• Cisco 3945 VSEC CUBE router with silver accents and sleek design
1 1

Cisco

Cisco C3945-VSEC-CUBE/K9 | 3945 Router, PVDM3-64, UC and SEC, CUBE-25

C3945-VSEC-CUBE/K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco 3945 is a Cisco 3900 Series Integrated Services Router (ISR G2) supplied as a secure voice bundle. It suits branch and regional sites that need a voice gateway, SIP trunking with session border control, and encrypted voice, with voice and video conferencing and transcoding handled by onboard DSPs.

This bundle pairs the C3900-SPE150/K9 Services Performance Engine with a PVDM3-64 64-channel DSP module, the Unified Communications and Security (SEC) licence PAK, and the FL-CUBEE-25 licence for 25 Cisco Unified Border Element sessions. The chassis provides 3 onboard 10/100/1000 WAN/LAN ports, with SFP support on two of them, 4 EHWIC slots, 4 onboard PVDM3 DSP slots, 4 service-module slots and 1 ISM slot. It supports up to 1200 Cisco Unified SRST sessions and includes embedded hardware IPsec and SSL crypto acceleration. Memory defaults to 1 GB DRAM (2 GB maximum) with 256 MB external Compact Flash (4 GB maximum per slot).

The router is 3RU and rack-mountable in 19 inch EIA or 23 inch racks, with an internal AC supply and PoE and DC options on the 3945 platform. It runs Cisco IOS with the IP Base image, and the included licence PAK activates the UC and SEC feature sets. Additional CUBE sessions are available as stackable licences.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- PVDM3-64 DSP module for voice conferencing, transcoding and voice termination
- UC and SEC licence PAK for Unified Communications and security feature sets
- Cisco Unified Border Element for 25 sessions, with SIP and H.323 trunk interworking
- Embedded hardware IPsec and SSL crypto acceleration
- Supports Cisco Unified Communications Manager Express and Survivable Remote Site Telephony (SRST)
- Modular design with EHWIC, PVDM3, service-module and ISM slots
- Field-replaceable Services Performance Engine
- Integrated 802.3af PoE power distribution to modules

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Platform: Cisco 3945 with C3900-SPE150/K9 Services Performance Engine
- Onboard WAN/LAN 10/100/1000 ports: 3
- SFP-based ports: 2 (each disables one RJ-45 port)
- DSP module: PVDM3-64 (64-channel)
- CUBE licence: FL-CUBEE-25, 25 sessions
- Licence PAK: Unified Communications and Security (SEC)
- EHWIC slots: 4 (2 doublewide)
- Onboard DSP (PVDM3) slots: 4
- Service-module slots: 4 (1 doublewide)
- ISM slots: 1
- Cisco Unified SRST sessions: up to 1200
- DRAM (ECC DDR2): 1 GB default, 2 GB maximum
- External Compact Flash: 256 MB default in slot 0, 4 GB maximum per slot
- USB: 2 x USB 2.0 Type A, 1 x USB console (Type B)
- Serial ports: 1 console, 1 auxiliary, up to 115.2 kbps
- AC input: 100 to 240 VAC, 47 to 63 Hz, 7.1 to 3.0 A maximum
- DC operating input: 24 to 60 VDC
- Rack height: 3 RU, 19 in. EIA or 23 in.
- Airflow: back to front
- Service-integrated performance: 150 Mbps

FAQs

Q: Which licences come with this bundle?
A: The bundle includes the Unified Communications and Security (SEC) licence PAK and FL-CUBEE-25, which covers 25 Cisco Unified Border Element Enterprise sessions. The base image is IP Base, and the licence PAK activates the UC and SEC feature sets.

Q: Can I add more CUBE sessions?
A: Yes. Additional CUBE sessions are available as stackable licences on top of the 25 sessions provided by FL-CUBEE-25.

Q: What power options are available for the 3945?
A: The 3945 platform supports an internal AC supply (100 to 240 VAC, 47 to 63 Hz) as well as PoE and DC (24 to 60 VDC) power-supply options.

Q: What modules does the 3945 work with?
A: It accepts EHWIC and HWIC modules, PVDM3 DSP modules, service modules including SRE and UCS-E, ISM modules, and Compact Flash cards up to 4 GB per slot. Two of the three onboard Gigabit ports can use SFP optics.

Q: How does this SKU differ from a standard 3945 router?
A: This is the Voice Sec and CUBE bundle. It adds the PVDM3-64 DSP module, the UC and SEC licence PAK and the 25-session FL-CUBEE-25 licence for secure voice and session border control deployments.
