• Back side of a cisco c8225-g2 8200 router 8-port gigabit 2x 10g sfp+ module with ethernet ports and ventilation grille
1 1

Cisco

Cisco C8225-G2 | 8200 Secure Router, 8x 1G RJ45, 2x 10G SFP+, 16GB

C8225-G2

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco 8200 Series C8225-G2 is a fanless secure router built for medium-sized branch WAN edge deployments. It combines routing, SD-WAN and next-generation firewall security on a dedicated secure networking processor, and its quiet desktop design suits noise-sensitive or space-constrained sites.

This SKU provides 8x 1GE RJ-45 ports plus 2x 1/10GE SFP+ ports, backed by 16 GB DRAM and 16 GB storage. Of the RJ-45 ports, 2 are WAN-capable, 2 are flex and 4 are LAN, while the SFP+ ports can also be used for WAN uplinks. Forwarding throughput is 19 Gbps (512B), IPsec throughput is 5 Gbps, SD-WAN throughput is 4 Gbps and threat protection throughput is 2.4 Gbps. It supports up to 2500 IPsec tunnels on IOS XE 26.2.1 and later. The 16 GB memory distinguishes it from the 8 GB C8221-G2 that shares the same chassis. Power comes from a 66W AC external adapter with dual power inputs for redundancy, drawing a typical 21 W.

It runs Cisco IOS XE 26.1.2 or later and is managed through Cisco Catalyst SD-WAN Manager. The SFP+ ports accept SFP and SFP+ optics, and the unit can be rack-mounted in a tray that holds the power supply (2RU).

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Dedicated secure networking processor for hardware-accelerated cryptography and deep packet inspection
- Fanless design with fewer moving parts for quiet, space-constrained branch sites
- Integrated NGFW security, routing and SD-WAN on one platform
- Post-Quantum Cryptography (PQC) readiness for quantum-resistant encryption
- On-premises, infrastructure-as-code or cloud management via Cisco Catalyst SD-WAN Manager
- Dual power supply inputs for power redundancy
- Sustainability features including auto-off ports and LEDs, bezel-free design and powder-coat finish

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- WAN ports: 2x 1/10 GE SFP+, 2x 1 GE RJ-45
- Flex ports: 2x 1 GE RJ-45
- LAN ports: 4x 1 GE RJ-45
- Cellular slot: None
- Management port: 1x RJ-45 OOB management
- Console port: 1x RJ-45
- USB: 1x USB 3.0 Type-C storage
- DRAM: 16 GB
- Storage: 16 GB
- Forwarding throughput (512B): 19 Gbps
- IPsec throughput (512B): 5 Gbps
- SD-WAN throughput (512B): 4 Gbps
- Threat protection throughput (EMIX): 2.4 Gbps
- IPv4/IPv6 routes: 1.5M
- IPsec tunnels: up to 2500 (IOS XE 26.2.1 and later), up to 700 prior
- IPv4 ACLs: 3000
- IPv4 ACEs: 15,000
- NAT sessions: 1.5M
- VRF instances: 4000
- Power supply: 66W AC external adapter, secondary PSU option
- Typical power consumption: 21 W
- Input voltage: 85 to 264 VAC
- Dimensions (H x D x W): 4.09 x 21.59 x 32.26 cm
- Chassis weight: 2.27 kg
- Operating temperature: 0 to 45 C at sea level (0 to 40 C with dust/liquid cover)
- Minimum software: IOS XE 26.1.2 and SD-WAN Release 26.1.2

FAQs

Q: What software and management platform does it require?
A: It runs Cisco IOS XE 26.1.2 or later and is managed with Cisco Catalyst SD-WAN Manager release 26.1.2 or later for SD-WAN operation.

Q: Does it provide PoE?
A: No. The C8225-G2 has no PoE budget. It is powered by a 66W AC external adapter with a secondary PSU option for redundancy.

Q: Does it have a module or cellular slot?
A: No. This model has fixed ports only, with no NIM, PIM or cellular slot.

Q: What optics do the SFP+ ports take?
A: The 2x 1/10GE SFP+ ports accept SFP and SFP+ optics, and can be used as WAN uplinks.

Q: How does it differ from the C8221-G2?
A: The C8225-G2 has 16 GB DRAM, while the C8221-G2 shares the same chassis with 8 GB. The C8225-G2 offers 8x 1GE RJ-45 plus 2x 1/10GE SFP+ ports.

Q: Can it be rack-mounted?
A: Yes. It is a desktop unit that can be rack-mounted using a tray that holds the power supply, occupying 2RU.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .
