Cisco C9120AXE-EWC-Z | Catalyst 9120AXE Wi-Fi 6 Access Point, Embedded Controller, Z Domain

Name: Cisco C9120AXE-EWC-Z | Catalyst 9120AXE Wi-Fi 6 Access Point, Embedded Controller, Z Domain
Brand: Cisco
SKU: C9120AXE-EWC-Z
Price: 2916.82 AUD
Availability: BackOrder

SKU:C9120AXE-EWC-Z

Stock Status: Enquire

$2,916.82 inc. GST

$2,651.65 ex. GST

Sale Sold out

Shipping calculated at checkout.

Quantity

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 9120AXE is an indoor Wi-Fi 6 (802.11ax) dual-band access point with external antennas, designed for challenging environments. This SKU ships with the Cisco Embedded Wireless Controller software image, so a separate controller appliance is not needed to manage the wireless network. It is the Z regulatory domain variant, with 4x4 MIMO, a 2.5 Gbps Multigigabit Ethernet uplink and an integrated Bluetooth Low Energy 5 radio for IoT use cases.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Uplink and downlink OFDMA scheduling
- MU-MIMO with four spatial streams
- Cisco CleanAir with 160 MHz channel support
- Built-in controller with no physical appliance and no added footprint
- Easy migration path to Catalyst 9800 Series controllers
- Bluetooth Low Energy 5 for IoT use cases such as location tracking and wayfinding
- Supports both embedded wireless controller and lightweight (controller-based) deployments

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- Wi-Fi 6 (802.11ax), dual-band 2.4 GHz / 5 GHz
- 4x4 MIMO with four spatial streams
- Four radios: 4x4 XOR radio for 2.4 or 5 GHz, single-band 4x4 5 GHz radio, 2.4 GHz IoT/BLE radio, auxiliary radio
- Dual 5 GHz radio support, up to 5.2 Gbps (2 x 2.6 Gbps) over the air
- Multigigabit Ethernet uplink: 2.5 Gbps, plus 100 Mbps and 1 Gbps
- Integrated Bluetooth Low Energy 5 radio
- External antennas (RP-TNC connectors) plus smart antenna connector
- USB 2.0 port
- Embedded Wireless Controller image based on Catalyst 9800 code (minimum IOS XE 16.12.2)
- Z regulatory domain

FAQs

Q: Does this access point need a separate wireless controller?
A: No. It ships with the Cisco Embedded Wireless Controller image, which is based on Catalyst 9800 code, so the access point can run the controller function itself with no separate appliance.

Q: Does it use internal or external antennas?
A: It uses external antennas via RP-TNC connectors, and also includes a smart antenna connector. This makes it well suited to challenging indoor environments.

Q: What does the Z domain designation mean?
A: Z refers to the regulatory domain this SKU is built for. It is one of several regional variants of the Catalyst 9120AXE, so confirm the domain suits your deployment location.

Q: Can it later be moved to a controller-based deployment?
A: Yes. The access point supports both embedded wireless controller and lightweight controller-based deployments, with an easy migration path to Catalyst 9800 Series controllers.

Q: What uplink speeds are supported?
A: The Multigigabit Ethernet uplink supports 2.5 Gbps, as well as 1 Gbps and 100 Mbps, to suit a range of switch port types.
