Cisco

Cisco ISR4221-SEC/K9 | ISR 4221 Router, 2x 1G RJ45, 2x NIM, Security Bundle

ISR4221-SEC/K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ISR 4221 is a branch-office Integrated Services Router from the Cisco 4000 Series ISR family, supplied as the Security (SEC) bundle. It suits lean-IT sites that need WAN edge routing, secure VPN connectivity and Catalyst SD-WAN connectivity back to data centres and public cloud over MPLS, VPN and internet links.

The router provides two onboard 10/100/1000 RJ-45 WAN/LAN ports and one SFP-based port, plus two NIM slots for interfaces such as LTE, serial and T1/E1 modules. Aggregate throughput is 35 Mbps by default and up to 75 Mbps with the Performance licence, while CEF-only throughput can reach 1.2 Gbps with the Boost licence. It carries 4 GB of DDR3 ECC DRAM and 8 GB of flash. This SKU includes the Security (SEC) licence bundle with the IOS XE Security technology package, and embedded IPsec VPN hardware acceleration supports secure WAN links.

The NIM slots do not support SM-X service modules or online insertion and removal, so power down before changing modules. The 1RU chassis uses an external AC power supply (100-240 VAC), can be wall-mounted, and accepts an optional 19-inch rack-mount kit.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Supports Cisco Catalyst SD-WAN for application-aware routing across MPLS, VPN and internet links
- Embedded IPsec VPN hardware acceleration
- Includes the IOS XE Security licence bundle for WAN link security and VPN services
- Modular NIM slots for adding WAN/LAN interfaces such as LTE
- Throughput upgradable through Performance and Boost licences without a hardware change
- Services can be activated on demand through a licensing change
- Runs Cisco IOS XE software

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

- Onboard WAN/LAN ports: 2 x 10/100/1000 RJ-45
- SFP-based ports: 1
- NIM slots: 2
- Enhanced service-module slots: 0
- Aggregate throughput (default): 35 Mbps
- Aggregate throughput (Performance licence): 75 Mbps
- Aggregate CEF-only throughput (Boost licence): 1.2 Gbps
- DRAM: 4 GB DDR3 ECC (fixed)
- Flash: 8 GB (fixed)
- USB 2.0 type A: 1
- Console: 1 x RJ45 combo CON/AUX
- Power supply: external AC, 100-240 VAC, 47-63 Hz
- Power consumption: 24 W typical, 90 W maximum
- PoE support: No
- Dimensions (H x W x D): 43.7 x 322.6 x 254 mm
- Rack height: 1 RU
- Weight: 3.22 kg without modules
- Operating temperature: 0 to 40 C
- Operating relative humidity: 5% to 85%
- MTBF: 593,270 hours

FAQs

Q: What licence does this SKU include?
A: This is the Security (SEC) bundle, which includes the Cisco IOS XE Security technology package. Performance and Boost throughput licences are separate options.

Q: How can throughput be increased?
A: Aggregate throughput is 35 Mbps by default and rises to 75 Mbps with the Performance licence. The Boost licence raises CEF-only throughput up to 1.2 Gbps.

Q: What modules can it take?
A: It has two NIM slots for modules such as LTE, serial and T1/E1. SM-X service modules are not supported, and modules cannot be inserted or removed while powered.

Q: Does it support PoE or a redundant power supply?
A: No. It uses a single external AC power supply (100-240 VAC) and does not provide PoE or a redundant or DC power option.

Q: Can it be rack mounted?
A: Yes. It is a 1RU unit that fits a 19-inch rack with the optional rack-mount kit, and it can also be wall-mounted.
