Cisco C9130AXI-EWC-Z | Catalyst 9130AXI Wi-Fi 6 AP, Embedded Controller, Z

SKU:C9130AXI-EWC-Z

Stock Status: Enquire

$3,415.56 inc. GST

$3,105.05 ex. GST

Sale Sold out

Shipping calculated at checkout.

Condition New Used

Quantity

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9130AXI is an indoor Wi-Fi 6 (802.11ax) access point with internal antennas, delivering dual-band 2.4 GHz and 5 GHz coverage with PHY data rates up to 5.38 Gbps. This variant runs the Cisco Embedded Wireless Controller image, allowing small and distributed networks to manage up to 100 access points and 2000 clients without a separate physical controller. The multigigabit Ethernet uplink with UPOE support lets it use existing Cat 5e/6 cabling, and the Z suffix denotes the Z regulatory domain.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Cisco Embedded Wireless Controller manages the wireless LAN without a physical controller, suited to small and medium-sized businesses and distributed enterprises
- Wi-Fi 6 with uplink and downlink OFDMA and MU-MIMO, TWT and BSS colouring
- WPA3 support
- Multigigabit Ethernet uplink to use existing Cat 5e/6 cabling at up to 5 Gbps
- Cisco CleanAir and Flexible Radio Assignment (FRA)
- IoT ready with BLE and 802.15.4 support such as Zigbee
- FlexConnect deployment and Smart Licence enabled
- Management via Cisco DNA Center, integrated WebUI, mobile app and open-standards APIs
- Cisco Trust Anchor module and secure boot

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Wi-Fi 6 (802.11ax), dual-band 2.4 GHz and 5 GHz
- PHY data rates up to 5.38 Gbps
- 5 GHz flexible radio (single 8x8 or dual 4x4), 2.4 GHz 4x4 radio
- Internal antennas: 4 dBi peak gain on 2.4 GHz, 6 dBi peak gain on 5 GHz
- Uplink: 1x 100/1000/2500/5000 Mbps multigigabit Ethernet, UPOE supported
- 1x management port, 1x USB 2.0
- Dimensions: 22.6 x 22.6 x 4.8 cm (8.9 x 8.9 x 1.88 in), weight 3.2 lb
- Z regulatory domain: 2.412-2.462 GHz, 5.180-5.320 GHz, 5.500-5.700 GHz (excluding 5.600-5.640 GHz), 5.745-5.825 GHz
- Embedded Wireless Controller: up to 100 access points, 2000 clients and 16 WLANs
- Minimum software for EWC: Cisco IOS XE 16.12.2 or later

FAQs

Q: Does this access point need a separate wireless controller?
A: No. This variant runs the Cisco Embedded Wireless Controller image, so the access point itself acts as the controller for the wireless network.

Q: How many access points and clients can the embedded controller manage?
A: The Embedded Wireless Controller supports up to 100 access points, 2000 clients and 16 WLANs.

Q: Which access points can the Embedded Wireless Controller manage?
A: It can manage Catalyst 9100 series access points and Aironet 802.11ac Wave 2 access points, with the Aironet models in client serving mode only.

Q: What software version is required for the Embedded Wireless Controller?
A: The Embedded Wireless Controller requires Cisco IOS XE 16.12.2 or later.

Q: What does the Z suffix mean?
A: The Z suffix denotes the Z regulatory domain, which defines the permitted channels in the 2.4 GHz and 5 GHz bands for this model.
