• Cisco C8300-2N2S-4T2X SD-WAN edge router with 4x 1G RJ45 ports
1 1

Cisco

Cisco C8300-2N2S-4T2X | Catalyst 8300 Router, 2RU, 2x 10G SFP+, 2 SM + 2 NIM

C8300-2N2S-4T2X

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Catalyst 8300 is a 2RU edge router built for medium and large branch offices and regional sites that need high-throughput encrypted WAN connectivity. It suits Catalyst SD-WAN or SD-Routing deployments with integrated security, cloud and internet access, unified communications and container-hosted services.

This 2N2S-4T2X variant gives you 2 x 10 Gigabit Ethernet SFP+ and 4 x 1 Gigabit Ethernet RJ-45 embedded Layer 3 ports, plus 2 SM slots, 2 NIM slots and 1 PIM slot for WAN and service modules. The 12-core platform ships with 8 GB DRAM (upgradeable to 16 or 32 GB) and 16 GB M.2 USB storage. IPv4 forwarding reaches up to 19.7 Gbps and IPsec throughput up to 18.9 Gbps with 1400 byte packets, or 9.3 Gbps IMIX. Dual power supplies are standard.

Catalyst 8300 platforms use a Cisco DNA Software subscription with Cisco Smart Licensing, and the tier is selected at order time. The router requires Cisco IOS XE 17.3.2 or later and works with Cisco SM and NIM modules.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Dynamic core allocation between service-oriented mode (up to 5 cores for KVM and Docker containers) and data-plane-heavy mode
- Embedded IPsec VPN hardware acceleration plus SSL and crypto acceleration
- Six built-in Layer 3 Ethernet ports, with 2 SFP/SFP+ capable ports for fibre or copper connectivity
- Modular SM, NIM and PIM slots for WAN, voice and service modules
- Integrated security including NGFW with application awareness, IPS/IDS, AMP, URL filtering and Umbrella SIG (SASE)
- Hardware-anchored Secure Boot and SUDI for Plug and Play provisioning
- Supports Catalyst SD-WAN and SD-Routing, managed via Catalyst SD-WAN Manager or Cisco DNA Center
- Unified communications support including CUBE, SRST, CUCME and voice modules

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Model: C8300-2N2S-4T2X
- Chassis: 2RU
- 10G ports: 2 x 10 Gigabit Ethernet SFP+ embedded Layer 3
- 1G ports: 4 x 1 Gigabit Ethernet RJ-45 embedded Layer 3
- Slots: 2 SM, 2 NIM, 1 PIM
- Processor: 12-core platform
- DRAM: 8 GB default, upgradeable to 16 GB and 32 GB
- Onboard flash: 8 GB, not upgradeable
- M.2 storage: 16 GB default, upgradeable to 32 GB M.2 USB, or 600 GB / 2 TB M.2 NVMe
- IPv4 forwarding throughput (1400B): up to 19.7 Gbps
- IPsec throughput (1400B): up to 18.9 Gbps
- IPsec throughput (IMIX): 9.3 Gbps
- SD-WAN IPsec throughput (1400B): up to 18.8 Gbps
- SD-WAN IPsec throughput (IMIX): 7.6 Gbps
- SD-WAN overlay tunnels: 6000
- IPsec SVTI tunnels: 4000
- Firewall sessions: 512K
- NAT sessions: 1.2M with default 8 GB, up to 2M with 32 GB
- IPv4 routes: 1.6M with default 8 GB, up to 4M with 32 GB
- VRFs: 4000
- Typical power (no modules, single PSU): 275 W
- Input voltage: AC 85 to 264 VAC, DC -40 to 72 V
- Dimensions (H x W x D): 3.5 in. x 17.25 in. x 18.52 in.
- Operating temperature: 0 to 40 C
- Minimum software: Cisco IOS XE 17.3.2

FAQs

Q: Does the C8300-2N2S-4T2X need a licence or subscription?
A: Catalyst 8300 platforms are sold with a Cisco DNA Software subscription, Enterprise Agreement or MSLA, using Cisco Smart Licensing with a Smart Account. Tiers include Catalyst Routing Essentials, Cisco DNA Essentials and Cisco DNA Advantage, chosen at order time rather than fixed by the hardware SKU.

Q: Which power supplies does the 2RU Catalyst 8300 use?
A: The 2RU chassis uses PWR-CC1-650WAC (650 W), PWR-CC1-1000WAC (1000 W, 500 W PoE budget), PWR-CC1-650WDC (650 W DC) or PWR-CC1-650WDCR (650 W DC, NEBS reversed airflow). At least one PoE-capable supply is needed to enable PoE on NIM and SM modules.

Q: Which modules does it work with?
A: It accepts Cisco SM and NIM modules plus one PIM slot, as listed in the Cisco Catalyst 8000 WAN module data sheets. DRAM can be upgraded to 16 or 32 GB, and storage can be M.2 USB or M.2 NVMe. Optics are listed in the Cisco TMG Compatibility Matrix.

Q: What software release does it require?
A: The C8300-2N2S-4T2X requires Cisco IOS XE 17.3.2 or later. It supports both Catalyst SD-WAN and SD-Routing operation.

Q: How does this model differ from other Catalyst 8300 variants?
A: This variant is the 2RU 2N2S-4T2X model with 2 SM slots, 2 NIM slots, 2 x 10GE SFP+ and 4 x 1GE RJ-45 ports, giving it a 10G WAN capable edge design.
