Cisco C9130AXE-STA-Z | Catalyst 9130AXE Wi-Fi 6 Access Point, Stadium Antenna, -Z

Name: Cisco C9130AXE-STA-Z | Catalyst 9130AXE Wi-Fi 6 Access Point, Stadium Antenna, -Z
Brand: Cisco
SKU: C9130AXE-STA-Z
Price: 3586.31 AUD
Availability: BackOrder

SKU:C9130AXE-STA-Z

Stock Status: Enquire

$3,586.31 inc. GST

$3,260.28 ex. GST

Sale Sold out

Shipping calculated at checkout.

Quantity

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9130AXE Stadium Antenna bundle is a dual-band Wi-Fi 6 (802.11ax) indoor access point built for high-density, large open-area venues such as stadiums, arenas, auditoriums and convention centres. It pairs the 9130AXE with the C-ANT9104 stadium antenna for beam-steerable coverage and supports PHY data rates up to 5.38 Gbps across 2.4 GHz and 5 GHz. The -Z suffix is the regulatory domain covering Australia and New Zealand. A 5 Gbps Multigigabit Ethernet uplink, PoE+ or UPOE power and Catalyst 9800 controller support make it suited to demanding wireless deployments.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Wi-Fi 6 uplink/downlink MU-MIMO with up to eight spatial streams
- BSS coloring (spatial reuse) and Target Wake Time (TWT) power saving
- Cisco Flexible Radio Assignment (FRA) and CleanAir technology
- Integrated Bluetooth Low Energy/IoT radio
- Cisco RF ASIC for scanning and spectrum analysis
- Intelligent Capture with Cisco DNA Center
- WPA3 support
- Designed for high-density environments such as auditoriums, convention centres, arenas and stadiums
- Beam-steerable coverage via the C-ANT9104 stadium antenna

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Wi-Fi 6 (802.11ax), dual-band 2.4 GHz and 5 GHz
- 4x4:4 on 2.4 GHz and 8x8 on 5 GHz (or dual 4x4 on 5 GHz)
- PHY data rates up to 5.38 Gbps
- 1 x 100/1000/2500/5000 Multigigabit Ethernet (RJ-45)
- Management console port (RJ-45)
- USB 2.0 at 4.5W
- PoE: 802.3at (PoE+) or 802.3bt (Cisco UPOE)
- Smart antenna connector (8-DART) with Self-Identifiable Antenna (SIA) support
- Certified for external antenna gains up to 13 dBi on 2.4 GHz and 5 GHz
- Dimensions: 18.2 x 23.5 x 5.8 in (59.70 x 46.23 x 14.8 cm)
- Weight: 15.5 lb (7.03 kg)
- Software: Cisco IOS XE 17.6.1 or later for the stadium antenna AP
- Operating temperature range from -4 to 122°F (-20 to 50°C)
- Includes C-ANT9104 stadium antenna, -Z regulatory domain (Australia/New Zealand)

FAQs

Q: What does the -Z suffix mean on this access point?
A: The -Z suffix is the regulatory domain covering Australia and New Zealand, so this bundle is configured for deployment in those regions.

Q: What antenna is included in this bundle?
A: This bundle pairs the Catalyst 9130AXE with the C-ANT9104 stadium antenna, which provides beam-steerable coverage for high-density, large open-area venues.

Q: Which wireless controllers are supported?
A: The access point works with the Catalyst 9800 Series, and with Cisco 3504, 5520, 8540 and Virtual Wireless Controllers.

Q: How is the access point powered?
A: It can be powered over Ethernet using 802.3at (PoE+) or 802.3bt (Cisco UPOE).

Q: What software version is required?
A: The stadium antenna access point requires Cisco IOS XE 17.6.1 or later.
