance and Boost throughput licences are separate upgrades.

Q: What is the default throughput and how can it be increased?
A: Default aggregate throughput is 50 Mbps. The Performance licence raises it to 100 Mbps, and the Boost licence provides 1.5 Gbps CEF-only throughput.

Q: Can this router supply PoE to connected devices?
A: Yes, with the optional PoE AC power supply (PWR-4320-POE-AC), which provides up to 120 W of endpoint PoE. The standard external AC supply does not provide PoE.

Q: Can I add LTE or cellular connectivity?
A: Yes. Cellular connectivity is added through optional NIM modules fitted in the two NIM slots.

Q: Can the memory be upgraded?
A: Yes. DRAM can be upgraded to 8 GB using MEM-4320-4GU8G and flash to 8 GB using MEM-FLSH-4U8G.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
