Cisco C9120AXE-Z | Catalyst 9120AXE Wi-Fi 6 Access Point, External Antennas, Z Domain

Name: Cisco C9120AXE-Z | Catalyst 9120AXE Wi-Fi 6 Access Point, External Antennas, Z Domain
Brand: Cisco
SKU: C9120AXE-Z
Price: 1096.00 AUD
Availability: InStock

SKU:C9120AXE-Z

2 in stock

$1,096.00 inc. GST

$996.36 ex. GST

Sale Sold out

Shipping calculated at checkout.

Quantity

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9120AXE is an indoor Wi-Fi 6 (802.11ax) enterprise access point with a 4x4:4 MIMO design and external antenna connectors, suited to challenging RF environments such as warehouses and high-ceiling spaces. It combines dual-band 2.4 GHz and 5 GHz radios with a 2.5G Multigigabit uplink, an integrated Bluetooth 5 IoT radio and a USB port. This C9120AXE-Z variant uses external antennas and is built for the Z regulatory domain.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Flexible Radio Assignment selects 2.4/5 GHz or dual 5 GHz operation based on the RF environment
- Uplink and downlink OFDMA, Target Wake Time and BSS colouring
- Multigigabit Ethernet uplink up to 2.5 Gbps over Cat 5e cabling
- Bluetooth 5 radio for IoT use cases such as location tracking and wayfinding
- Container support for edge computing and IoT applications on the host access point
- Cisco RF ASIC (software-defined radio) providing CleanAir, WIPS and DFS detection
- Smart Antenna Connector for the compact multi-RF DART, which requires the AIR-CAB002-DART-R= cable
- Works with Catalyst 9800, 3500, 5520 and 8540 Series controllers and the Virtual Wireless Controller

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Wi-Fi 6 (802.11ax), backward compatible with 802.11a/b/g/n/ac
- 4x4 MU-MIMO with four spatial streams
- Dual-band 2.4 GHz and 5 GHz radios, with Flexible Radio Assignment allowing dual 5 GHz mode
- Maximum PHY data rate of 5.38 Gbps (160 MHz on 5 GHz, 20 MHz on 2.4 GHz)
- External antennas (sold separately), certified for gains up to 6 dBi on 2.4 GHz and 5 GHz
- 1x 100/1000/2500 Multigigabit Ethernet uplink (RJ-45, 802.3bz)
- Management console port (RJ-45)
- USB 2.0 port at 3.75W (enabled via future software)
- Integrated Bluetooth Low Energy 5 radio
- PoE: 802.3at (PoE+) draws up to 25.5W for full functionality; 802.3af draws 13.4W with reduced performance
- 2048 MB DRAM and 1024 MB flash
- Operating temperature -20 to 50°C (-4 to 122°F), humidity 10-90% non-condensing
- Dimensions 8.5 x 8.05 x 2.0 in (21.6 x 21.6 cm), excluding mounting brackets
- Z regulatory domain

FAQs

Q: Are antennas included with the C9120AXE-Z?
A: No. The C9120AXE uses external antennas that are sold separately. The access point is certified for external antennas with gains up to 6 dBi on both 2.4 GHz and 5 GHz.

Q: What does the Z suffix mean?
A: The Z suffix indicates the Z regulatory domain. The same hardware is offered in other regulatory domains under different SKUs, so confirm the domain suits your deployment country.

Q: How should the C9120AXE be powered?
A: It runs on 802.3at (PoE+), drawing up to 25.5W for full functionality. It can also operate on 802.3af at 13.4W, but with reduced performance.

Q: Which wireless controllers does it work with?
A: Supported controllers include the Catalyst 9800, 3500, 5520 and 8540 Series, as well as the Virtual Wireless Controller.

Q: What uplink speeds does the Ethernet port support?
A: The single RJ-45 port supports 100 Mbps, 1 Gbps and 2.5 Gbps Multigigabit (802.3bz), so 2.5 Gbps can be achieved over existing Cat 5e cabling.
