• Silver cisco c8221l-g2 8200 series 10-port gigabit router with 2x 10g rj45 and ventilation grille back view
1 1

Cisco

Cisco C8221L-G2 | 8200 Router, 2x 10G RJ45, 8x 1G RJ45, 8 GB DRAM

C8221L-G2

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The C8221L-G2 is a secure router from the Cisco 8200 Series, built for medium-sized branch WAN edge deployments. It combines routing, SD-WAN and NGFW-class security on a dedicated secure networking processor, in a compact desktop form factor that can also be rack mounted.

Connectivity is two 10 GE RJ-45 WAN ports alongside eight 1 GE RJ-45 ports, with a separate RJ-45 out-of-band management port, an RJ-45 console port and a USB 3.0 Type-C storage port. This SKU carries 8 GB DRAM and 16 GB storage. Quoted throughput at 512B is 19 Gbps forwarding, 5 Gbps IPsec and 4 Gbps SD-WAN, with 1 Gbps threat protection throughput using EMIX traffic. It scales to 1.5M IPv4/IPv6 routes, 1.5M NAT sessions and 4000 VRF instances.

Power comes from a 66W AC external adapter with a typical draw of 21 W. A second power supply input is available for redundancy. There is no cellular or NIM slot and no PoE. The router requires IOS XE Release 26.1.2 or later, and SD-WAN operation uses Cisco Catalyst SD-WAN Manager Release 26.1.2 or later.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Dedicated secure networking processor for hardware-accelerated cryptography and deep packet inspection
- Integrated NGFW security, routing and SD-WAN in one unified platform
- Post-Quantum Cryptography (PQC) readiness
- Managed on-premises, through infrastructure-as-code or from the cloud
- Energy management features including auto-off for ports without an SFP and auto-off port LEDs
- Energy Management dashboard in Cisco Catalyst SD-WAN Manager
- Dual power supply inputs for redundancy
- Bezel-free, powder-coat design built from standard subassemblies

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

- WAN ports: 2x 10 GE RJ-45, 2x 1 GE RJ-45
- Flex ports: 2x 1 GE RJ-45
- LAN ports: 4x 1 GE RJ-45
- Cellular slot: None
- Management port: 1x RJ-45 out-of-band management
- Console port: 1x RJ-45
- USB: 1x USB 3.0 Type-C storage
- DRAM: 8 GB
- Storage: 16 GB
- Forwarding throughput (512B): 19 Gbps
- IPsec throughput (512B): 5 Gbps
- SD-WAN throughput (512B): 4 Gbps
- Threat protection throughput (EMIX): 1 Gbps
- IPv4/IPv6 routes: 1.5M
- IPsec tunnels: Up to 1500 (IOS XE 26.2.1 and later), up to 700 (prior to IOS XE 26.2.1)
- IPv4 ACLs: 3000
- IPv4 ACEs: 15,000
- NAT sessions: 1.5M
- VRF instances: 4000
- Power supply: 66W AC external adapter, dual power supply inputs
- Typical power consumption: 21 W
- Input voltage: 85 to 264 VAC
- Dimensions (H x D x W): 1.61 x 8.5 x 12.7 in. (4.09 x 21.59 x 32.26 cm)
- Chassis weight: 5 lb (2.27 kg)
- Form factor: Desktop (2RU when rack mounted)
- Operating temperature: 0 to 45 C at sea level, 0 to 40 C with dust/liquid cover
- Storage temperature: -40 to 70 C
- Minimum software: IOS XE Release 26.1.2 and later

FAQs

Q: Does this router support SD-WAN?
A: Yes. It supports Cisco Catalyst SD-WAN operation and is managed through Cisco Catalyst SD-WAN Manager Release 26.1.2 or later. It requires IOS XE Release 26.1.2 or later.

Q: Does the C8221L-G2 provide PoE or a cellular slot?
A: No. This SKU has no PoE and no NIM or cellular slot. Connectivity is limited to its fixed 10 GE and 1 GE RJ-45 ports.

Q: What power supply does it use and can it be made redundant?
A: It uses a 66W AC external adapter with an input range of 85 to 264 VAC, and typical consumption is 21 W. It has dual power supply inputs, so a second 66W AC adapter can be added for redundancy.

Q: How is it mounted?
A: It is a desktop unit and can also be rack mounted using a rack-mount tray, where it occupies 2RU. The tray version measures 2.835 x 12 x 17.56 in.

Q: What is the memory and storage on this SKU?
A: It has 8 GB DRAM and 16 GB storage, which is the variant detail separating it from other 8200 Series models.
