Cisco

Cisco C3925-VSEC-PSRE-K9 | ISR 3925 Router, UC+SEC, PVDM3-64, SRE 900/910

C3925-VSEC-PSRE-K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ISR 3925 UC+SEC bundle is a Cisco 3900 Series Integrated Services Router (ISR G2) aimed at branch offices that need routing, voice, security and on-router application hosting in a single chassis.

This SKU combines the 3925 chassis with an SRE 900 or SRE 910 Services-Ready Engine module, a PVDM3-64 voice DSP module, and the Unified Communications (UC) and Security (SEC) licence PAKs. The SRE module uses an Intel Core2 Duo 1.86 GHz CPU with 4 GB DRAM by default, expandable to 8 GB, a 2 GB internal USB flash module, and two hot-swappable 500 GB SATA drives with RAID 0 or 1 support. It also provides hardware crypto acceleration, one RJ-45 Gigabit Ethernet port and one USB port. The PVDM3-64 supplies DSP resources for voice and video, while the bundled licence PAKs enable the UC and Security feature sets on the router.

The SRE 900 and 910 are supported in Cisco 2911, 2921, 2951, 3925, 3925E, 3945 and 3945E routers running IOS 15.1(4)M. The 3925 takes up to two SRE 700, 710, 900 or 910 service modules.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hosts Cisco and third-party applications on the SRE module, including Unity Express, UCS Express, WAAS, WLC, Prime NAM and Unified SIP Proxy
- Hot-swappable dual hard disks with RAID 0 or 1 on the SRE 900/910
- Hardware-based cryptography acceleration on the service module
- Bundled UC and SEC licence PAKs enable the Unified Communications and Security feature sets
- PVDM3-64 provides DSP resources for voice and video
- Converges routing, voice, security and application hosting in one branch chassis

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Chassis: Cisco 3925 ISR G2
- Bundle: UC and SEC licence PAK
- Voice DSP module: PVDM3-64
- Service module: SRE 900 or SRE 910 (SM-SRE-900-K9 / SM-SRE-910-K9)
- Service module form factor: SM (service module)
- Service module CPU: Intel Core2 Duo, 1.86 GHz
- Service module DRAM: 4 GB default, 8 GB option
- Service module flash: 2 GB internal USB flash module
- Service module storage: Two 500 GB SATA drives (1 TB in non-RAID mode)
- Drive speed: 5400 rpm (SRE 900), 7200 rpm (SRE 910)
- Hot-swappable drives: Yes
- RAID support: RAID 0 or 1 (application dependent)
- Service module interfaces: One RJ-45 Gigabit Ethernet, one USB
- Hardware crypto acceleration: Yes
- Required IOS release: 15.1(4)M
- Maximum SRE 700/710/900/910 modules in 3925: 2
- Maximum SRE modules of all types in 3925: 3
- Service module maximum power consumption: 50 W
- Service module dimensions (H x W x D): 4 x 18.9 x 19.1 cm
- Service module weight: up to 1.1 kg
- Service module operating temperature: 0 to 40 C normal, -5 to 55 C short term
- Service module operating humidity: 10 to 85%

FAQs

Q: Does this bundle include the UC and Security licences?
A: Yes. It includes the Unified Communications (UC) and Security (SEC) technology package licence PAKs for the Cisco ISR G2 router. Applications hosted on the SRE module may need their own licences.

Q: Is it supplied with an SRE 900 or an SRE 910?
A: The bundle covers an SRE 900 or SRE 910 service module. Both share the same CPU, memory and storage layout. The SRE 900 uses 5400 rpm drives and the SRE 910 uses 7200 rpm drives.

Q: How many SRE service modules can the 3925 take?
A: The 3925 supports up to two SRE 700, 710, 900 or 910 service modules, and up to three SRE modules of all types.

Q: Which IOS release does the SRE 900/910 require?
A: The SRE 900 and SRE 910 require Cisco IOS Release 15.1(4)M on the host router.

Q: What does the PVDM3-64 do?
A: The PVDM3-64 is a packet voice DSP module that provides the DSP resources the router uses for voice and video processing.
