• Cisco 1941 router in black and gray sleek modern design
1 1

Cisco

Cisco C2951-VSEC-PSRE-K9 | ISR 2951 Router, SRE 910, PVDM3-32, UC and SEC PAK

C2951-VSEC-PSRE-K9

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ISR 2951 is a Cisco ISR G2 branch router, supplied in this bundle with a Services-Ready Engine 910 service module, a 32-channel PVDM3 voice DSP module and the Unified Communications and Security licence PAKs. It suits branch offices and small enterprise sites that need an integrated router with voice gateway, security and on-router application services in one platform.

The 2951 chassis provides 3 onboard 10/100/1000 Ethernet WAN ports, with one port able to use SFP in place of RJ-45, plus 4 EHWIC slots, 3 DSP slots and 1 ISM slot. The base platform ships with 512 MB DRAM and 256 MB Compact Flash by default. The SRE 910 adds a 1.86 GHz Intel Core2 Duo service module with 4 GB DRAM as standard and a 2 GB internal USB flash module, while the PVDM3-32 supplies voice DSP resources. The UC and SEC licence PAKs enable Unified Communications and IOS security features on the Universal IOS image.

The 2951 accepts up to two SRE 700, 710, 900 or 910 service modules and one SRE 300 ISM, and supports EHWIC, SM and double-wide SM-D module families. An external Redundant Power Supply can be fitted for power redundancy or PoE boost.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Bundles router, service module, voice DSPs and licences under one SKU
- SRE 910 service module hosts virtualised applications on the router
- UC licence enables Unified Communications features such as CUBE and SRST
- SEC licence enables IOS security features including firewall, IPS and VPN
- Secure voice support with SRTP, SRTP-to-RTP fallback and AES-128
- Modular design with EHWIC, DSP and service module slots
- Optional external RPS for power redundancy

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Chassis: Cisco 2951 ISR (ISR G2)
- Service module: Cisco SRE 910 (Services-Ready Engine)
- Voice DSP: PVDM3-32
- Licences: UC and SEC License PAK
- Onboard WAN ports: 3 x 10/100/1000 Ethernet, one supports SFP in lieu of RJ-45
- EHWIC slots: 4
- DSP slots: 3
- ISM slot: 1
- Default memory: 512 MB DRAM
- Default flash: 256 MB Compact Flash
- Maximum SRE modules: 3 total (1 x SRE 300 ISM, 2 x SRE 700/710/900/910)
- Service module support: double-wide SM-D modules
- SRE 910 CPU: Intel Core2 Duo, 1.86 GHz
- SRE 910 DRAM: 4 GB default or 8 GB
- SRE 910 internal flash: 2 GB USB flash module
- Power redundancy: optional external RPS, PoE boost mode available with RPS
- Environment: designed for NEBS environments
- Hardware encryption: onboard IPSec VPN acceleration

FAQs

Q: Which licences does this bundle include?
A: It includes the Unified Communications (UC) and Security (SEC) licence PAKs on the Universal IOS image. The Data licence is a separate SL-29-DATA-K9 licence.

Q: How many service modules can the Cisco 2951 accept?
A: The 2951 supports up to 3 SRE modules in total: 1 SRE 300 ISM and 2 SRE 700, 710, 900 or 910 service modules.

Q: Can the router be powered redundantly?
A: Yes. The 2951 supports an optional external Redundant Power Supply (RPS) for power redundancy. The RPS can also be used for PoE boost mode, which doubles the platform's PoE power capacity.

Q: Which ISR G2 routers support the SRE 910?
A: The SRE 910 is supported on the Cisco 2911, 2921, 2951, 3925, 3925E, 3945 and 3945E ISR G2 routers.

Q: Can one of the WAN ports use fibre?
A: Yes. The 2951 has 3 onboard 10/100/1000 Ethernet ports, and one of them supports SFP-based fibre connectivity in place of RJ-45.
